Chevrolet engine rebuild kit and Chevrolet Master Engine Rebuild Kits- parts

Chevrolet Master Engine Rebuild Kits
or Overhaul Kits and parts

Master engine rebuild kits for Metro, GEO, Chevette, Tracker, Nova, Prism, Storm, Aveo, Luv truck, S10, S15, Berreta, Cobalt, Cavalier, Malibu, Camaro, Citation, Canyon, Colorado, Lumina, Monte Carlo, Uplander, Trailblazer, Envoy, Typhoon, Astro Van, Blazer, Express, Savana, Silverado, Tahoe, Avalanche, Impala, Suburban, Yukon, Caprice, Corvette, Chevrolet GMC master engine rebuild kits and Chevrolet engine rebuild kit with quality parts at affordable prices from RPM.

RPM - RON'S PRECISION MACHINE, INC.
69 E. 580 N.
Santaquin, Utah 84655

Hours: 9:00 AM to 5:00 PM Monday - Friday
Mountain Time (Utah)

We also offer re-ring kits, CRANKSHAFT KITS, connecting rods, valves and other engine parts. Just fill out the Order Form or

Contact us anytime OR use your e-mail program and type in ron@rpmrons.com to send an e-mail with what you need

.These prices are current. Call toll free to purchase kits or parts at: 1-866-700-5877 U.S. only. Don't forget to bookmark this site or add to favorites. Hours: 9:00 AM to 5:00 PM Monday - Friday mountain time (Utah) International orders (outside the U.S.) Click Here

All engine rebuild kits or engine overhaul kits are offered with standard size or oversized pistons
and std. size or oversize main & rod bearings and the cost of the kit is the same price. Quality and affordable prices on all kits.

Also see Crankshaft Kits for crankshaft kits with bearings for Chevrolet and other domestic and import engines.

Parts included in these master engine rebuild kits (MK) are: Pistons, wrist pins, rings, main bearings, rod bearings, thrust washers (if applicable), jack shaft bearings (if applicable), cam bearings (if applicable), camshaft(s), lifters (if applicable), freeze plugs, gasket set, complete timing kit, and oil pump. (Most kits are complete, call for parts in the kit). Some kits do not include camshaft, lifters or complete timing kit (just the timing belt).You can also purchase re-ring kits, crankshaft kits, cam kits, engine rebuild kits, rod and main bearing kits, or a master kit-delete pistons or individual parts.

The tables below show each kit contents and related parts for each engine.

If you do not see what you need, just

Contact us anytime OR use your e-mail program and type in ron@rpmrons.com to send an e-mail with what you need

or call Toll free 1-866-700-5877 to check stock and prices.

Suffix MK = master engine rebuild kit, includes all the parts in the columns to the right of the left colored column that states master kit.
Suffix EK = engine rebuild kit, is a master engine rebuild kit less: camshaft, lifters and timing set.
Suffix RRP = Re-ring kit, includes: gasket set, rings, main bearings, rod bearings, and thrust washers (if seperate from main bearings).
Suffix RR = Re-ring kit, includes: gasket set, rings, and rod bearings.
Suffix CK = Camshaft Kit (most includes lifters)
Suffix RMK = Rod & Main bearings kit (includes thrust washers if seperate).

Prices have changed on master kits & engine kits which varies because of different parts & options & for different years!!!!

Kits are listed by size of engine below

1.0L/61 cu. in. 85/00 OHC-3. >

CH61MK $613.68
Master
Kit

1996-00 OHC 3 master engine rebuild kit is $336.51
no oil pump

w/Topline pistons, wrist pins & premium rings (no oil pump)
$376.35

CH61EK $468.81
Engine
Kit

CH61RR $166.71
Re-ring
Kit

Rings	NOTE 1
Rod Bearings	CLE-CB1401AL $7.00 Clevite Engine Parts (3)
Gasket Set	09-01917 $66.59 ITM Engine Parts (85/88) --- OR --- 09-00114 $60.36 ITM Engine Parts (89/00)

Pistons	RY6413-3 $34.87 ITM Engine Parts (3) (85/88) --- OR --- RY6440 $34.74 ITM Engine Parts (3) (89/00)
Main Bearings	CLE-MS1708A $28.54 Clevite Engine Parts CLE-TW455S $12.58 Clevite Engine Parts
Cam Bearings	-
Oil Pump	057-1047 $98.41 ITM Engine Parts (85/95) Note 2
Freeze Plugs	-
Pin Bushings	-

CAM KIT

Camshaft

CH61CK

Lifters

TIMING KIT

TB095 $9.73 Engine Pro Timing Components (85/88)
--- OR ---
TB166 $14.25 Engine Pro Timing Components (89/93)
--- OR ---
TB241 $11.69 Engine Pro Timing Components (94/95)
--- OR ---
TB194 $14.14 Engine Pro Timing Components (96/00)
9182 $26.97 Engine Pro Timing Components (85/88)
--- OR ---
9343 $33.29 Engine Pro Timing Components (89/95)
--- OR ---
9221 $44.33 Engine Pro Timing Components (96/00)

Specialty KITS

CH61RRP $205.00

RE-RING KIT + MAIN BEARINGS

CH61RMK $55.48

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-12560 $391.99 (w/1.900" Neck Length)
CS-92560 $426.99 (w/2.100" Neck Length)

Related Parts

Intake Valves	RV9446 $10.22 ITM Engine Parts (3) (89/99 1.417 x 4.550 x .2738 x 1 grv) 10103 $11.08 E-Loy Engine Parts (3) (85/88 1.417 x 4.550 x .2738 x 1 grv)
Exhaust Valves	RX9432 $11.93 ITM Engine Parts (3) (89/99 1.181 x 4.510 x .273 x 1 Grv) RX9331 $25.36 ITM Engine Parts (3) (85/88 1.181 x 4.508 x .276 x 1 Grv) 10102S $18.87 E-Loy Engine Parts (3) (85/88 1.181 x 4.510 x .2738 x 1 grv - (Stainless Steel)
Valve Springs	-
Spring Shims	-
Valve Guides	VG1056CI $3.63 ITM Engine Parts (x6) (89/99) VG1039CI $3.39 ITM Engine Parts (x6) (85/88) VG1056BR $7.87 ITM Engine Parts (x6) (89/99)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	CRSZ1L $81.68 Topline Automotive (x4) BP-716 $60.18 (x4)
Cylinder Sleeves	CSL605A $36.44 Melling Automotive (3) (85/94)
Balancer Sleeve	-

Note 1: Opt. (OEM 2-Ring Piston use Top & Oil Ring Only) 41493CP $39.64 PC, RSSZ1 $57.34 Topline
Nore 2: Oil pump 1996-00 Topline OPSZ5 $144.80 not included.

84cu.in. 1.4L DOHC4 2011-2016
LUJ/LUV Turbo Cruze & Sonic

CH1364TMK $899.70
Master Kit

CH1364TEK $599.22
Engine Kit

CH1364TRR $356.02
Re-Ring Kit

Rings	Included with pistons
Rod Bearings	RBGM5 $45.06 Topline Automotive
Gasket Set	CGSGM5 $327.56 Topline Automotive Note: 1

Pistons Includes wrist pins & Premium ring	PAGM5 $85.64 Topline Automotive (x4)
Main Bearings	MBGM5 $67.08 Topline Automotive
Cam Bearings	-
Oil Pump	-
Freeze Plugs	-
Pin Bushings	-

CAM KIT

Camshaft

CH1364TCK

Lifters

LIFGM5 $12.42 Not included Topline

TIMING KIT

CTKGM5 $164.50 Topline Automotive
Does not include camshaft sprockets

Specialty KITS

CH1364TRRP $406.96

RE-RING KIT + MAIN BEARINGS

CH1364TRMK $85.76

ROD BEARINGS + MAIN BEARINGS

CRANK KIT

R E L A T E D

P A R T S

Intake Valves	IVGM5 $13.98 Topline
Exhaust Valves	EVGM5 $31.55 Topline
Valve Springs	-
Head Bolts	HBGM5 $54.60 Topline
Valve Guides	-
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	-
Cylinder Sleeves	-
Balancer Sleeve	-

Note:1: Not included - FelPro head gasket set FELP-HS26540PT1 $317.95 , FelPro conversion gasket set FELP-CS26540 $112.65

1.5L/1471-cc 85/89 4XC1 OHC-4

CH92MK $611.99
Master
Kit

CH92EK $480.05
Engine
Kit

CH92RR $170.03
Re-ring
Kit

Rings	NOTE 1
Rod Bearings	CLE-CB1478P $7.65 Clevite Engine Parts (x4)
Gasket Set	09-01910 $79.40 ITM Engine Parts

Pistons	RY6493 $41.12 ITM Engine Parts (x4)
Main Bearings	5M9336 $44.35 ITM Engine Parts 1T1003 $7.09 ITM Engine Parts
Cam Bearings	-
Oil Pump	OPIS3 $174.49 Topline Automotive
Freeze Plugs	-
Pin Bushings	-

CAM KIT

Camshaft	CAMIS3 $152.10 Topline Automotive	CH92CK $122.37
Lifters	-	-

TIMING KIT

TB118 $9.02 Engine Pro Timing Components (85/87 To 4/30/87)
--- OR ---
TB162 $12.15 Engine Pro Timing Components (87/91 5/1/87 Up)

Specialty KITS

CH92RRP $220.90

RE-RING KIT + MAIN BEARINGS

CH92RMK $96.82

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-12540 $436.87 (6 bolt f/w)
CS-12640 $436.87 (8 bolt f/w)

Related Parts

Intake Valves	RV35080 $7.81 ITM Engine Parts (x4) IVIS3 $14.20 Topline Automotive
Exhaust Valves	RX35080 $11.89 ITM Engine Parts (x4) EVIS3 $14.37 Topline Automotive (x4)
Valve Springs	VS1224 $18.84 ITM Engine Parts (x8)
Spring Shims	-
Valve Guides	VG1093CI $3.39 ITM Engine Parts (x4) (Int) VG1094CI $3.39 ITM Engine Parts (x4) (Exh)
Push Rods	-
Rocker Arms	056-6226 $30.08 ITM Engine Parts (x8) R9033 $0.00 EPWI P/L Valve Train Component (x8)
Oil Pump Screens	-
Connecting Rods	CRIS3 $69.18 Topline Automotive (x4)
Cylinder Sleeves	CSL1116 $41.21 Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. HA-4241 $82.44 or HA-2M4241 $96.82 Hastings, 41491 $54.43 PC, E546KC $65.07 Sealed Power, 021-6154 $54.03 ITM

1.6L/98 cu. in. 85/88 OHC-4
(Toyota 4ALC engine SOHC)

CH98MK $650.25
Master
Kit

CH98EK $392.49
Engine
Kit

CH98RR $128.58
Re-ring
Kit

Rings	NOTE 1
Rod Bearings	4B1710 $23.63 Engine Parts
Gasket Set	09-01559 $69.79 ITM Engine Parts (85) --- OR --- 09-01597 $77.85 ITM Engine Parts (86/88)

Pistons	RY6470 $38.03 ITM Engine Parts (x4)
Main Bearings	5M9310 $30.15 ITM Engine Parts 2T9304 $8.08 ITM Engine Parts
Cam Bearings	-
Oil Pump	OPTO18 $148.08 Topline Automotive
Freeze Plugs	MPE195R $4.26 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC967 $101.55 Engine Pro Camshafts	CH98CK $100.01
Lifters	-	-

TIMING KIT

TB070 $8.51 Engine Pro Timing Components
S560 $30.15 Engine Pro Timing Components
S551 $41.26 Engine Pro Timing Components
9066 $25.27 Engine Pro Timing Components

Specialty KITS

CH98RRP $165.19

RE-RING KIT + MAIN BEARINGS

CH98RMK $58.77

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	RV9225 $12.56 ITM Engine Parts (x4) (1.417 x 4.212 x 0.2746 1 grv) 10107 $7.27 E-Loy Engine Parts (x4) (1.417 x 4.212 x 0.2746 1 grv)
Exhaust Valves	RX9226 $10.61 ITM Engine Parts (x4) (1.220 x 4.212 x 0.2745 1 grv) 10106 $10.92 E-Loy Engine Parts (x4) (1.220 x 4.212 x 0.2745 1 grv)
Valve Springs	VS1147 $7.41 ITM Engine Parts (x8) RV1202 $3.84 Pioneer Products (x8)
Spring Shims	-
Valve Guides	140-8020 $3.45 E-Loy Engine Parts (x4) (Int) VG873CI $3.56 ITM Engine Parts (x4) (Intake) 140-8021 $3.24 E-Loy Engine Parts (x4) (Exh) VG874CI $3.56 ITM Engine Parts (x4) (Exhaust)
Push Rods	-
Rocker Arms	R9035 $20.48 EPWI P/L Valve Train Component (x4) (Intake) R9036 $0.00 EPWI P/L Valve Train Component (x4) (Exhaust)
Oil Pump Screens	287S $93.75 Melling Automotive
Connecting Rods	CRTO16L $84.32 Topline Automotive (x4)
Cylinder Sleeves	CSL623 $30.07 Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. HA-6180 $52.26 or HA-2M6180 $61.91 Hastings, E456KC $47.62 Sealed Power

1.6L/98 cu. in. 2004-2011 DOHC4 L91, LXV E-Tec II, VIN E -
2009-2011 Chevrolet Aveo, Pontiac G3, G3Wave, 2009 Suzuki Swift+

CH98LMK $813.46
Master
Kit

CH98LEK $630.02
Engine Kit

CH98LRR $270.20
Re-ring Kit

Rings	NOTE 1
Rod Bearings	RBGM1 $39.61 Topline Automotive
Gasket Set	CGSGM1 $238.67 Topline Automotive (04/05) CGSGM1L $238.67 Topline Automotive (06/08) CGSGM3 $241.76 Topline Automotive (09/11 Aveo Pontiac G3 09-Suzuki Swift+)

Pistons	PAGM1 $81.77 Topline Automotive (x4) (04/08) PAGM3 $86.88 Topline Automotive (4) (09/11 Aveo Pontiac G3 09- Suzuki Swift+)
Main Bearings	MBGM1 $62.01 Topline Automotive
Cam Bearings	.
Oil Pump	OPGM1 $235.46 Topline Automotive (04/08) OPGM6 $260.08 Topline Automotive (09/11 Aveo Pontiac G3 09-Suzuki Swift+)
Freeze Plugs	.
Pin Bushings	.

