MASTER ENGINE REBUILD KITS & PARTS

Home

TOYOTA

4AG - RACE SERIES VALVES

3SGTE - ECONOMICAL "H" BEAM STEEL CONNECTING RODS

3SGTE - RACE SERIES VALVES

2AZFE - ECONOMICAL "H" BEAM STEEL CONNECTING RODS

2AZFE - PRO SERIES TURBO TUFF "I" BEAM STEEL CONNECTING RODS

2AZFE - RACE SERIES VALVES

7M - RACE SERIES VALVES
SUPRA 3.0L - DOHC 24 VALVE ( 7MGE - TURBO 7MGTE ) - 1986 - 1992

2JZ - PLATINUM SERIES LIGHTWEIGHT PISTONS
Supra Turbo 93-98 - 2JZGTE 3.0L

2JZ - ECONOMICAL "H" BEAM STEEL CONNECTING RODS
Toyota Supra 3.0 2JZ ( 1993-1998 )

2JZ - PRO SERIES TURBO TUFF "I" BEAM STEEL CONNECTING RODS Toyota Supra 3.0 2JZ ( 1993-1998 )

2JZ - RACE SERIES VALVES
TOYOTA SUPRA 3.0L I/L 6 CYL - DOHC 24 VALVE ( 2JZGE - 2JZGTE ) - 1994 - 1998

2JZ - PRO SERIES VALVE SPRINGS RETAINERS AND LOCKS & Kits 2JZGT/2JZGTE

1FZFE - RACE SERIES VALVES
Land Cruiser 4.5L I6 - DOHC 24 Valve (1FZ-FE) 1993-1998

FA20 - PLATINUM SERIES LIGHTWEIGHT PISTONS
Scion FR-S 2013-Up - .866"/22mm x 2.250" Pin x .150" Wall

FA20 - H-TUFF H-TUFF PLUS RODS
FA20 BRZ 2.0L 2013-Up/WRX 2015-Up

FA20 - PRO SERIES TURBO TUFF "I" BEAM STEEL CONNECTING RODS FA20 BRZ 2.0L 2013-Up / WRX 2015-Up

STAINLESS STEEL VALVES

4AG - RACE SERIES VALVES

Manley valves have set the standard for excellence in quality, material and design in the performance world for four decades. Manufactured from proven Race Master materials, Manley valves feature chrome stems, hard tips, fully machined surfaces and swirl polished radii. Many applications are Pro Flow design for maximum air flow.

Note: Manley Performance strongly recommends that customers check their valve guide size in order to achieve the proper valve stem to guide clearance. Guides may need to be honed when replacing stock factory valves.

Part #
Your Cost
Type
Head Dia.
Stem
Dia.
O/A Length
Tip Length
Under- head
Angle/
Radius
Margin
Seat Width
Top of Head

  TOYOTA 4AG ( ATLANTIC )

11113-8 $200.31 Exh. 27.5 mm 6 mm/ .2362" 99.75 mm 3.5 mm 25° x 11/32" .065" .080" 20° Dish

11114-8 $200.31 Int. 32 mm 6 mm/ .2362" 99.6 mm 3.5 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

3SGTE - ECONOMICAL "H" BEAM STEEL CONNECTING RODS

Manley "H" Beam connecting rods are manufactured from 4340 forgings to the same exacting standards developed and approved by our original equipment customers. There is a vast difference in quality between a Manley "H" Beam and the "other" inexpensive H-Beams on the market. Weight matched to +/- 1.5 grams. Perfectly round big and small ends. Bend and twist is tightly controlled. Cap fasteners are 3/8" ARP 2000.

Part #
Your Cost Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

  Celica 1986-1999 MR2 1990-1999 3S-GTE DOHC

14008-4 $531.40 5.428" 2.008" 1.055" .866" (22mm) .8671" 564

3SGTE - RACE SERIES VALVES

Manley valves have set the standard for excellence in quality, material and design in the performance world for four decades. Manufactured from proven Race Master materials, Manley valves feature chrome stems, hard tips, fully machined surfaces and swirl polished radii. Many applications are Pro Flow design for maximum air flow.