CAM
KIT

Camshaft	.	CH98LCK
Lifters	.	.

TIMING
KIT

TB310 $34.77 Engine Pro Timing Components (04/08)
TBGM3 $145.68 Topline Automotive (09/11 Aveo Pontiac G3 09-Suzuki Swift+)

SPECIALTY
KITS

CH98LRRP $316.20

RE-RING KIT + MAIN Bearings

CH98LRMK $77.85

ROD Bearings + MAIN Bearings

CRANK KIT

CS-10440 $497.36 KITS (04/08 04-08 L91 E-TEC Aveo) includes Bearings

Related Parts

Intake Valves	02247 $9.03 SB International (x8) (04/08 1.124 x 3.999 x .2345 1 grv) IVGM3 $13.94 Topline Automotive (x8) (09/11 31.15MM x 117.2MM)
Exhaust Valves	02248S $15.84 SB International (x8) (04/08 1.073 x 3.982 x .2337 1 grv Stellite) EVGM3 $30.80 Topline Automotive (x8) (09/11 27.5MM x 116.3MM)
Valve Springs	.
Spring Shims	.
Valve Guides	140-3046 $2.15 SB International (x16) (04/08)
Push Rods	.
Rocker Arms	.
Oil Pump Screens	.
Connecting Rods	.
Cylinder Sleeves	.
Balancer Sleeve	.

Note 1: 04/08 RSGM1 $63.87 09/11 RSGM3 $82.93 Topline

1.8L/110 cu. in. 76/81 Luv Pickup
LUV- OHC-4 G180Z

CH110LMK $780.61
Master
Kit

Delete camshaft $583.73

CH110LEK $575.53
Engine
Kit

CH110LRR $144.52
Re-ring
Kit

Rings	NOTE 1 HA-9101 $57.14 Hastings Rings
Rod Bearings	4B2816 $22.09 ITM Engine Parts (sell out & reorder 4B9420) --- OR --- 4B9420 $23.85 ITM Engine Parts (replaces 4B2816)
Gasket Set	09-01901 $79.40 ITM Engine Parts

Pistons	SILV-1462 $80.90 (x4) Silvolite Pistons
Main Bearings	5M2817 $38.00 ITM Engine Parts 1T9966 $5.42 ITM Engine Parts
Cam Bearings	-
Oil Pump	057-1116 $82.55 ITM Engine Parts
Freeze Plugs	MPE146R $4.02 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC720 $92.19 Engine Pro Camshafts N/A	CH110LCK $92.03
Lifters	-	-

TIMING KIT

C4007S $100.00 Engine Pro Timing Components

Specialty KITS

CH110LRRP $185.84

RE-RING KIT + MAIN BEARINGS

CH110LRMK $109.50

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-12580 $475.99 (22 1/2 o.a.l. 6-bolt f/w)

Related Parts

Intake Valves	10087 $8.32 E-Loy Engine Parts (x4) (76/79 1.673 x 4.315 x .313 -1 grv) RV9233 $10.81 ITM Engine Parts (x4) (80/82 1.574 x 4.350 x .315 -1 grv) RV9151 $8.40 ITM Engine Parts (x4) (76/79 1.669 x 4.315 x .315 -1 grv) 10094 $8.86 E-Loy Engine Parts (x4) (80/82 1.588 x 4.353 x .3125 -1 grv)
Exhaust Valves	RX9232 $14.18 ITM Engine Parts (x4) (80/82 1.339 x 4.303 x .315 -1 grv) RX9157 $12.05 ITM Engine Parts (x4) (76/79 1.339 x 4.362 x .315 -1 grv) 10086 $10.68 E-Loy Engine Parts (x4) (76/79 1.339 x 4.363 x .313 -1 grv) 10093 $11.51 E-Loy Engine Parts (x4) (80/82 1.337 x 4.301 x .312 -1 grv)
Valve Springs	RV1130 $3.54 Pioneer Products (x8) (Outer) RV1131 $3.31 Pioneer Products (x8) (Inner) VS1117 $9.30 ITM Engine Parts (x8) (Outer) VS1116 $8.19 ITM Engine Parts (x8) (Inner)
Spring Shims	-
Valve Guides	07582 $3.98 Pioneer Products (x4) (Intake) VG949CI $3.32 ITM Engine Parts (x4) (Intake) 07581 $3.68 Pioneer Products (x4) (Exhaust) VG950CI $3.70 ITM Engine Parts (x4) (Exhaust)
Push Rods	-
Rocker Arms	R9041 $29.46 EPWI P/L Valve Train Component (x8)
Oil Pump Screens	-
Connecting Rods	CRIS2 $82.44 Topline Automotive (x4)
Cylinder Sleeves	CSL840 $31.64 Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. HA-4247 $42.79 or HA-2C4247 $50.69 Hastings; 41209 $78.77 PC; E357X $36.52 or E357KC $57.10 Sealed Power

1.8L/112 cu. in. 1982.
Pass Vin 'G' OHV-4

CH112MK $751.90
Master
Kit

CH112EK $586.65
Engine
Kit

CH112RR $252.62
Re-ring
Kit

Rings	NOTE 1 HA-2M4408 $152.51 Hastings Rings
Rod Bearings	CLE-CB745P $10.75 Clevite Engine Parts (x4)
Gasket Set	FELP-FS8851PT1 $93.79 FEL PRO GASKETS

Pistons	642P $18.87 Sealed Power Pistons (x4)
Main Bearings	CLE-MS1524P $58.69 Clevite Engine Parts
Cam Bearings	CH19 $31.74 Durabond
Oil Pump	M98 $141.35 Melling Automotive
Freeze Plugs	MPE173R $3.15 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC826 $60.26 Engine Pro Camshafts	CH112CK $98.37
Lifters	HA817 $4.91 EPW Tappets (x8)	CH112CK $98.37

TIMING KIT

C3060 $46.77 Cloyes Gears

Specialty KITS

CH112RRP $308.40

RE-RING KIT + MAIN BEARINGS

CH112RMK $96.93

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	-
Exhaust Valves	-
Valve Springs	RV1038X $7.08 Engine Pro Valve Train Comp (x8)
Spring Shims	-
Valve Guides	140-9705 $1.96 E-Loy Engine Parts (x8) (W/Iron Head) 140-8114 $3.05 E-Loy Engine Parts (x4) (Int W/Alum Head) 140-8115 $2.85 E-Loy Engine Parts (x4) (Exh W/Alum Head)
Push Rods	PR346 $1.88 EPWI P/L Valve Train Component (x8) EL-PR346 $5.39 Elgin Industries (x8)
Rocker Arms	RK407 $4.60 EPWI P/L Valve Train Component (x8) EL-RK407 $9.38 Elgin Industries (x8)
Oil Pump Screens	98S $20.45 Melling Autom
Connecting Rods	BP-530 $42.74 (x4)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x4)
Balancer Sleeve	HB4121 $5.35 Pioneer Products (Balancer)

Note 1: Opt. 41652 PC

1.8L/1796cc 00/05 2ZZGE 16V DOHC4
Celica GTS, Matrix XRS

TO1796MK $721.62
Master
Kit

TO1796EK $732.89
Engine
Kit

TO1796RR $262.29
Re-Ring
Kit

Rings	NOTE 1 (included in re-ring kit & pistons)
Rod Bearings	RBTO42 $50.96 Topline Automotive
Gasket Set	NOTE 2 09-09806 $107.93 ITM Engine Parts

Pistons	PATO42 $81.85 Topline Automotive (x4)
Main Bearings	MBTO42 $55.44 Topline Automotive TWTO39 $11.08 Topline Automotive
Cam Bearings	-
Oil Pump	OPTO42 $142.64 Topline Automotive
Freeze Plugs	EPSTO42 $9.62 Topline Automotive
Pin Bushings	PBTO39 $8.36 Topline Automotive (x4)

CAM KIT

Camshaft

TO1796CK

Lifters

TIMING KIT

Specialty KITS

TO1796RRP $313.17

RE-RING KIT + MAIN BEARINGS

TO1796RMK $108.06

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	IVTO42 $12.69 Topline Automotive (x8)
Exhaust Valves	EVTO42 $16.90 Topline Automotive (x8)
Valve Springs	-
Spring Shims	-
Valve Guides	VGTO42 $6.44 Topline Automotive (x16)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	CRTO42 $100.33 Topline Automotive (x4)
Cylinder Sleeves	-
Balancer Sleeve	-

Note 1: Opt. HA-2C5087 $39.69 Hastings
Note 2: Not incl. Head Bolts use 38-916 $58.62 Engine Pro

112cu.in. 1.8L DOHC4 2011-2016
LUW/LWE Cruze (2011-15) & Sonic

CH1796MK $1,143.07
Master Kit
No lifters
No timing belt

CH1796EK $807.48
Engine Kit

CH1796RR $357.69
Re-Ring Kit

Rings	Included with pistons (RSGM6 $126.63)
Rod Bearings	Note:1 ** RBGM6 $46.63 Automotive Or * RBGM1 $39.61
Gasket Set	CGSGM6 $285.47 Topline Automotive

Pistons Includes wrist pins & Premium ring	PAGM6 $100.01 Topline Automotive (x4)
Main Bearings	MBGM1 $62.01 Topline Automotive
Cam Bearings	-
Oil Pump	OPGM6 $260.08 Topline Automotive
Freeze Plugs	-
Pin Bushings	-

CAM KIT

Camshaft

N/A

CH1796CK

Lifters

LIFGM6 $25.17 each Not in any kit above

TIMING KIT

Timing belt TBGM3 $145.68 not in any kit above

Specialty KITS

CH1796RRP $405.34

RE-RING KIT + MAIN BEARINGS

CH1796RMK $84.08

ROD BEARINGS + MAIN BEARINGS

CRANK KIT

R E L A T E D

P A R T S

Intake Valves	IVGM6 $13.36
Exhaust Valves	EVGM6 $17.71
Valve Springs	-
Spring Shims	-
Valve Guides	VGGM3 $7.19
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	-
Cylinder Sleeves	-
Balancer Sleeve	-
Water Pump	WPGM3 $108.10

Note 1: **tabs 1/2 & 1/2 Or *tab all on one side

1.9L/119 cu. in. 82/85 OHC-4

CH119MK $872.69
Master
Kit

CH119EK $743.99
Engine
Kit

CH119RR $341.83
Re-ring
Kit

Rings	NOTE 1 HA-2C6149 $82.62 Hastings Rings (w/1.5mm Comp Rings) The pistons below includes ITM rings
Rod Bearings	CLE-CB1654P $15.66 Clevite Engine Parts (x4)
Gasket Set	FELP-260-1090 $109.63 Sealed Power

Pistons	ber: RY6371 $39.58 39 ITM $163.12 set of 4 std., .020", .030" or .040"
Main Bearings	5M2817 $38.00 ITM Engine Parts CLE-TW451S $10.14 Clevite Engine Parts
Cam Bearings	-
Oil Pump	NOTE 2 057-1116 $82.55 ITM Engine Parts
Freeze Plugs	MPE171R $2.53 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC720 $92.19 no longer available - not in kit
Lifters	-	-

TIMING KIT

3SR94 $20.45 Engine Pro Timing Components
S500 $17.32 Engine Pro Timing Components
S501 $8.81 Engine Pro Timing Components
7034 $9.00 Pro Timing Components
9061 $28.52 Engine Pro Timing Components
9063 $10.35 Engine Pro Timing Components

Specialty KITS

CH119RRP $387.75

RE-RING KIT + MAIN BEARINGS

CH119RMK $101.59

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	RV9233 $10.81 ITM Engine Parts (x4) (1.574 x 4.358 x .315 -1 grv) 10094 $8.86 E-Loy Engine Parts (x4) (1.588 x 4.353 x .3125 -1 grv)
Exhaust Valves	RX9232 $14.18 ITM Engine Parts (x4) (1.339 x 4.303 x .315 -1 grv) 10093 $11.51 E-Loy Engine Parts (x4) (1.337 x 4.301 x .3120 -1 grv)
Valve Springs	RV1130 $3.54 Pioneer Products (x4) (82/83 Outer) RV1131 $3.31 Pioneer Products (x8) (82/83 Inner)
Spring Shims	-
Valve Guides	VG949CI $3.32 ITM Engine Parts (x4) (Intake) 140-7713 $3.72 E-Loy Engine Parts (x4) (Int) VG950CI $3.70 ITM Engine Parts (x4) (Exhaust) 140-7714 $3.83 E-Loy Engine Parts (x4) (Exh)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	CRIS2 $82.44 Topline Automotive (x4)
Cylinder Sleeves	CSL870 $47.56 Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. (OEM pist) 41453 $59.08 PC, E483K $61.79 Sealed Power, 021-6402 $39.62 ITM, RSIS2 $68.91 Topline: (repl pist) 41452 $65.02 PC, E484K $105.12 Sealed Power, 021-6143 $31.74 ITM, RSIS2L $84.37 Topline

Note 2: Opt. OPIS2 $115.40 Topline

2.2L/133 cu. in. 90/93 OHV-4

CH133MK $745.58
Master
Kit

CH133EK $592.83
Engine
Kit

CH133RR $125.39
Re-ring
Kit

Rings	NOTE 1 HA-2M6209 $57.13 Hastings Rings
Rod Bearings	CLE-CB745P $10.75 Clevite Engine Parts (x4)
Gasket Set	FELP-260-1227 $127.12 Sealed Power (90/91) --- OR --- FELP-260-1562 $120.70 Sealed Power (92/93 w/8.0mm Valve Stem) --- OR --- FELP-260-1749 $120.63 Sealed Power (93 w/7.0mm Valve Stem)

Pistons	569P $33.20 Sealed Power Pistons (x4) (90/91) --- OR --- H637CP $53.90 Sealed Power Pistons (x4) (92/93)
Main Bearings	CLE-MS1704A $33.31 Clevite Engine Parts
Cam Bearings	CH19 $31.74 Durabond
Oil Pump	M98 $141.35 Melling Automotive
Freeze Plugs	MPE240R $8.06 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC1935 $66.72 Engine Pro Camshafts	CH133CK $112.67
Lifters	HA969 $5.76 EPW Tappets (x8)	CH133CK $112.67

TIMING KIT

3047 $45.94 Engine Pro Timing Components

Specialty KITS

CH133RRP $155.76

RE-RING KIT + MAIN BEARINGS

CH133RMK $73.08

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	01569 $9.40 E-Loy Engine Parts (x4) (90/91 1.693 x 5.456 x .3136 -1 grv) 01705 $10.64 E-Loy Engine Parts (x4) (92/93 1.732 x 5.457 x .3136 -1 grv) S2684 $11.42 Engine Pro Valves (x4) (92/93 1.732 x 5.457 x .3136 -1 grv)
Exhaust Valves	01568 $7.97 E-Loy Engine Parts (x4) (90/91 1.457 x 5.165 x .3132 -1 grv)
Valve Springs	VS907 $9.24 Sealed Power (x8) (90/91) 160-1086 $3.13 E-Loy Engine Parts (x8) (90/91)
Spring Shims	-
Valve Guides	140-9705 $1.96 E-Loy Engine Parts (x8) (W/Iron Head) 140-8114 $3.05 E-Loy Engine Parts (x4) (Int W/Alum Head) 140-8115 $2.85 E-Loy Engine Parts (x4) (Exh W/Alum Head)
Push Rods	PR445 $3.53 EPWI P/L Valve Train Component (x8)
Rocker Arms	R1090 $9.89 Sealed Power (x8) (90/91) 181-1063 $18.84 E-Loy Engine Parts (x8) (90/91)
Oil Pump Screens	98S $20.45 Melling Automotive (90/91)
Connecting Rods	BP-542 $42.74 (x4) (exc Alum.Head) BP-562 $48.48 (x4) (w/Alum.Head)
Cylinder Sleeves	CSL1137 $31.78 Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. 41564 $44.42 PC, E477K $79.39 Sealed Power

2.2L/133 cu. in. 94/97 OHV-4

CH133LMK $561.08
Master
Kit

CH133LEK $508.63
Engine
Kit

CH133LRR $192.22
Re-ring
Kit

Rings	NOTE 1 HA-2M6209 $57.13 Hastings Rings
Rod Bearings	CLE-CB745P $10.75 Clevite Engine Parts (x4)
Gasket Set	FELP-260-1749 $120.63 Sealed Power (Passenger) --- OR --- FELP-260-1748 $115.96 Sealed Power (Truck)

Pistons	H637CP $53.90 Sealed Power Pistons (x4)
Main Bearings	CLE-MS1704A $33.31 Clevite Engine Parts
Cam Bearings	CH19 $31.74 Durabond
Oil Pump	M248 $117.50 Melling Automotive
Freeze Plugs	MPE240R $8.06 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

NOTE 2

CH133LCK

Lifters

NOTE 3

TIMING KIT

3019 $55.46 Engine Pro Timing Components

Specialty KITS

CH133LRRP $224.08

RE-RING KIT + MAIN BEARINGS

CH133LRMK $74.65

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	S2892 $9.94 Engine Pro Valves (x4) (1.732 x 5.465 x .2742 -1 grv)
Exhaust Valves	A2885 $12.51 Engine Pro Valves (x4) (1.457 x 5.142 x .2738 -1 grv)
Valve Springs	VS1628 $9.67 Sealed Power (x8) 160-1267 $4.85 E-Loy Engine Parts (x8)
Spring Shims	-
Valve Guides	140-8536 $3.85 E-Loy Engine Parts (x4) (Intake) 140-8535 $3.04 E-Loy Engine Parts (x4) (Exhaust)
Push Rods	RP3328 $8.78 Sealed Power (x8) 192-1513 $3.39 E-Loy Engine Parts (x8) PR610 $4.37 EPWI P/L Valve Train Component (x8)
Rocker Arms	R1090 $9.89 Sealed Power (x8) 181-1063 $18.84 E-Loy Engine Parts (x8)
Oil Pump Screens	248S $17.38 Melling Automotive (Car) 249S $25.30 Melling Automotive (Truck)
Connecting Rods	BP-562 $48.48 (x4)
Cylinder Sleeves	CSL1137 $31.78 Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. 41564 $44.42 PC, E477k $79.39 Sealed Power
Note 2: Not incl. MC1303 $425.90 Melling
Note 3: Not incl. HA2270 $11.93 Tappet (x8) Roller lifter

2.2L/133 cu. in. 98/03 Vin 4, 5 - OHV-4

CH133LLMK $691.59
Master
Kit

CH133LLEK $627.81
Engine
Kit

CH133LLRR $287.76
Re-ring
Kit

Rings	NOTE 1 HA-2M6209 $57.13 Hastings Rings
Rod Bearings	CLE-CB745P $10.75 Clevite Engine Parts (x4)
Gasket Set	NOTE 2 FELP-HS9170PT1 $157.27 FEL PRO GASKETS (98/02 Vin 4) AND FELP-CS9469 $82.46 FEL PRO GASKETS --- OR --- FELP-HS9170PT2 $150.81 FEL PRO GASKETS (00/03 Vin 5) AND FELP-CS9469 $82.46 FEL PRO GASKETS

Pistons	H851CP $65.13 Sealed Power Pistons (x4)
Main Bearings	7369MA $123.80 Sealed Power Engine Bearings
Cam Bearings	CH19 $31.74 Durabond
Oil Pump	M248 $117.50 Melling Automotive
Freeze Plugs	MPE240R $8.06 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

NOTE 3

CH133LLCK

Lifters

NOTE 4

TIMING KIT

3019 $55.46 Engine Pro Timing Components

Specialty KITS

CH133LLRRP $363.92

RE-RING KIT + MAIN BEARINGS

CH133LLRMK $117.45

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	V4572 $33.22 Sealed Power (x4) (1.732 x 5.2850 x .2746 -1 grv) 01902 $11.26 E-Loy Engine Parts (x4) (1.732 x 5.2850 x .2746 -1 grv) S3456 $11.37 Engine Pro Valves (x4) (1.732 x 5.2850 x .2746 -1 grv)
Exhaust Valves	V4558 $17.33 Sealed Power (x4) (1.457 x 5.0000 x .2738 -1 grv) 01903 $15.84 E-Loy Engine Parts (x4) (1.457 x 5.0000 x .2738 -1 grv) A3449 $17.33 Engine Pro Valves (x4) (1.457 x 5.0000 x .2738 -1 grv)
Valve Springs	VS1644 $9.33 Sealed Power (x8) 160-1436 $11.23 E-Loy Engine Parts (x8)
Spring Shims	-
Valve Guides	140-3009 $3.37 E-Loy Engine Parts (x8) (Int & Exh)
Push Rods	RP3341 $5.22 Sealed Power (x8) 190-1539 $3.35 E-Loy Engine Parts (x8)
Rocker Arms	-
Oil Pump Screens	248S $17.38 Melling Automotive (Car) 249S $25.30 Melling Automotive (Truck)
Connecting Rods	BP-562 $48.48 (x4)
Cylinder Sleeves	CSL1137 $31.78 Melling Automotive (x4)
Balancer Sleeve	MS228 $640.64 Micro Sleeve Company, Inc. (Balancer) MS337 $11.34 Micro Sleeve Company, Inc. (R. Crank)

Note 1: Opt. 41564 $44.42 PC, E531K $149.38 Sealed Power
Note 2: Head Bolts not incl. use FELP-ES72170 $41.13 FelPro
Note 3: Not incl use MC1351 $535.75 Melling
Note 4: Not incl use HA2270 $11.93 (x8) Tappet

2.2L/133 cu. in. 2000/08 DOHC
VIN 'D', 'F', '6'

CH133LDMK $2,504.12
Master
Kit

CH133LDEK $1,316.38
Engine
Kit

CH133LDRR $869.54
Re-ring
Kit

Rings	NOTE 1 HA-2C5130 $50.75 Hastings Rings
Rod Bearings	CLE-CB1827A $9.06 Clevite Engine Parts (x4)
Gasket Set	NOTE 2 FELP-260-1962 $317.89 Sealed Power (00/01 00-All & 01-w/AT exc Calif.) --- OR --- FELP-260-1963 $305.06 Sealed Power (01 w/ MT & w/AT Calif.) --- OR --- FELP-260-1961 $316.25 Sealed Power (02/06 All) --- OR --- FELP-HS26223PT5 $255.85 FEL PRO GASKETS (07/08) AND FELP-CS26223-1 $103.14 FEL PRO GASKETS (06/08)

Pistons	H1120CPA $92.08 Sealed Power Pistons (x4)
Main Bearings	CLE-MS2232A $114.27 Clevite Engine Parts
Cam Bearings	SH2002S $44.42 Clevite Engine Parts (Balance shaft brg set)
Oil Pump	K349 $198.61 Melling Automotive
Freeze Plugs	-
Pin Bushings	-

CAM KIT

Camshaft	CS1586 $346.41 Sealed Power (02/06 Intake - Vin F & 6) CS1588 $322.55 Sealed Power (02/06 Exhaust - Vin F & 6)	CH133LDCK $820.33
Lifters	HT2307 $19.00 Sealed Power (x16) (02/06)	CH133LDCK $820.33

TIMING KIT

C6092S $217.59 Engine Pro Timing Components (00/07 Timing kit - camshaft/ Cavalier,Malibu)
--- OR ---
C6209S $171.48 Engine Pro Timing Components (05/08 Timing kit- camshaft/ Cobalt,HHR)
C6093S $152.43 Engine Pro Timing Components (00/05 Balance shaft kit)

Specialty KITS

CH133LDRRP $972.86

RE-RING KIT + MAIN BEARINGS

CH133LDRMK $144.45

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-11460 $515.04 (# 7327, Ecotec, Cavalier, Cobalt, HHR, Malibu)

Related Parts

Intake Valves	S4584 $11.40 Engine Pro Valves (x8) (00/06 1.382 x 4.026 x .2347 -3 grv) V4673 $25.23 Sealed Power (x8) (00/05 1.382 x 4.026 x .2347 -3 grv) 01997 $14.09 E-Loy Engine Parts (x8) (00/06 1.382 x 4.026 x .2347 -3 grv)
Exhaust Valves	A4585 $17.43 Engine Pro Valves (x8) (00/06 1.185 x 3.975 x .2343 -3 grv) 02010S $23.64 E-Loy Engine Parts (x8) (00/06 1.185 x 3.975 x .2343 -3 grv)
Valve Springs	160-1508 $6.95 E-Loy Engine Parts (x16) (00/06 (Int & Exh))
Spring Shims	-
Valve Guides	140-3029 $2.75 E-Loy Engine Parts (x16) (00/06 (Int & Exh ))
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	-
Cylinder Sleeves	-
Balancer Sleeve	-

Note 1: Opt. E971K $174.84 Sealed Power Note 2: Not incl Head Bolts use 38-314 $63.41 Engine Pro or FELP-ES72196 $142.86 FelPro

2.3L/138 cu. in. 89/95 QUAD 4
Vin 'A' & 'D' DOHC4

OL138MK $1,442.07
Master
Kit

OL138EK $982.78
Engine
Kit

OL138RR $322.34
Re-ring
Kit

Rings	NOTE 1 HA-2M4468 $115.88 Hastings Rings
Rod Bearings	1540A $19.02 Sealed Power Engine Bearings (x4)
Gasket Set	FELP-260-1460 $226.77 Sealed Power (88/91) --- OR --- FELP-260-1644 $200.21 Sealed Power (92/94) --- OR --- FELP-HS9515PT3 $200.20 FEL PRO GASKETS (95) AND FELP-CS9515-1 $63.44 FEL PRO GASKETS (95)

Pistons	H566P $31.74 Sealed Power Pistons (x4) (Replaces Early & Late Design)
Main Bearings	7054MA $92.16 Sealed Power Engine Bearings
Cam Bearings	1883M $28.46 Sealed Power Engine Bearings (Bal Shaft)
Oil Pump	M136 $162.05 Melling Automotive (87/94) --- OR --- M205 $138.27 Melling Automotive (95)
Freeze Plugs	MPE242R $4.87 Melling Automotive
Pin Bushings	1544Y $17.25 Sealed Power Engine Bearings (x4)

CAM KIT

Camshaft	MC1941 $71.36 Engine Pro Camshafts (87/94 Vin D Intake) AND MC1942 $136.61 Engine Pro Camshafts (87/94 Vin D Exhaust)	OL138CK $381.54
Lifters	HA2236 $10.38 EPW Tappets (x16)	OL138CK $381.54

TIMING KIT

3099 $103.27 Engine Pro Timing Components (1st Design Only (Double Row Chain))

Specialty KITS

OL138RRP $411.02

RE-RING KIT + MAIN BEARINGS

OL138RMK $168.75

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-20200 $489.75 (87/88 Specify Frg#)
CS-20300 $444.76 (89/94 Specify Frg#)

Related Parts

Intake Valves	S2228 $8.94 Engine Pro Valves (x8) (89/92 89 Vin'A' 90-92 all 1.441 x 4.328 x .2750 -1 grv) 01673 $7.38 E-Loy Engine Parts (x8) (88/89 Vin "D" 1.398 x 4.331 x .2748 -1 grv)
Exhaust Valves	A2265 $9.68 Engine Pro Valves (x8) (89/92 89 Vin'A' 90-92 all 1.239 x 4.308 x .2745 -1 grv) 01674 $9.64 E-Loy Engine Parts (x8) (88/89 1.182 x 4.311 x .2743 -1 grv)
Valve Springs	VS1530 $8.19 Sealed Power (x16) (88/89 88-89) 160-1112 $6.36 E-Loy Engine Parts (x16) (88/89)
Spring Shims	-
Valve Guides	140-8124 $3.20 E-Loy Engine Parts (x16) (87/92)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	255S $107.91 Melling Automotive (89/94 87-88 VIN D 2nd DES, 89-94 VIN A, 89-94 VIN D All.)
Connecting Rods	BP-553 $42.74 (x4) (87/92 Oval Cap (Replaces 554 $63.43 Bushed w/Oval Cap)) BP-545 $42.74 (x4) (87/92 1" Bar (Replaces 552 $42.90 Bushed w/Bar Cap))
Cylinder Sleeves	CSL144 $31.64 Melling Automotive (x4) (87/92)
Balancer Sleeve	-