Note: Manley Performance strongly recommends that customers check their valve guide size in order to achieve the proper valve stem to guide clearance. Guides may need to be honed when replacing stock factory valves.

Part #
Your Cost
Type
Head Dia.
Stem
Dia.
O/A Length
Tip Length
Under- head
Angle/
Radius
Margin
Seat Width
Top of Head

  TOYOTA MR2 2.0L - DOHC 16 VALVE ( TURBO 3SGTE ) - 1990 - 1995

11115-8 $200.31 Exh. 29 mm 6 mm/ .2362" 99.5 mm 3.5 mm 25° x 11/32" .065" .080" 20° Dish

11117-8 $200.31 Exh. 30 mm 6 mm/ .2362" 99.5 mm 3.5 mm 25° x 11/32" .065" .080" 20° Dish

11116-8 $200.31 Int. 33.5 mm 6 mm/ .2362" 100.55 mm 3.5 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

11118-8 $200.31 Int. 34.5 mm 6 mm/ .2362" 100.55 mm 3.5 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

2AZFE - ECONOMICAL "H" BEAM STEEL CONNECTING RODS

Manley "H" Beam connecting rods are manufactured from 4340 forgings to the same exacting standards developed and approved by our original equipment customers. There is a vast difference in quality between a Manley "H" Beam and the "other" inexpensive H-Beams on the market. Weight matched to +/- 1.5 grams. Perfectly round big and small ends. Bend and twist is tightly controlled. Cap fasteners are 3/8" ARP 2000.

Part #
Your Cost Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

  Scion TC 2.4L 2AZFE

14009-4 5.886" 2.008" .784" .866" (22mm) .8671" 530

2AZFE - PRO SERIES TURBO TUFF "I" BEAM STEEL CONNECTING RODS

Manley Pro Series connecting rods are forged from aircraft quality 4340 vacuum degassed material. Each rod is fully machined in the Manley Lakewood, NJ factory to the highest standards. Our signature "Turbo Tuff" design combines the appropriate weight and rugged strength for ultimate horsepower applications. Each rod is shot peened after machining and magnafluxed. Bores are round and without taper. Bend and twist is tightly controlled. Cap fasteners are 3/8" APR 2000 cap screws.

These rods are also available with ARP 625+ fasteners. To order, affix an "R6" to the part number.

Part #
Your Cost Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

Toyota Scion 2.4 2AZFE

14419-4 $1,023.76 5.886" 2.008" .784" .866" ( 22 mm ) .8671" 582

2AZFE - RACE SERIES VALVES

Manley valves have set the standard for excellence in quality, material and design in the performance world for four decades. Manufactured from proven Race Master materials, Manley valves feature chrome stems, hard tips, fully machined surfaces and swirl polished radii. Many applications are Pro Flow design for maximum air flow.

Note: Manley Performance strongly recommends that customers check their valve guide size in order to achieve the proper valve stem to guide clearance. Guides may need to be honed when replacing stock factory valves.

Part #
Your Cost
Type
Head Dia.
Stem
Dia.
O/A Length
Tip Length
Under- head
Angle/
Radius
Margin
Seat Width
Top of Head

TOYOTA SCION 2.4L - DOHC 16 VALVE ( 2AZFE )

11157-8 $200.31 Exh. 29.5 mm 5.5 mm/ .2165" 101.65 mm 2.49 mm 25° x 11/32" .065" .080" Flat Face

11159-8 $200.31 Exh. 30.5 mm 5.5 mm/ .2165" 101.65 mm 2.49 mm 25° x 11/32" .065" .080" Flat Face

11156-8 $200.31 Int. 34 mm 5.5 mm/ .2165" 101.96 mm 2.49 mm Pro Flo: 22° x 5/16" .050" .075" Flat Face

11158-8 $200.31 Int. 35 mm 5.5 mm/ .2165" 101.96 mm 2.49 mm Pro Flo: 22° x 5/16" .050" .075" Flat Face

7M - RACE SERIES VALVES

Manley valves have set the standard for excellence in quality, material and design in the performance world for four decades. Manufactured from proven Race Master materials, Manley valves feature chrome stems, hard tips, fully machined surfaces and swirl polished radii. Many applications are Pro Flow design for maximum air flow.