Note 1: Opt. 41555CP $88.88 PC E535K $166.82 Sealed Power

2.4L/146 cu. in. 96/99 DOHC Quad 4 DOHC4

OL146MK $988.85
Master
Kit

OL146EK $820.38
Engine
Kit

OL146RR $429.19
Re-Ring
Kit

Rings	NOTE 1 HA-2C4898 $96.78 Hastings Rings
Rod Bearings	CLE-CB1647A $8.00 Clevite Engine Parts (x4) (replaces CLE-CB1647P)
Gasket Set	NOTE 2 FELP-HS9115PT $302.02 FEL PRO GASKETS (exc 99 w/o EGR) AND FELP-CS9115 $66.67 FEL PRO GASKETS

Pistons	H837CP $39.58 Sealed Power Pistons (x4)
Main Bearings	CLE-MS2056A $72.95 Clevite Engine Parts (replaces MS2056P)
Cam Bearings	1883M $28.46 Sealed Power Engine Bearings (Bal Shaft)
Oil Pump	M205 $138.27 Melling Automotive
Freeze Plugs	MPE242R $4.87 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

OL146CK

Lifters

TIMING KIT

C6090AS $176.38 Engine Pro Timing Components (96)
--- OR ---
C6090S $189.02 Engine Pro Timing Components (97/01)

Specialty KITS

OL146RRP $497.56

RE-RING KIT + MAIN BEARINGS

OL146RMK $100.00

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	01941 $7.68 E-Loy Engine Parts (x8) (1.396 x 4.207 x .2333 -1 grv) S3444 $7.87 Engine Pro Valves (x8) (1.400 head)
Exhaust Valves	01937 $11.26 E-Loy Engine Parts (x8) (1.141 x 4.238 x .2328 -1 grv) A3441 $11.64 Engine Pro Valves (x8) (1.140 head)
Valve Springs	160-1338 $5.96 E-Loy Engine Parts (x16)
Spring Shims	-
Valve Guides	140-8670 $2.21 E-Loy Engine Parts (x8) (Intake) 140-8671 $2.21 E-Loy Engine Parts (x8) (Exhaust)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	BP-563 $46.57 TIMING SET Chain Secondary (x4) (650 gm wt) BP-564 $54.44 TIMING SET Chain Secondary (x4) (615 gm wt)
Cylinder Sleeves	-

Note 1: Opt. HA-2M5107 $101.65 Hastings, E944K $190.72 Sealed Power
Note 2: Opt 1999 $14.47 w/EGR use FELP-HS9059PT $324.25 FelPro;
Not incl. Head Bolts use 38-332 $25.36 Engine Pro

2.4L/145 cu. in. 2013-2017

CH145MK $1,438.76
Master
Kit

CH145EK $968.15
Engine
Kit

CH145RR $430.65
Re-Ring
Kit

Rings	HA-2C4564 $52.41 Hastings Rings
Rod Bearings	CLE-CB1827A $9.06 (x4) Clevite Engine Parts (.002 Use CB1828A)
Gasket Set	FELP-HS26517PT $302.02 Fel Pro & FELP-CS26223-1 $103.14 FEL PRO GASKETS

Pistons	SILV-3537HCA $55.41 (x4) Silvolite Pistons (13/17)
Main Bearings	CLE-MS2232A $114.27 Clevite Engine Parts (13/17)
Cam Bearings
Oil Pump	M349 $224.13 Melling Automotive
Freeze Plugs
Pin Bushings	-

CAM KIT

Camshaft

CH145CK

Lifters

VL175 $15.76 SB International (x16) (13/17)

TIMING KIT

C6209S $171.48 Engine Pro Timing Components (13/17 Partial kit)
C6093SS $104.88 Engine Pro Timing Components (13/17 Balance Shaft Kit)

Specialty KITS

CH145RRP $538.82 RE-RING KIT + MAIN BEARINGS

CH145RMK $144.45

ROD BEARINGS + MAIN BEARINGS

Related Parts (each)

Intake Valves	13293 $10.97 SB International (8) (13/17 (1.382 X 4.026 - 3grv))
Exhaust Valves	02010 $11.69 SB International (8) (13/17 (1.185 X 3.975 3grv))
Valve Springs	160-1508 $6.95 SB International (16) (13/17)
Head Bolts	FELP-ES72190 $142.86 FelPro
Valve Guides	140-3029 $2.75 SB International (16) (13/17)
Push Rods	-
Rocker Arms	MR1340 $9.87 Melling Automotive (16) (13/17)
Oil Pump Screens	-
Connecting Rods	594 $68.06 Rods (x4) (13/17 Smooth Beam-Fractured Cap #8217)
Cylinder Sleeves	-

2.5L/ 151 cu. in. 77/84 Passenger &
Truck w/o Roller Cam OHV-4

PT151MK $1,259.20
Master
Kit

PT151EK $995.12
Engine
Kit

PT151RR $150.94
Re-ring
Kit

Rings	NOTE 1 HA-2M5570 $95.27 Hastings Rings (77/80 5/64 Top;Deep Oil) --- OR --- HA-2M5663 $87.39 Hastings Rings (81/92 1/16 Top;Shallow Oil)
Rod Bearings	CLE-CB610P $8.33 Clevite Engine Parts (x4)
Gasket Set	FELP-FS8530PT $101.66 FEL PRO GASKETS (77/79 exc Crossflow) --- OR --- FELP-260-1128 $76.16 Sealed Power (79/86 w/Crossflow)

Pistons	457P $58.62 Sealed Power Pistons (x4) (77/78 5/64 Top, Deep Oil) --- OR --- 465AP $25.30 Sealed Power Pistons (x4) (79/81 5/64 Top,Deep Oil,2nd Design) --- OR --- H547CP $55.46 Sealed Power Pistons (x4) (82/84 1/16 Top;Shallow Oil replace in sets)
Main Bearings	CLE-MS1733P $114.27 Clevite Engine Parts
Cam Bearings	CH16 $20.56 Durabond
Oil Pump	M62C $61.93 Melling Automotive (79/87 exc.77-78 Vin V & 78-79 Vin I)
Freeze Plugs	MPE163R $10.18 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC708 $297.09 Engine Pro Camshafts (77/78) --- OR --- MC696 $166.87 Engine Pro Camshafts (79/84)	PT151CK $198.59
Lifters	HA969 $5.76 EPW Tappets (x8) (77/78) --- OR --- HA2077 $6.69 EPW Tappets (x8) (79/84)	PT151CK $198.59

TIMING KIT

2542S $96.93 Engine Pro Timing Components

Specialty KITS

PT151RRP $259.07

RE-RING KIT + MAIN BEARINGS

PT151RMK $157.19

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-21290 $486.70 (77/78 Specify Frg #)
CS-21430 $498.02 (79/86 Specify Frg #)

Related Parts

Intake Valves	V2204 $15.73 Sealed Power (x4) (80/86 1.720 x 4.669 x .342 -2rv) 01813 $7.93 E-Loy Engine Parts (x4) (78/86 exc 78-79 Vin 'V','1','9' 1.72 x 4.649 x .3421 -2g)
Exhaust Valves	V2203 $20.45 Sealed Power (x4) (80/86 1.500 x 4.619 x .341 -2 grv) 01814 $14.20 E-Loy Engine Parts (x4) (78/86 exc 78-79 Vin 'V','1','9' 1.50 x 4.60 x .3415 -2gr)
Valve Springs	RV685X $6.49 Engine Pro Valve Train Comp (x8) VS521 $5.17 Sealed Power (x8)
Spring Shims	-
Valve Guides	VG9946 $1.13 EPWI P/L Valve Train Component (x8)
Push Rods	PR317 $1.99 EPWI P/L Valve Train Component (x8) (77/79 incl 79 Calif) EL-PR317 $4.17 Elgin Industries (x8) (77/79 incl 79 Calif) PR338 $1.81 EPWI P/L Valve Train Component (x8) (79/81 exc 79 Calif) PR347 $1.81 EPWI P/L Valve Train Component (x8) (82/84) EL-PR347 $7.08 Elgin Industries (x8) (82/84)
Rocker Arms	RK546 $10.62 EPWI P/L Valve Train Component (x8) (77/80 1st Design) EL-RK546 $17.25 Elgin Industries (x8) (77/80 1st Design) RK409 $7.82 EPWI P/L Valve Train Component (x8) (80/88 2nd Design) EL-RK409 $15.69 Elgin Industries (x8) (80/88 2nd Design) R894 $12.72 Sealed Power (x8)
Oil Pump Screens	62CS1 $25.25 Melling Automotive (77-87 Car,85-93 Truck,EXC.U Code & Super Duty)
Connecting Rods	BP-521 $60.18 (x4)
Cylinder Sleeves	CSL159 $18.92 Melling Automotive (x4) (5-1/2 sleeve) CSL1104N $45.87 Melling Automotive (x4) (Notched)
Balancer Sleeve	HB4121 $5.35 Pioneer Products (Balancer) MS339 $905.09 Micro Sleeve Company, Inc. (79/97 R. Crank) MS339G $11.34 Micro Sleeve Company, Inc. (79/97 For 020 Grind R. Crank)

Note 1: Opt. (77-80 5/64 Top;Deep Oil) 41240Cp $68.16 PC, E381K $71.39 Sealed Power; (80-81 5/64 Top;
Shallow Oil) 41510CP $106.43 PC, E383K $57.52 Sealed Power; (81-84 1/16 Top; Shallow Oil) 41559CP $77.77 PC, E384K $57.05 Sealed Power

2.5L/151 cu. in. 85/91 Pass & Truck
Vin'2',' R', & 'U' w/Roller Cam OHV-4

PT151LMK $642.15
Master
Kit

PT151LEK $440.21
Engine
Kit

PT151LRR $128.62
Re-ring
Kit

Rings	NOTE 1 HA-2M5663 $87.39 Hastings Rings
Rod Bearings	CLE-CB610P $8.33 Clevite Engine Parts (x4)
Gasket Set	NOTE 2 FELP-260-1178 $76.19 Sealed Power (85/86 Vin 'R') --- OR --- FELP-260-1179 $61.95 Sealed Power (85/86 Vin 'U') --- OR --- FELP-260-1228 $71.36 Sealed Power (87 Vin 'E', 'R') --- OR --- FELP-260-1229 $76.10 Sealed Power (87 Vin 'U') --- OR --- FELP-260-1482 $100.09 Sealed Power (88/91 Vin 'E') --- OR --- FELP-260-1464 $79.33 Sealed Power (88/89 Vin 'R') --- OR --- FELP-260-1462 $77.74 Sealed Power (88 Vin 'U') --- OR --- FELP-260-1563 $85.76 Sealed Power (90/91 Vin 'R') --- OR --- FELP-260-1463 $92.03 Sealed Power (89/91 Vin 'U')

Pistons	H547CP $55.46 Sealed Power Pistons (x4) (replaces H547P)
Main Bearings	CLE-MS1733P $114.27 Clevite Engine Parts (Except Vin 'U') --- OR --- CLE-MS1643P $92.06 Clevite Engine Parts (Vin 'U')
Cam Bearings	CH16 $20.56 Durabond (Except Vin 'U') --- OR --- CH20 $23.64 Durabond (Vin 'U')
Oil Pump	M62C $61.93 Melling Automotive
Freeze Plugs	MPE163R $10.18 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	NOTE 3 MC1023 $189.05 Engine Pro Camshafts (85/89 Vin 'R') --- OR --- MC1028 $55.52 Engine Pro Camshafts (85/88 Vin 'U')	PT151LCK $147.71
Lifters	HA2148 $15.69 EPW Tappets (x8)	PT151LCK $147.71

TIMING KIT

2542S $96.93 Engine Pro Timing Components (77/90 Vin 'R')
--- OR ---
3112 $61.84 Engine Pro Timing Components (91/92 Vin 'R')
--- OR ---
2544S $39.64 Engine Pro Timing Components (85/89 Vin 'U')
--- OR ---
3066 $68.20 Engine Pro Timing Components (90/91 Vin 'U')

Specialty KITS

PT151LRRP $219.28

RE-RING KIT + MAIN BEARINGS

PT151LRMK $108.01

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-21400 $470.46 (85/86 check kit notes)
CS-21410 $475.46 (87 check kit notes)
CS-21430 $498.02 (check kit notes)

Related Parts

Intake Valves	01551 $9.81 E-Loy Engine Parts (x4) (87/88 1.720 x 4.394 x .3135 -1 grv) 01592 $9.81 E-Loy Engine Parts (x4) (89/91 1.720 x 4.591 x .3135 -1 grv) V2530 $18.98 Sealed Power (x4) (89/92 1.720 x 4.591 x .3135 -1 grv) V3941 $15.82 Sealed Power (x4) (87/88 1.720 x 4.394 x .3135 -1 grv) V2204 $15.73 Sealed Power (x4) (80/86 1.720 x 4.669 x .342 -2 grv) 01813 $7.93 E-Loy Engine Parts (x4) (85/86 1.720 x 4.649 x .3421 -2 grv)
Exhaust Valves	01550 $8.94 E-Loy Engine Parts (x4) (87/88 1.500 x 4.335 x .3182 -1 grv) 01814 $14.20 E-Loy Engine Parts (x4) (85/86 1.500 x 4.600 x .3415 -2 grv) V2529 $20.45 Sealed Power (x4) (89/92 1.500 x 4.541 x .3133 -1 grv) V2436 $15.84 Sealed Power (x4) (87/88 1.500 x 4.355 x .3122 -1 grv) V2203 $20.45 Sealed Power (x4) (80/86 1.500 x 4.619 x .341 -2 grv) 01591 $10.81 E-Loy Engine Parts (x4) (89/91 1.500 x 4.541 x .3133 -1 grv) A2397 $10.78 Engine Pro Valves (x4) (89/91 1.500 x 4.541 x .31315 1 grv)
Valve Springs	RV685X $6.49 Engine Pro Valve Train Comp (x8) (77/86 exc 86 Vin 'R') RV1300X $11.01 Pioneer Products (x8) (86 Vin 'R') RV1301X $7.27 Pioneer Products (x8) (89/90) VS521 $5.17 Sealed Power (x8) (85) VS861 $11.34 Sealed Power (x8) (87/88) VS922 $14.21 Sealed Power (x8) (89/90) VS925 $12.66 Sealed Power (x8) (91/92)
Spring Shims	-
Valve Guides	140-8040 $2.75 E-Loy Engine Parts (x8) (89/91) VG9607 $1.08 EPWI P/L Valve Train Component (x8) (77/88)
Push Rods	PR282 $1.53 EPWI P/L Valve Train Component (x8) (85/86) EL-PR282 $4.91 Elgin Industries (x8) (85/86) PR372 $1.81 EPWI P/L Valve Train Component (x8) (87/92) EL-PR372 $4.56 Elgin Industries (x8) (87/91)
Rocker Arms	RK409 $7.82 EPWI P/L Valve Train Component (x8) (80/88) EL-RK409 $15.69 Elgin Industries (x8) (80/88) R894 $12.72 Sealed Power (x8)
Oil Pump Screens	62CS1 $25.25 Melling Automotive (77-87 Car,85-93 Truck,All exc Vin U & Super Duty)
Connecting Rods	BP-521 $60.18 (x4) (77/86 Frg# 324) BP-544 $60.18 (x4) (87/93 Frg# 987)
Cylinder Sleeves	CSL159 $18.92 Melling Automotive (x4) (5-1/2 sleeve) CSL1104N $45.87 Melling Automotive (x4) (Notched)
Balancer Sleeve Harmonic Balancer	HB4121 $5.35 Pioneer Products (77/88 Balancer) MS339 $905.09 Micro Sleeve Company, Inc. (R. Crank) MS339G $11.34 Micro Sleeve Company, Inc. (For 020 Grind R. Crank) PB1441N $173.20 Engine Pro Harmonic Balancers (87/91 Vin "R")

Note 1: Opt. 41559CP $77.77 PC, E384K $57.05 Sealed Power
Note 2: (85/86) (R) FELP-260-1178 $76.19 ; (U) FELP-260-1179 $61.95 ; (87) (E,R) FELP-260-2228 ; (U) FELP-260-1229 $76.10 ; (88/91) (E) FELP-260-1482 $100.09 ; (88/89) (R) FELP-260-1464 $79.33 ; (88) (U) FELP-260-1462 $77.74 ; (90/91) (R) FELP-260-1563 $85.76 ; (89/91) (U) FELP-260-1463 $92.03 Sealed Power

Note 3: (90-91) Not available

2.5L/153 cu. in. 62/70
OHV-4 car. & Truck

CH153MK $1,136.69
Master
Kit

CH153EK $640.72
Engine
Kit

CH153RR $203.38
Re-ring
Kit

Rings	NOTE 1 HA-665 $36.40 Hastings Rings
Rod Bearings	CLE-CB745P $10.75 Clevite Engine Parts (x4)
Gasket Set	FELP-260-1230 $69.83 Sealed Power (62/67) --- OR --- FELP-260-1231 $66.78 Sealed Power (68/70)

Pistons	1108NP $28.54 Sealed Power Pistons (x4)
Main Bearings	CLE-MS1733P $114.27 Clevite Engine Parts
Cam Bearings	CH6 $31.70 Durabond
Oil Pump	M62 $57.10 Melling Automotive
Freeze Plugs	MPE104R $6.46 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC708 $297.09 Engine Pro Camshafts (w/Hydraulic Lifters)	CH153CK $328.89
Lifters	HA817 $4.91 EPW Tappets (x8)	CH153CK $328.89

TIMING KIT

2523S $95.23 Engine Pro Timing Components (62/64)
--- OR ---
2525S $96.80 Engine Pro Timing Components (65/70)

Specialty KITS

CH153RRP $316.31

RE-RING KIT + MAIN BEARINGS

CH153RMK $155.74

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	S1078 $5.66 Engine Pro Valves (x4) (1.720" x 4.9175 x .34185 -2 Grooves -45 Degree..)
Exhaust Valves	A1077 $5.74 Engine Pro Valves (x4) (1.500" x 4.923 x .3405/.34135 -2 Groove -45 Degree)
Valve Springs	RV685X $6.49 Engine Pro Valve Train Comp (x8)
Spring Shims	-
Valve Guides	VG9946 $1.13 EPWI P/L Valve Train Component (x4) (Int) VG9459 $1.08 EPWI P/L Valve Train Component (x4) (Exh) 7-15006 $2.35 EPWI P/L Valve Train Component (Bronze Exhaust)
Push Rods	PR317 $1.99 EPWI P/L Valve Train Component (x8) EL-PR317 $4.17 Elgin Industries (x8)
Rocker Arms	RK402 $7.03 EPWI P/L Valve Train Component (x8) EL-RK402 $11.80 Elgin Industries (x8)
Oil Pump Screens	-
Connecting Rods	BP-219 $50.62 (x4)
Cylinder Sleeves	CSL181 $33.33 Melling Automotive (x4)
Balancer Sleeve	HB4121 $5.35 Pioneer Products (Balancer)

Note 1: Opt. HA-2C665 $77.80 Hastings, 50452CP $29.99 or 40452CP $61.99 PC, E450X $90.39 or E450K $84.11 Sealed Power

2.5L/153 cu. in. 62/70 OHV-4 Marine

Marine

CH153MK.M $813.71
Master
Kit

Marine

CH153EK.M $500.73
Engine
Kit

Marine

CH153RR.M $243.09
Re-ring
Kit

Rings

NOTE 1
HA-665 $36.40 Hastings Rings

Rod
Bearings

CLE-CB745P $10.75 Clevite Engine Parts (x4)

Gasket Set

FELP-17200 $88.88 FelPro Marine head gasket set (does not include int. or exh. gaskets)

Bottom end gasket sets:
FELP-17100 $55.44 Std. rotation; w/Two-piece rear main bearing seal & Four-piece oil pan gskt. FelPro
OR
17101 $70.82 Std. rotation; w/Two-piece rear main bearing seal & One-piece oil pan gskt.; PermaDry® molded rubber oil pan gskt. incl.

1 Int. & Exh. Gasket Set 17302 $33.18 Cobra drive unit
OR
1 Int. & Exh. Gasket Set 17300 $34.76 Exc. Cobra drive unit
OR
1 Exh. Manifold Cooling Set 17506 $26.92 w/Round exhaust elbow; Engs. to 12/31/81
OR
1 Exh. Manifold Cooling Set 17505 $25.31 w/Square exhaust elbow; Engs. from 01/01/82

Pistons	1108NP $28.54 Sealed Power Pistons (x4)
Main Bearings	CLE-MS1733P $114.27 Clevite Engine Parts
Cam Bearings	CH6 $31.70 Durabond
Oil Pump	M62 $57.10 Melling Automotive
Freeze Plugs	MPE104BR $12.70 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC708 $297.09 Engine Pro Camshafts (w/Hydraulic Lifters)	CH153CK $328.89
Lifters	HA817 $4.91 EPW Tappets (x8)	CH153CK $328.89

TIMING KIT

2523S $95.23 Engine Pro Timing Components (62/64)
--- OR ---
2525S $96.80 Engine Pro Timing Components (65/70)

Specialty KITS

Marine
CH153RRP.M $305.30

RE-RING KIT + MAIN BEARINGS

CH153RMK $155.74

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	S1078 $5.66 Engine Pro Valves (x4) (1.720" x 4.9175 x .34185 -2 Grooves -45 Degree..)
Exhaust Valves	A1077 $5.74 Engine Pro Valves (x4) (1.500" x 4.923 x .3405/.34135 -2 Groove -45 Degree)
Valve Springs	RV685X $6.49 Engine Pro Valve Train Comp (x8)
Spring Shims	-
Valve Guides	VG9946 $1.13 EPWI P/L Valve Train Component (x4) (Int) VG9459 $1.08 EPWI P/L Valve Train Component (x4) (Exh) 7-15006 $2.35 EPWI P/L Valve Train Component (Bronze Exhaust)
Push Rods	PR317 $1.99 EPWI P/L Valve Train Component (x8) EL-PR317 $4.17 Elgin Industries (x8)
Rocker Arms	RK402 $7.03 EPWI P/L Valve Train Component (x8) EL-RK402 $11.80 Elgin Industries (x8)
Oil Pump Screens	-
Connecting Rods	BP-219 $50.62 (x4)
Cylinder Sleeves	CSL181 $33.33 Melling Automotive (x4)
Balancer Sleeve	HB4121 $5.35 Pioneer Products (Balancer)

Note 1: Opt. HA-2C665 $77.80 Hastings, 50452CP $29.99 or 40452CP $61.99 PC, E450X $90.39 or E450K $84.11 Sealed Power

2.8L/169 cu. in. 2004/06
LK5 Canyon, Colorado L-4

CH169TMK $1,314.69
Master
Kit

CH169TEK $1,014.20
Engine
Kit

CH169TRR $378.23
Re-ring
Kit

Rings	HA-2C5137 $106.31 Hastings Rings
Rod Bearings	CLE-CB1882A $9.60 Clevite Engine Parts (x4)
Gasket Set	FELP-HS26335PT $206.54 FEL PRO GASKETS FELP-CS26335 $87.37 FEL PRO GASKETS

Pistons	SILV-3511HC $71.39 (x5) Silvolite Pistons
Main Bearings	CLE-MS2249A $168.48 Clevite Engine Parts
Cam Bearings	CHG23 $41.34 Durabond
Oil Pump	K322 $169.99 Melling Automotive
Freeze Plugs	-
Pin Bushings	-

CAM KIT

Camshaft

CH169TCK

Lifters

TIMING KIT

C6191S $209.80 Engine Pro Timing Components
C6206S $107.95 Engine Pro Timing Components (Bal shaft kit)

Specialty KITS

CH169TRRP $538.85

RE-RING KIT + MAIN BEARINGS

CH169TRMK $198.58

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-11540 $685.98 (Vortec DOHC 16V, 12582403, 588)

Related Parts

Intake Valves	S4800 $10.57 Engine Pro Valves (x8) (1.457 x 4.149 x .2346 -3 grv) 01998 $11.72 E-Loy Engine Parts (x8) (1.457 x 4.149 x .2346 -3 grv)
Exhaust Valves	A4801 $14.23 Engine Pro Valves (x8) (1.201 x 4.246 x .2339 -3 grv) 01999 $15.76 E-Loy Engine Parts (x8) (1.201 x 4.246 x .2339 -3 grv)
Valve Springs	160-1480 $6.58 E-Loy Engine Parts (x16)
Spring Shims	-
Valve Guides	140-8556 $3.28 E-Loy Engine Parts (x16) (Int & Exh)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	BP-572 $68.06
Cylinder Sleeves	CSL174 $28.49 Melling Automotive
Balancer Sleeve	-

2.8L/173 cu. in. 80/84 V-6

CH173MK $610.51
Master
Kit

CH173EK $452.99
Engine
Kit

CH173RR $142.97
Re-ring
Kit

Rings	NOTE 1 HA-5632 $47.51 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	FELP-260-1123 $93.64 Sealed Power

Pistons	464P $22.15 Sealed Power Pistons (x6) (8.5 Cr)
Main Bearings	CLE-MS1494P $60.28 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M95B $68.15 Melling Automotive
Freeze Plugs	MPE165R $6.77 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC715 $60.26 Engine Pro Camshafts (w/2-BBL. carb.) --- OR --- MC1000 $133.42 Engine Pro Camshafts (81/89 w/FI Or HD)	CH173CK $119.11
Lifters	HA2095 $5.90 EPW Tappets (x12)	CH173CK $119.11

TIMING KIT

3175 $28.48 Engine Pro Timing Components

Specialty KITS

CH173RRP $181.12

RE-RING KIT + MAIN BEARINGS

CH173RMK $60.31

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	01395 $8.89 E-Loy Engine Parts (x6) (Vin 'X','7','1' 1.600 x 4.700 x .3413 -2 grv) 01481 $14.25 E-Loy Engine Parts (x6) (81/91 Vin 'Z','S','L','9','W' 1.718 x 4.705 x.3413 2 grv) S2138 $14.14 Engine Pro Valves (x6) (81/91 Vin 'Z','S','L','9','W' 1.718 x 4.705 x.3413 2 grv)
Exhaust Valves	01394 $9.11 E-Loy Engine Parts (x6) (Vin 'X','7','1' 1.307 x 4.730 x .3413 -2 grv) 01480 $15.66 E-Loy Engine Parts (x6) (81/91 Vin 'Z','L','S','9','W' 1.425 x 4.736 x .3413 -2gr)
Valve Springs	RV1038X $7.08 Engine Pro Valve Train Comp (x12) (80) RV1190X $1.11 Engine Pro Valve Train Comp (x12) (81/93 exc Vin 'W')
Spring Shims	-
Valve Guides	140-9560 $1.96 E-Loy Engine Parts (x12)
Push Rods	PR342 $1.81 EPWI P/L Valve Train Component (x12) EL-PR342 $4.17 Elgin Industries (x12)
Rocker Arms	RK407 $4.60 EPWI P/L Valve Train Component (x12) EL-RK407 $9.38 Elgin Industries (x12)
Oil Pump Screens	95S3 $14.26 Melling Automotive (81/86 HI VOL) 95S4 $15.68 Melling Automotive (80 VIN 7,82-84 VIN 1,82 VIN X,82-90 2WD TrK.EXC HV)
Connecting Rods	BP-529 $42.74 (x6)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x4)
Balancer Sleeve Harmonic Balancer Harmonic Balancer	HB4127 $5.54 Pioneer Products (Balancer) PB1442N $128.65 Engine Pro Harmonic Balancers (83/84 VIN "X") PB1444N $66.68 Engine Pro Harmonic Balancers (82/84 VIN "I" "S" "B" "R")

Note 1: Opt. (1.5mm top/std oil) HA-2M5632 $108.01 Hastings, 51284Cp $63.36 or 41284CP $74.62 PC, E411X $41.28 or E411K $61.79 Sealed Power; (1.5mm top/shallow oil) HA-2M6194 $104.78 Hastings, 51474CP $60.20 or 41474CP PC, E432X $63.54 or E432K $98.39 Sealed Power; (2.0mm top) HA-2M582 $112.78 Hastings, E398X $43.23 or E398K $57.65 Sealed Power

2.8L/173 cu. in. 85/86 V-6

CH173LMK $610.50
Master
Kit

CH173LEK $454.53
Engine
Kit

CH173LRR $141.41
Re-ring
Kit

Rings	NOTE 1 HA-5632 $47.51 Hastings Rings (Use w/464P) --- OR --- HA-6194 $71.33 Hastings Rings (Use w/516P)
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1123 $93.64 Sealed Power (85 Trk w/5.5mm Thk R.Seal) --- OR --- FELP-260-1143 $115.85 Sealed Power (85 Trk w/11MM R.Seal & Pass w/2bl) --- OR --- FELP-260-1144 $107.95 Sealed Power (86 Trk & 85-86 Pass w/FI exc Fiero)