Note: Manley Performance strongly recommends that customers check their valve guide size in order to achieve the proper valve stem to guide clearance. Guides may need to be honed when replacing stock factory valves.

Part #
Your Cost
Type
Head Dia.
Stem
Dia.
O/A Length
Tip Length
Under- head
Angle/
Radius
Margin
Seat Width
Top of Head

TOYOTA SUPRA 3.0L - DOHC 24 VALVE ( 7MGE - TURBO 7MGTE ) - 1986 - 1992

11119-12 $300.47 Exh. 27.5 mm 6 mm/ .2362" 98.05 mm 4 mm 25° x 11/32" .065" .080" 20° Dish

11121-12 $300.47 Exh. 28.5 mm 6 mm/ .2362" 98.05 mm 4 mm 25° x 11/32" .065" .080" 20° Dish

11120-12 $300.47 Int. 32 mm 6 mm/ .2362" 98.05 mm 4 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

11122-12 $300.47 Int. 33 mm 6 mm/ .2362" 98.05 mm 4 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

2JZ - PLATINUM SERIES LIGHTWEIGHT PISTON KITS

Manley pistons are machined of high strength 2618 material. Each design is lightweight yet robust enough to deliver long service life. Offset wrist pin design is utilized for quiet start-ups. Perfect ring groove to skirt squareness is achieved through our unique "one fixturing" manufacturing method that assures maximum horsepower. All pistons come with moly coated skirts and will accommodate +1mm valve sizes. Round wire locks, premium chrome moly wrist pins, and premium steel top ring sets from Total Seal are included with every kit at no additional charge. 9310 alloy upgraded wrist pins are available. Simply order the EXTREME DUTY part number in the column below. These are equipped with 9310 pins. Recommended clearance: .0035" measured 1.100" down from the bottom of the oil ring groove.

Part #
Your Cost Extreme Duty Part #
Your Cost Bore Size
(mm) Over
Size Rod
Length Strk Comp.
Distance Dome Vol. (cc)
Cyl.
Head
(cc)
Comp.
Ratio Piston
Type Piston
Wt / Gms Included
Ring Set

Toyota Supra Turbo 93-98 - 2JZGTE 3.0L .866"/22mm x 2.250" Pin x .150" Wall

86mm STD STROKE (3.0L)

609000C-6 $1,077.64 609000CE-6 $1,269.32 86 STD 5.590" 86 1.338" -10 45 9:1 Dish 347 46861-6 $244.08

609005C-6 $1,077.64 609005CE-6 $1,269.32 86.5 +.5mm 5.590" 86 1.338" -10 45 9:1 Dish 353 46866-6 $244.08

609015C-6 $1,077.64 609015CE-6 $1,269.32 87 +1.0mm 5.590" 86 1.338" -10 45 9:1 Dish 359 46871-6 $244.08

609100C-6 $1,077.64 609100CE-6 $1,269.32 86 STD 5.590" 86 1.338" -2.5 45 10:1 Flat Top 347 46861-6 $244.08

609105C-6 $1,077.64 609105CE-6 $1,269.32 86.5 +.5mm 5.590" 86 1.338" -2.5 45 10:1 Flat Top 354 46866-6 $244.08

609115C-6 $1,077.64 609115CE-6 $1,269.32 87 +1.0mm 5.590" 86 1.338" -2.5 45 10:1 Flat Top 360 46871-6 $244.08

94mm STROKER (3.4L)

629100C-6 $1,077.64 629100CE-6 $1,269.32 86 STD 5.590" 94 1.180" -16 45 9:1 Dish 315 46861-6 $244.08

629105C-6 $1,077.64 629105CE-6 $1,269.32 86.5 +.5mm 5.590" 94 1.180" -16 45 9:1 Dish 322 46866-6 $244.08

629115C-6 $1,077.64 629115CE-6 $1,269.32 87 +1.0mm 5.590" 94 1.180" -16 45 9:1 Dish 329 46871-6 $244.08

629000C-6 $1,077.64 629000CE-6 $1,269.32 86 STD 5.590" 94 1.180" -8 45 10:1 Dish 315 46861-6 $244.08

629005C-6 $1,077.64 629005CE-6 $1,269.32 86.5 +.5mm 5.590" 94 1.180" -8 45 10:1 Dish 322 46866-6 $244.08