Pistons	464P $22.15 Sealed Power Pistons (x6) (w/o FI-Comp Ht = 1.583) --- OR --- 516P $26.87 Sealed Power Pistons (x6) (w/FI-Comp Ht = 1.598)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M95B $68.15 Melling Automotive
Freeze Plugs	MPE165R $6.77 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC715 $60.26 Engine Pro Camshafts (w/2 Bbl carb) --- OR --- MC1000 $133.42 Engine Pro Camshafts (w/FI Or HD)	CH173LCK $119.11
Lifters	HA2095 $5.90 EPW Tappets (x12)	CH173LCK $119.11

TIMING KIT

3175 $28.48 Engine Pro Timing Components
--- OR ---
3048 $28.48 Engine Pro Timing Components (Vin 'W' Cavalier Or Cadet)

Specialty KITS

CH173LRRP $184.34

RE-RING KIT + MAIN BEARINGS

CH173LRMK $65.13

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	S2138 $14.14 Engine Pro Valves (x6) (Vin 'Z','S','L','9','W' 1.718 x 4.705 x.3413 2grv) 01481 $14.25 E-Loy Engine Parts (x6) (Vin 'X','7','1' 1.718 x 4.705 x .3412 -2 grv) 01395 $8.89 E-Loy Engine Parts (x6) (Vin 'Z','S','L','9','W' 1.60 x 4.70 x .3413 -2 grv)
Exhaust Valves	01394 $9.11 E-Loy Engine Parts (x6) (Vin 'X','7','1' 1.307 x 4.730 x .3413 -2 grv)
Valve Springs	RV1190X $1.11 Engine Pro Valve Train Comp (x12) (exc Vin 'W')
Spring Shims	-
Valve Guides	140-9560 $1.96 E-Loy Engine Parts (x12)
Push Rods	PR342 $1.81 EPWI P/L Valve Train Component (x12) EL-PR342 $4.17 Elgin Industries (x12)
Rocker Arms	RK407 $4.60 EPWI P/L Valve Train Component (x12) EL-RK407 $9.38 Elgin Industries (x12)
Oil Pump Screens	95S3 $14.26 Melling Automotive (Car HI-VOL) 95S4 $15.68 Melling Automotive (2WD Truck With 5/8"PU Tube)
Connecting Rods	BP-529 $42.74 Tensioner Arm TENSIONER (x6) (80/85) BP-543 $44.66 (x6) (86/90)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x6)
Balancer Sleeve Harmonic Balancer Harmonic Balancer	HB4127 $5.54 Pioneer Products (Balancer) PB1442N $128.65 Engine Pro Harmonic Balancers (VIN "X") PB1444N $66.68 Engine Pro Harmonic Balancers (VIN "I" "S" "B" "R")

Note 1: Opt.(std oil) HA-2M5632 $108.01 Hastings, 51284CP $63.36 or 41284CP $74.62 PC, E411X $41.28 or E411K $61.79 Sealed Power; (shallow oil) HA-2M6194 $104.78 Hastings, 51474CP $60.20 or 41474CP PC, E432X $63.54 or E432K $98.39 Sealed Power
Note 2: Not Incl. exh. packing For Fiero use vin 9 gaskets FELP-HS8699PT5 $203.44 & FELP-CS8699-1 $36.47

2.8L/173 cu. in. 87/93 V-6 (exc. Vin 'W' MFI),

VIN 9 Fiero
+$40.24

CH173LLMK $831.49
Master
Kit

CH173LLEK $529.41
Engine
Kit

CH173LLRR $217.61
Re-ring
Kit

Rings	NOTE 1 HA-6194 $71.33 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1232 $157.27 Sealed Power (Camaro, Firebird, Fiero & Trk) --- OR --- FELP-260-1233 $155.61 Sealed Power (All exc Camaro, Firebird, Fiero & Truck)

Pistons	516P $26.87 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M95B $68.15 Melling Automotive
Freeze Plugs	MPE165R $6.77 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC1000 $133.42 Engine Pro Camshafts	CH173LLCK $263.88
Lifters	HA2095 $5.90 EPW Tappets (x12)	CH173LLCK $263.88

TIMING KIT

3175 $28.48 Engine Pro Timing Components

Specialty KITS

CH173LLRRP $260.60

RE-RING KIT + MAIN BEARINGS

CH173LLRMK $65.13

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS
Matching bearings included

CS-10540 $490.19 (85/87)
CS-10550 $430.19 (w/Dir. Mag. Ignition)
CS-10650 $493.19 (88/93 w/Distributor Ignition)

Related Parts

Intake Valves	S2138 $14.14 Engine Pro Valves (x6) (81/91 1.718 x 4.705 x.3413 2grv)
Exhaust Valves	-
Valve Springs	RV1190X $1.11 Engine Pro Valve Train Comp (x12)
Spring Shims	-
Valve Guides	140-9560 $1.96 E-Loy Engine Parts (x12) (87/88 W/Iron Head) VG8112 $1.73 EPWI P/L Valve Train Component (x12) (87/88 W/Alum Head)
Push Rods	PR342 $1.81 EPWI P/L Valve Train Component (x12) (80/88) EL-PR342 $4.17 Elgin Industries (x12) (80/88)
Rocker Arms	RK407 $4.60 EPWI P/L Valve Train Component (x12) EL-RK407 $9.38 Elgin Industries (x12) (80/89)
Oil Pump Screens	95S4 $15.68 Melling Automotive (82/90 85-89 car. VIN S,82-90 2WD Truck With 5/8"PU TUBE) 95S5 $17.25 Melling Automotive (82/89 4WD Truck With 5/8"PU Tube)
Connecting Rods	BP-543 $44.66 (x6) (86/90)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x6) (87/88)
Balancer Sleeve Harmonic Balancer Harmonic Balancer	HB4127 $5.54 Pioneer Products (80/92 Balancer) PB1443N $84.14 Engine Pro Harmonic Balancers (87/88 VIN "W") PB1444N $66.68 Engine Pro Harmonic Balancers (87/88 VIN "I" "S" "B" "R")

Note 1: Opt. HA-2M6194 $104.78 Hastings, 51474CP $60.20 or 41474CP PC, E432X $63.54 or E432K $98.39 Sealed Power
Note 2: Not Incl. Man. Gaskets in FELP-260-1233 $155.61 use (Intake) MS96041 $52.23 & (Exhaust-Beretta, Cavalier, Corsica, Firenza) MS93575 $22.20 or (Exhaust-all others) MS93692 $23.85 FelPro Fiero vin 9 use FELP-HS8699PT5 $203.44 & FELP-CS8699-1 $36.47

2.8L/173 cu. in. 87/89 V-6 (Vin 'W' w/MFI)

CH173LWMK $828.33
Master
Kit

CH173LWEK $521.46
Engine
Kit

CH173LWRR $236.81
Re-ring
Kit

Rings	NOTE 1 HA-2M4456 $95.29 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1232 $157.27 Sealed Power (Camaro, Firebird, Truck) --- OR --- FELP-260-1233 $155.61 Sealed Power (exc Camaro, Firebird, & Truck)

Pistons	531P $23.69 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M95B $68.15 Melling Automotive
Freeze Plugs	MPE165R $6.77 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC1000 $133.42 Engine Pro Camshafts	CH173LWCK $263.88
Lifters	HA2095 $5.90 EPW Tappets (x12)	CH173LWCK $263.88

TIMING KIT

3048 $28.48 Engine Pro Timing Components

Specialty KITS

CH173LWRRP $279.74

RE-RING KIT + MAIN BEARINGS

CH173LWRMK $65.13

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS
Matching bearings included

CS-10540 $490.19 (85/87)
CS-10550 $430.19 (w/Dir. Mag. Ignition)
CS-10650 $493.19 (88/93 w/Distributor Ignition)

Related Parts

Intake Valves	S2138 $14.14 Engine Pro Valves (x6) (1.718 x 4.705 x.3413 2grv) S2140 $8.46 Engine Pro Valves (x6) (w/Aluminum Heads 1.718 x 4.7050 x 0.31395 1 grv)
Exhaust Valves	A2143 $11.67 Engine Pro Valves (x6) (w/Aluminum Heads 1.425" x 4.737 x .3136 1Grv. SS)
Valve Springs	RV1268 $5.22 Pioneer Products (x12)
Spring Shims	-
Valve Guides	140-9560 $1.96 E-Loy Engine Parts (x12) (W/Iron Head) VG8112 $1.73 EPWI P/L Valve Train Component (x12) (W/Alum Head)
Push Rods	PR375 $1.86 EPWI P/L Valve Train Component (x6) (Intake) PR376 $1.86 EPWI P/L Valve Train Component (x6) (Exhaust) EL-PR375 $4.39 Elgin Industries (x6) (Intake) EL-PR376 $4.36 Elgin Industries (x6) (Exhaust)
Rocker Arms	RK407 $4.60 EPWI P/L Valve Train Component (x12) EL-RK407 $9.38 Elgin Industries (x12)
Oil Pump Screens	95S3 $14.26 Melling Automotive (Car HI-VOL) 95S6 $14.17 Melling Automotive (Car EXC.HI-VOL)
Connecting Rods	BP-543 $44.66 (x6)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x6)
Balancer Sleeve Harmonic Balancer	HB4127 $5.54 Pioneer Products (Balancer) PB1443N $84.14 Engine Pro Harmonic Balancers

Note 1: Opt. HA-4456 $93.60 Hastings, 41473CP $57.18 PC, E478X $63.52 or E478K $74.57 Sealed Power
Note 2: Not Incl. Man.Gaskets in FELP-260-1233 $155.61 use (Intake) MS96041 $52.23 & (Exhaust-Beretta,Cavalier,Corsica,Firenza) MS93575 $22.20 or (Exhaust-all others) MS93692 $23.85

2.9L/178 cu. in. 2007-12 4Cyl DOHC
Vin 9 Colorado Canyon

CH178MK $1,554.92
Master Kit

CH178EK $1,273.40
Engine Kit

CH178RR $435.58
Re-ring Kit

Rings	Included w/pistons HA-2C5236 $115.93 Hastings Rings (07/11)
Rod Bearings	CLE-CB1882A $9.60 Clevite Engine Parts (x4) (Use CLE-CB1883A for .002 OD.)
Gasket Set	FELP-HS26389PT $367.18 FEL PRO GASKETS FELP-CS26335 $87.37 FEL PRO GASKETS

Pistons	224-3945WR $115.94 Mahle Pistons (x4) (Pistons W/Rings)
Main Bearings	CLE-MS2249A $168.48 Clevite Engine Parts
Cam Bearings	CLE-SH2000S $53.89 Clevite Engine Parts (Balance Shaft Brg Set.)
Oil Pump	K322 $169.99 Melling Automotive (Oil Pump Kit)
Freeze Plugs	.
Pin Bushings	.

CAM
KIT

Camshaft	.	CH178CK
Lifters	.	.

TIMING KIT

C6190SM $354.38 Engine Pro Timing Components (No VVT sprocket.)

Specialty
KITS

CH178RRP $596.06 07-11

RE-RING KIT + MAIN BEARINGS

CH178RMK $198.58

ROD BEARINGS + MAIN BEARINGS

CRANK KIT

Not available

Related Parts

Intake Valves	S4802 $11.19 Engine Pro Valves (x8) (1.525 x 4.165 - 3grv)
Exhaust Valves	A4803 $14.10 Engine Pro Valves (x8) (1.323 x 4.252 - 3grv)
Valve Springs	160-1579 $7.73 SB International (x16)
Spring Shims	.
Valve Guides	140-8556 $3.28 SB International (x16)
Push Rods	.
Rocker Arms	MR1323 $6.74 Melling Automotive (x16)
Oil Pump Screens	.
Connecting Rods	582 $69.97 Rods (x4) (#9040)
Cylinder Sleeves	.
Balancer Sleeve	.

3.0L/181 cu. in. 1980-92 and later 4 cyl.
Mercruiser Marine & Industrial

CH181MK $893.52
Master
Kit

CH181EK $496.02
Engine Kit

CH181RR $173.25
Re-Ring
Kit

Rings	NOTE 1 HA-5570 $37.87 SPROCKET Hastings Rings (Size:STD)
Rod Bearings	NOTE 2 CLE-CB663P $5.10 Clevite Engine Parts (x4) (Size:STD)
Gasket Set	NOTE 3 FELP-17200 $85.35 FEL PRO GASKETS 17100 $52.04 FEL PRO GASKETS (4-pc oil pan, 2-pc r.seal) --- OR --- CS5719 $86.58 Victor Gaskets (1-pc oil pan, 2-pc r.seal) --- OR --- 17102 $137.82 FEL PRO GASKETS (1-pc oil pan, 1-pc r.seal)

Pistons	Note 0 H896CP $93.59 Sealed Power Pistons (x4) (w/Dish Top) (Size:STD) --- OR --- H897CP $95.32 Sealed Power Pistons (x4) (w/Flat Top) (Size:STD)
Main Bearings	CLE-MS1733P $114.27 Clevite Engine Parts (Size:STD)
Cam Bearings	CH16 $20.56 Durabond
Oil Pump	M62 $57.10 Timing Chain Melling Automotive
Freeze Plugs	MPE104BR $12.70 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

MC708 $297.09 Engine Pro Camshafts

CH181CK $321.15

Lifters

HA817 $4.91 EPW Tappets (x8)

TIMING KIT

2528S $95.29 Engine Pro Timing Components

Specialty KITS

CH181RRP $281.37

RE-RING KIT + MAIN BEARINGS

CH181RMK $128.62

ROD BEARINGS + MAIN BEARINGS

ADDITIONAL PARTS

Related Parts

Intake Valves	S1078 $5.66 Engine Pro Valves (x4) (65/90 1.720" x 4.9175 x .34185 -2 Grooves -45 Degree..) S1476 $5.10 Engine Pro Valves (x4) (65/90 1.937" x 4.8815 x .34185 -2 Groove -45 Degree..)
Exhaust Valves	A1649 $10.45 Engine Pro Valves (x4) (65/90 1.600 x 4.901 x .3415 x 2Grv. Stainless) AX867 $18.86 Engine Pro Valves (x4) (65/90 1.500" x 4.923 x .3413/.3413 -2 Grooves -45 Degree)
Valve Springs	RV685X $6.49 Engine Pro Valve Train Comp (8) (65/90)
Spring Shims	-
Valve Guides	VG9606 $1.08 EPWI P/L Valve Train Component (x8) 7-15006 $2.35 EPWI P/L Valve Train Component (x8) (65/90 Bronze)
Push Rods	PR317 $1.99 EPWI P/L Valve Train Component (x8) (65/90) EL-PR317 $1.99 Elgin Industries (x8) (65/90)
Rocker Arms	RK402 $7.03 EPWI P/L Valve Train Component (x8) (65/90) EL-RK402 $7.03 Elgin Industries (x8) (65/90)
Oil Pump Screens	-
Connecting Rods	-
Cylinder Sleeves	CSL159 $18.92 Primary Chain Melling Automotive (x4)
Balancer Sleeve	-

Note 1: Opt. HA-2M5570 $95.27 Hastings, 51240CP $25.20 or 41240CP $68.16 PC, E381X $42.88 or E381K $71.39 Sealed Power
Note 2: Opt. Late 1 pc seal crank w/lrg radius std journals use CLE-CB663HN $14.18 Clevite
Note 3: Not Incl-Man. Gask use (to Sn# 6229717) FELP-17301 $34.81 or (after Sn# 6229718) FELP-17302 $33.22 FelPro FELP-17300 $34.81 or FELP-17304 $34.74 see pg 108 FelPro marine cat
Note 0: Opt. Flat-top use H897CP $95.32 (x4) Sealed Power or SILV-3493H $55.59 (x4) Silvolite

3.0L/182 cu. in. 2010-2012
Chevrolet Terrain, Equinox V-6 DOHC 24V VIN Y

CH182MK $2,527.97
Master
Kit

CH182EK $1,796.60
Engine Kit

CH182RR $936.35
Re-ring Kit

Rings	NOTE 1
Rod Bearings	CLE-CB1877A $7.54 Clevite Engine Parts (x6)
Gasket Set	FELlP-HS26559PT $716.92 FEL PRO GASKETS FELlP-CS26376-1 $133.34 FEL PRO GASKETS

Pistons	224-3930WR $136.68 Mahle Pistons (x6) (Pistons and Rings)
Main Bearings	CLE-MS2276A $65.06 Clevite Engine Parts
Cam Bearings	.
Oil Pump	M353 $131.78 Melling Automotive
Freeze Plugs	.
Pin Bushings	.

CAM
KIT

Camshaft	.	CH182CK
Lifters	VL175 $15.75 SB International (x24)

TIMING
KIT

C6210SS $445.18 Engine Pro Timing Components (No VVT No Sprockets)

SPECIALTY
KITS

CH182RRP $999.87

RE-RING KIT + MAIN BEARINGS

CH182RMK $106.36

ROD BEARINGS + MAIN BEARINGS

CRANK KIT

Not available

Related Parts

Intake Valves	13211 $11.85 SB International (x12) (1.384 x 3.985 - 1grv)
Exhaust Valves	13212 $15.84 SB International (x12) (1.205 x 3.748 - 1grv)
Valve Springs	160-1588 $8.32 SB International (x24)
Spring Shims	.
Valve Guides	140-3112 $2.96 SB International (x24)
Push Rods	.
Rocker Arms	180-1323 $17.27 SB International (x24)
Oil Pump Screens	.
Connecting Rods	.
Cylinder Sleeves	.
Balancer Sleeve	.

Note 1: HA-2C5225 $192.18 Hasting Ring Set

3.1L/189 cu. in. 88/94 exc Vin 'M' V-6

CH189MK $755.06
Master
Kit

CH189EK $594.58
Engine
Kit

CH189RR $287.66
Re-ring
Kit

Rings	NOTE 1 HA-2M4456 $95.29 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1233 $155.61 Sealed Power (88/90 Vin 'T' exc 90 Camaro & Firebird) --- OR --- FELP-260-1466 $131.86 Sealed Power (90/92 Vin 'T' Camaro & Firebird) --- OR --- FELP-260-1564 $179.43 Sealed Power (91/94 Vin 'T','W' exc Camaro & Firebird)

Pistons	H561CP $31.61 Sealed Power Pistons (x6) (w/Aluminum Heads) --- OR --- H562CP $31.69 Sealed Power Pistons (x6) (88/93 w/Cast Iron Heads)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M95B $68.15 Melling Automotive (88/90 1st Design) --- OR --- M134 $95.29 Melling Automotive (90/95 2nd Design)
Freeze Plugs	MPE276R $7.71 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

MC1000 $133.42 Engine Pro Camshafts (Vin 'T', 'W')
--- OR ---
MC715 $60.26 Engine Pro Camshafts (90/94 Vin 'D')

CH189CK $112.81

Lifters

HA2095 $5.90 EPW Tappets (x12)

TIMING KIT

3048 $28.48 Engine Pro Timing Components
7131 $7.04 Engine Pro Timing Components (exc 90-92 Camaro Vin-T)

Specialty KITS

CH189RRP $329.03

RE-RING KIT + MAIN BEARINGS

CH189RMK $65.13

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-10610 $455.19 (89/00 w/Dir. Mag. Ignition)
CS-10620 $500.19 (89/00 w/Distributor Ignition)

Related Parts

Intake Valves	S2140 $8.46 Engine Pro Valves (x6) (89/91 exc Camaro,F.Bird,Silhouette,Transport,Lumina Van) S2138 $14.14 Engine Pro Valves (x6) (90/91 Camaro,F.Bird,Silhouette,Transport,Lumina Van)
Exhaust Valves	A2143 $11.67 Engine Pro Valves (x6) (89/91 exc Camaro,F.Bird,Silhouette,Transport,Lumina Van)
Valve Springs	RV1268 $5.22 Pioneer Products (x12) (89/94) 160-1076 $4.93 E-Loy Engine Parts (x12) (89/94)
Spring Shims	-
Valve Guides	140-9560 $1.96 E-Loy Engine Parts (x12) (W/Iron Head) VG8112 $1.73 EPWI P/L Valve Train Component (x12) (W/Alum Head)
Push Rods	PR375 $1.86 EPWI P/L Valve Train Component (x6) (89/94 Int) PR376 $1.86 EPWI P/L Valve Train Component (x6) (89/94 Exh)
Rocker Arms	R881 $9.59 Sealed Power (x12) RK407 $4.60 EPWI P/L Valve Train Component (x12)
Oil Pump Screens	-
Connecting Rods	BP-543 $44.66 (x6) (88/93)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x6)
Balancer Sleeve	MS228-2 $6.47 Micro Sleeve Company, Inc. (89/94 Balancer) MS337G $11.34 Micro Sleeve Company, Inc. (89/94 R. Crank)

Note 1: Opt. HA-4456 $93.60 Hastings, 41473CP $57.18 PC, E478X $63.52 or E605K $115.83 Sealed Power
Note 2: Not Incl.Man.Gask. use (Intake 88-90) MS96041 $52.23 or (91-93) MS96046 $57.16 and (Exhaust-All) MS93692 $23.85 FelPro; Head Bolts use 3FELP-8-3115 $39.67 Engine Pro

3.1L/189 cu. in. 94/99 Vin 'M' V-6

CH189MMK $1,564.40
Master
Kit

CH189MEK $971.35
Engine
Kit

CH189MRR $418.11
Re-ring
Kit

Rings	NOTE 1 HA-2M4456 $95.29 Hastings Rings (88/96 94-96) --- OR --- HA-2C4888 $60.31 Hastings Rings (97/99 97-99)
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1746 $209.67 Sealed Power (94/95 94-95 1st Design w/o Push Rod Guides On Int Gasket) --- OR --- FELP-HS54059 $209.71 Victor Gaskets (96/98 96-98 1st Design w/o Push Rod Guides On Int Gasket) AND FELP-CS9957 $61.91 FEL PRO GASKETS --- OR --- FELP-HS9957PT2 $319.51 FEL PRO GASKETS (95/99 95-99 2nd Design w/Push Rod Guides On Int Gasket) AND FELP-CS9957 $61.91 FEL PRO GASKETS

Pistons	H692CP $39.53 Sealed Power Pistons (x6) (94/96 94-96) --- OR --- H809CP $36.43 Sealed Power Pistons (x6) (97/99 97-99)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M134 $95.29 Melling Automotive
Freeze Plugs	MPE276R $7.71 Melling Automotive (94 94 Only; 95/99 = N/A)
Pin Bushings	-

CAM KIT

Camshaft	MC1569 $335.36 Engine Pro Camshafts	CH189MCK $534.07
Lifters	HA2270 $11.93 EPW Tappets (x12)	CH189MCK $534.07

TIMING KIT

3036 $63.54 Engine Pro Timing Components

Specialty KITS

CH189MRRP $418.11

RE-RING KIT + MAIN BEARINGS

CH189MRMK $65.13

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS
Matching bearings included

CS-10610 $455.19 (mag. ignition)
CS-10620 $500.19 (dist. ignition)

Related Parts

Intake Valves	01810 $14.14 E-Loy Engine Parts (x6) (1.718 X 4.713 X .3139 -1 grv) S3532 $14.15 Engine Pro Valves (x6) (1.718 x 4.705 x .31395 -1 grv)
Exhaust Valves	01811 $15.85 E-Loy Engine Parts (x6) (1.425 x 4.736 x .3132 -1 grv) A3543 $15.71 Engine Pro Valves (x6) (1.425 x 4.7360 x .31360 -1 grv)
Valve Springs	160-1363 $7.63 E-Loy Engine Parts (x12)
Spring Shims	-
Valve Guides	VG8112 $1.73 EPWI P/L Valve Train Component (x12) (94/97)
Push Rods	RP3330 $7.35 Sealed Power (x6) (94/98 Int) PR475 $2.11 EPWI P/L Valve Train Component (x6) (94/98 Int) RP3331 $7.35 Sealed Power (x6) (94/98 Exh) PR474 $2.11 EPWI P/L Valve Train Component (x6) (94/98 Exh)
Rocker Arms	-
Oil Pump Screens	251S $18.94 Melling Automotive
Connecting Rods	BP-543 $44.66 (x6) (94/96 w/574 966 996 Castings)
Cylinder Sleeves	CSL890 $33.33 Melling Automotive (x6) (94/96)
Balancer Sleeve	MS228-2 $6.47 Micro Sleeve Company, Inc. (94/96 Balancer) MS337G $11.34 Micro Sleeve Company, Inc. (94/96 R. Crank)

Note 1: Opt. (94-96) HA-4456 $93.60 Hastings, 41473CP $57.18 PC, E478X $63.52 or E605K $115.83 Sealed Power; (97-99) 41685 CP PC, E922K $79.29 Sealed Power
Note 2: Not Incl Head Bolts use 38-3131 $33.31 Engine Pro or FELP-ES74019 $37.95 FelPro

3.1L/189 cu. in. 99/05 Vin 'J' V-6

CH189LMK $1,058.86
Master
Kit

CH189LEK $794.78
Engine
Kit

CH189LRR $422.75
Re-ring
Kit

Rings	NOTE 1 HA-2M4979 $147.81 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1871 $220.85 Sealed Power (99/03)

Pistons	H882CP $39.65 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M134 $95.29 Melling Automotive
Freeze Plugs	MPE276R $7.71 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC1362 $343.38 Melling Automotive (99/02)	CH189LCK $208.08
Lifters	HA2270 $11.93 EPW Tappets (x12)	CH189LCK $208.08

TIMING KIT

3036 $63.54 Engine Pro Timing Components (99 1st design w/64L chain)
--- OR ---
3134 $131.76 Engine Pro Timing Components (2nd design w/80L chain)

Specialty KITS

CH189LRRP $464.18

RE-RING KIT + MAIN BEARINGS

CH189LRMK $65.13

ROD BEARINGS + MAIN BEARINGS

CRANKSHAFT KITS -
Matching
bearings included

CS-10610 $455.19 (99/04 w/magnetic ignition)
CS-10620 $500.19 (99/04 w/distributor ignition)

Related Parts

Intake Valves	01929 $9.40 E-Loy Engine Parts (x6) (1.760 x 4.684 x .3139 -1 grv) S3446 $9.68 Engine Pro Valves (x6) (1.760 x 4.684 x .3139 -1 grv)
Exhaust Valves	01811 $15.85 E-Loy Engine Parts (x6) (1.425 x 4.736 x .3132 -1 grv) A3543 $15.71 Engine Pro Valves (x6) (1.425 x 4.736 x .3136 -1 grv)
Valve Springs	160-1363 $7.63 E-Loy Engine Parts (x12)
Spring Shims	-
Valve Guides	VG5080 $3.66 Sealed Power (x12) (99/04 Int & Exh)
Push Rods	190-1534 $3.80 E-Loy Engine Parts (x6) (Int) PR475 $2.11 EPWI P/L Valve Train Component (x6) (Int) 190-1535 $3.80 E-Loy Engine Parts (x6) (Exh) PR474 $2.11 EPWI P/L Valve Train Component (x6) (Exh)
Rocker Arms	-
Oil Pump Screens	251S $18.94 Melling Automotive (99/04)
Connecting Rods	BP-543 $44.66 (x6) (99/04)
Cylinder Sleeves	CSL1112 $31.78 Melling Automotive (x6) (99/04)
Balancer Sleeve	-

Note 1: Opt. HA-2C4979 $149.30 Hastings, E970K $188.99 Sealed Power
Note 2: 04-05 not incl use FELP-HS9957PT3 $405.37 & FELP-CS9957 $61.91 FelPro

3.3L/200 cu. in. 78/79 V-6

CH200MK $852.14
Master
Kit

CH200EK $689.89
Engine
Kit

CH200RR $317.92
Re-ring
Kit

Rings	NOTE 1 HA-582 $84.14 Hastings Rings
Rod Bearings	CLE-CB1227P $18.95 Clevite Engine Parts (x6)
Gasket Set	FELP-HS8629PT $117.56 FEL PRO GASKETS AND FELP-CS8629 $38.10 FEL PRO GASKETS

Pistons	475NP $39.53 Sealed Power Pistons (x6)
Main Bearings	CLE-MS1454P $80.99 Clevite Engine Parts
Cam Bearings	CH17 $25.33 Durabond
Oil Pump	M55 $41.17 Melling Automotive
Freeze Plugs	MPE169R $10.89 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC710 $71.49 Engine Pro Camshafts	CH200CK $128.71
Lifters	HA817 $4.91 EPW Tappets (x12)	CH200CK $128.71

TIMING KIT

3033 $39.58 Engine Pro Timing Components

Specialty KITS

CH200RRP $395.69

RE-RING KIT + MAIN BEARINGS

CH200RMK $182.71

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	S1856 $7.97 Engine Pro Valves (x6) (1.600 x 4.8800 x 0.34130 2 grv)
Exhaust Valves	-
Valve Springs	RV880X $3.01 Engine Pro Valve Train Comp (x12)
Spring Shims	-
Valve Guides	VG9946 $1.13 EPWI P/L Valve Train Component (x6) (Int) 7-15027 $2.29 EPWI P/L Valve Train Component (Bronze Exhaust) VG9867 $1.14 EPWI P/L Valve Train Component (x6) (Exh)
Push Rods	PR34B $1.49 EPWI P/L Valve Train Component (x12) EL-PR34B $4.23 Elgin Industries (x12)
Rocker Arms	RK401 $8.06 EPWI P/L Valve Train Component (x12) EL-RK401 $9.06 Elgin Industries (x12)
Oil Pump Screens	55S1 $14.18 Melling Automotive
Connecting Rods	BP-230 $60.18 (x6)
Cylinder Sleeves	CSL109 $33.39 Melling Automotive (x6)
Balancer Sleeve Harmonic Balancer	HB4121 $5.35 Pioneer Products (Balancer) PB1208N $106.47 Engine Pro Harmonic Balancers

Note 1: Opt. HA-2M582 $112.78 Hastings, 50277 $84.08 or 40277 $74.30 PC, E197X $57.18 or E197K $84.21 Sealed Power

3.4L/207 cu. in.93/95 Vin 'S' V-6

CH207MK $1,006.34
Master
Kit

CH207EK $720.11
Engine
Kit

CH207RR $337.02
Re-ring
Kit

Rings	NOTE 1 HA-2M4649 $133.46 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-HS9105PT $122.32 FEL PRO GASKETS AND FELP-CS9471 $120.78 FEL PRO GASKETS

Pistons	H800P $82.49 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M134 $95.29 Melling Automotive
Freeze Plugs	MPE708R $6.96 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC1539 $195.49 Engine Pro Camshafts	CH207CK $249.39
Lifters	HA2095 $5.90 EPW Tappets (x12)	CH207CK $249.39

TIMING KIT

3175 $28.48 Engine Pro Timing Components

Specialty KITS

CH207RRP $381.38

RE-RING KIT + MAIN BEARINGS

CH207RMK $65.13

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	V2291 $23.64 Sealed Power (x6) (1.718 x 4.705 x .3413 -2 grv) S2138 $14.14 Engine Pro Valves (x6) (1.718 x 4.705 x .3413 -2 grv)
Exhaust Valves	V2290 $25.34 Sealed Power (x6) (1.425 x 4.736 x .3413 -2 grv)
Valve Springs	160-1046 $5.02 E-Loy Engine Parts (x12) VS798 $2.89 Sealed Power (x12) RV1190X $1.11 Engine Pro Valve Train Comp (x12)
Spring Shims	-
Valve Guides	140-9560 $1.96 E-Loy Engine Parts (x12)
Push Rods	RP3207 $3.10 Sealed Power (x12) PR342 $1.81 EPWI P/L Valve Train Component (x12)
Rocker Arms	R881 $9.59 Sealed Power (x12) RK407 $4.60 EPWI P/L Valve Train Component (x12)
Oil Pump Screens	244S $26.84 Melling Automotive
Connecting Rods	BP-543 $44.66 (x6)
Cylinder Sleeves	CSL630 $31.61 Melling Automotive (x6)
Balancer Sleeve	-

Note 1: Opt. 41615 $111.24 PC, E548K $363.87 Sealed Power
Note 2: Not incl. Head Bolts use FELP-ES72857 $44.42 FelPro

3.4L/207 cu. in. 91/95 Vin 'X' V-6

CH207LMK $1,033.50
Master
Kit

CH207LEK $896.62
Engine
Kit

CH207LRR $363.98
Re-ring
Kit

Rings	NOTE 1 HA-2C4903 $130.28 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-HS9113PT1 $235.16 FEL PRO GASKETS AND FELP-CS9113 $52.39 FEL PRO GASKETS

Pistons	H684CP $44.41 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CHG22 $36.46 Durabond
Oil Pump	NOTE 3 M187S $217.59 Melling Automotive
Freeze Plugs	MPE708R $6.96 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

CH207LCK

Lifters

TIMING KIT

NOTE 4
3139 $133.46 Engine Pro Timing Components
TB192 $31.64 Engine Pro Timing Components

Specialty KITS

CH207LRRP $405.40

RE-RING KIT + MAIN BEARINGS

CH207LRMK $65.13

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	01703 $10.59 E-Loy Engine Parts (x12) (1.437 x 4.091 x .2742 -1 grv) V4476 $22.07 Sealed Power (x12) (1.437 x 4.091 x .2742 -1 grv)
Exhaust Valves	01702 $11.62 E-Loy Engine Parts (x12) (1.260 x 4.100 x .2739 -1 grv) V4475 $20.54 Sealed Power (x12) (1.260 x 4.100 x .2739 -1 grv)
Valve Springs	160-1365 $4.63 E-Loy Engine Parts (x12)
Spring Shims	-
Valve Guides	140-8593 $3.35 E-Loy Engine Parts (x12) (Int & Exh)
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	BP-543 $44.66 (x6)
Cylinder Sleeves	CSL630 $31.61 Melling Automotive (x6)
Balancer Sleeve	-

Note 1: Opt. HA-2C4903 $130.28 Hastings,
Note 2: Not incl. Head Bolts use 38-3112 $33.18 Engine Pro
Note 3: Screen incl.
Note 4: Not incl. - Belt sprockets and belt tensioners

3.4L/207 cu. in. 96/97 Vin 'X' V-6

CH207LLMK $1,217.73
Master
Kit

CH207LLEK $1,047.75
Engine
Kit

CH207LLRR $521.36
Re-ring
Kit

Rings	NOTE 1 HA-2C4903 $130.28 Hastings Rings
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-HS9113PT2 $426.06 FEL PRO GASKETS AND FELP-CS9113 $52.39 FEL PRO GASKETS

Pistons	H684CP $44.41 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CHG22 $36.46 Durabond
Oil Pump	NOTE 3 M187S $217.59 Melling Automotive
Freeze Plugs	MPE708R $6.96 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft

CH207LLCK

Lifters

TIMING KIT

NOTE 4
3139 $133.46 Engine Pro Timing Components
TB273 $37.99 Engine Pro Timing Components
9308 $33.26 Engine Pro Timing Components

Specialty KITS

CH207LLRRP $562.73

RE-RING KIT + MAIN BEARINGS

CH207LLRMK $65.13

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	01703 $10.59 E-Loy Engine Parts (1.437 x 4.091 x .2742 -1 grv) V4476 $22.07 Sealed Power (x6) (1.437 x 4.091 x .2742 -1 grv)
Exhaust Valves	01702 $11.62 E-Loy Engine Parts (1.260 x 4.100 x .2739 -1 grv) V4475 $20.54 Sealed Power (x6) (1.260 x 4.100 x .2739 -1 grv)
Valve Springs	160-1365 $4.63 E-Loy Engine Parts (x12)
Spring Shims	-
Valve Guides	140-8593 $3.35 E-Loy Engine Parts
Push Rods	-
Rocker Arms	-
Oil Pump Screens	-
Connecting Rods	BP-543 $44.66
Cylinder Sleeves	CSL630 $31.61 Melling Automotive
Balancer Sleeve	-

Note 1: Opt. (OEM pist 1.2mm, 1.5mm, 3.0mm) 2C4903 $137.10 ;
(repl pist 1.5mm, 1.5mm, 4.0mm) HA-2M4649 $133.46 Hastings, 41615 $111.24 PC
Note 2: Not incl. Head Bolts use 38-3112 $33.18 Engine Pro
Note 3: Screen incl.
Note 4: Not incl. - Belt sprockets and tensioners.

3.4L/207 cu. in. 96/05 Vin 'E' OR 'F' V-6

CH207TMK $1,939.58
Master
Kit

CH207TEK $1,346.52
Engine
Kit

CH207TRR $858.47
Re-ring
Kit

Rings	NOTE 1 HA-2C4893 $58.73 Hastings Rings (1.2mm, 1.5mm, 4.0mm)
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	NOTE 2 FELP-260-1873T $274.83 Sealed Power (96/99) --- OR --- FELP-260-1872 $260.54 Sealed Power (00/03) --- OR --- FELP-HS9071PT2 $322.55 FEL PRO GASKETS (04/05) AND FELP-CS9957 $61.91 FEL PRO GASKETS (04/05)

Pistons	H847CP $76.11 Sealed Power Pistons (x6)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $25.34 Durabond
Oil Pump	M134 $95.29 Melling Automotive
Freeze Plugs	MPE708R $6.96 Melling Automotive
Pin Bushings	-

CAM KIT

Camshaft	MC1569 $335.36 Engine Pro Camshafts (96/99) --- OR --- MC1362 $343.38 Melling Automotive (00/02)	CH207TCK $534.07
Lifters	HA2270 $11.93 EPW Tappets (x12)	CH207TCK $534.07

TIMING KIT

3036 $63.54 Engine Pro Timing Components (96/99)
--- OR ---
3134 $131.76 Engine Pro Timing Components (00/05)

Specialty KITS

CH207TRRP $901.47

RE-RING KIT + MAIN BEARINGS

CH207TRMK $65.13

ROD BEARINGS + MAIN BEARINGS

Related Parts

Intake Valves	01810 $14.14 E-Loy Engine Parts (x6) (96/97 1.718 x 4.7050 x 0.31395 -1 grv) S3532 $14.15 Engine Pro Valves (x6) (96/97 1.718 x 4.7050 x 0.31395 -1 grv) V4571 $28.38 Sealed Power (x6) (98/06 1.760 x 4.684 x .3139 -1 grv) 01929 $9.40 E-Loy Engine Parts (x6) (98/06 1.760 x 4.684 x .3139 -1 grv) S3446 $9.68 Engine Pro Valves (x6) (98/06 1.760 x 4.684 x .3139 -1 grv)
Exhaust Valves	V4497 $26.81 Sealed Power (x6) (1.425 x 4.7360 x 0.31360 -1 grv) 01811 $15.85 E-Loy Engine Parts (x6) (1.425 x 4.7360 x 0.31360 -1 grv) A3543 $15.71 Engine Pro Valves (x6) (1.425 x 4.7360 x 0.31360 -1 grv)
Valve Springs	VS1642 $9.29 Sealed Power (x12) 160-1363 $7.63 E-Loy Engine Parts (x12)
Spring Shims	-
Valve Guides	140-8593 $3.35 E-Loy Engine Parts (x12)
Push Rods	RP3330 $7.35 Sealed Power (x6) (Intake) PR475 $2.11 EPWI P/L Valve Train Component (x6) (Intake) RP3331 $7.35 Sealed Power (x6) (Exhaust) PR474 $2.11 EPWI P/L Valve Train Component (x6) (Exhaust)
Rocker Arms	-
Oil Pump Screens	251S $18.94 Melling Automotive
Connecting Rods	BP-543 $44.66 (x6)
Cylinder Sleeves	CSL630 $31.61 Melling Automotive (x6)
Balancer Sleeve	-

Note 1: Opt (1.2mm, 1.5mm, 4.0mm) E918K $185.82 Sealed Power; (1.2mm, 1.5mm, 3.0mm) E928K $217.66 Sealed Power
Note 2: Not incl. Head Bolts use 38-3147 $31.72 Engine Pro or ES72892 $52.37

3.4L/207 cu. in. 2005-2007 Chevrolet Equinox,
2006-2007 Pontiac Torrent V-6 12V ViN F

CH207TLMK $1,193.95
Master Kit

CH207TLEK $907.78
Engine Kit

CH207TLRR $414.80
Re-ring Kit

Rings	HA-2M4893 $100.03 Hastings Rings (1.2MM 1.5MM 4.0MM)
Rod Bearings	CLE-CB1238A $3.75 Clevite Engine Parts (x6)
Gasket Set	FELP-HS9071PT3 $284.37 FEL PRO GASKETS FRLP-CS9071 FEL PRO GASKETS

Pistons	SILV-3439HC $58.64 Silvolite Pistons (x6) (1.2MM 1.5MM 4.0MM)
Main Bearings	CLE-MS2273A $45.95 Clevite Engine Parts
Cam Bearings	CH18 $20.56 Durabond
Oil Pump	M134 $95.29 Melling Automotive
Freeze Plugs	.
Pin Bushings	.

CAM
KIT

Camshaft	.	CH207TLCK
Lifters	JB2270 $18.89 Melling Automotive (x12)

TIMING
KIT

C6193S $93.59 Engine Pro Timing Components

SPECIALTY
KITS

CH207TLRRP $459.29

RE-RING KIT + MAIN BEARINGS

CH207TLRMK $65.13

ROD BEARINGS + MAIN BEARINGS

CRANK KIT

Not available

Related Parts

Intake Valves	S3446 $9.68 Engine Pro Valves (x6) (1.760 x 4.684 - 1grv)
Exhaust Valves	A3543 $15.71 Engine Pro Valves (x6) (1.425 x 4.736 - 1grv)
Valve Springs	160-1363 $7.63 SB International (x12)
Spring Shims	.
Valve Guides	140-3067 $2.39 SB International (x12)
Push Rods	PR434 $1.75 Valve Train Component (x6) (Exhaust) PR475 $2.05 Valve Train Component (x6) (Intake)
Rocker Arms	.
Oil Pump Screens	.
Connecting Rods	.
Cylinder Sleeves	.
Balancer Sleeve	.

Engine Rebuild & Assembly	Balancing & Blueprinting	Cylinder Heads
Engine Rebuild Kits	Engine Start-up	Other Related Web Sites Page 1
Crankshafts	Degree Cam	Other Related Web Sites Page 2
Purchase warranty & Return Information	About the owner of RPM	Frequently Asked Questions
MASTER ENGINE REBUILD KITS & PARTS