629015C-6 $1,077.64 629015CE-6 $1,269.32 87 +1.0mm 5.590" 94 1.180" -8 45 10:1 Dish 328 46871-6 $244.08

2JZ - PLATINUM SERIES TURBO TUFF PISTON KITS

2618 high strength material
2.250 x .250" wall 9310 alloy pin included P/N 42552
Moly Coated Skirts
Pressure balance groove
Will accommodate +1mm valve sizes
Vertical Gas Ports designed for high HP Race Engines
Premium Steel top rings with Napier seconds and round wire locks included
Recommended piston clearance .0035" measured .850" from the bottom of the oil ring

Part #
Your Cost
Bore Size (mm)
Over Size
Rod Length
Strk
Comp. Dist.
Dome Vol. (cc) Cyl.
Head
(cc)
Comp. Ratio
Piston Type
Piston Wt / Gms
Included Ring Set

86mm STD STROKE (3.0L)

609202CE-6 $1,531.44 86.25 +.25mm 5.590" 86 1.328" -8 45 9.0 Dish TBA 47862-6 $244.08

609205CE-6 $1,531.44 86.50 +.5mm 5.590" 86 1.328" -8 45 9.0 Dish TBA 47865-6 $244.08

609207CE-6 $1,531.44 86.75 +.75mm 5.590" 86 1.328" -8 45 9.0 Dish TBA 47867-6 $244.08

609210CE-6 $1,531.44 87.00 +1.0mm 5.590" 86 1.328" -8 45 9.0 Dish TBA 47870-6 $244.08

609302CE-6 $1,531.44 86.25 +.25mm 5.590" 86 1.328" -1 45 10.0 Dome TBA 47862-6 $244.08

609305CE-6 $1,531.44 86.50 +.5mm 5.590" 86 1.328" -1 45 10.0 Dome TBA 47865-6 $244.08

609307CE-6 $1,531.44 86.75 +.75mm 5.590" 86 1.328" -1 45 10.0 Dome TBA 47867-6 $244.08

609310CE-6 $1,531.44 87.00 +1.0mm 5.590" 86 1.328" -1 45 10.0 Dome TBA 47870-6 $244.08

94mm STROKER (3.4L)

629202CE-6 $1,531.44 86.25 +.25mm 5.590" 94 1.170" -14 45 9.0 Dish TBA 47862-6 $244.08

629205CE-6 $1,531.44 86.50 +.5mm 5.590" 94 1.170" -14 45 9.0 Dish TBA 47865-6 $244.08

629207CE-6 $1,531.44 86.75 +.75mm 5.590" 94 1.170" -14 45 9.0 Dish TBA 47867-6 $244.08

629210CE-6 $1,531.44 87.00 +1.0mm 5.590" 94 1.170" -14 45 9.0 Dish TBA 47870-6 $244.08

629302CE-6 $1,531.44 86.25 +.25mm 5.590" 94 1.170" -6 45 10.0 Dish TBA 47862-6 $244.08

629305CE-6 $1,531.44 86.50 +.5mm 5.590" 94 1.170" -6 45 10.0 Dish TBA 47865-6 $244.08

629307CE-6 $1,531.44 86.75 +.75mm 5.590" 94 1.170" -6 45 10.0 Dish TBA 47867-6 $244.08

629310CE-6 $1,531.44 87.00 +1.0mm 5.590" 94 1.170" -6 45 10.0 Dish TBA 47870-6 $244.08

2JZ - ECONOMICAL "H" BEAM STEEL CONNECTING RODS

Manley "H" Beam connecting rods are manufactured from 4340 forgings to the same exacting standards developed and approved by our original equipment customers. There is a vast difference in quality between a Manley "H" Beam and the "other" inexpensive H-Beams on the market. Weight matched to +/- 1.5 grams. Perfectly round big and small ends. Bend and twist is tightly controlled. Cap fasteners are 3/8" ARP 2000 for the "H" Beam and 3/8" ARP Custom Age 625+ for the H-Tuff Plus.

Part #
Your Cost Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

  Toyota Supra 3.0 2JZ ( 1993-1998 )

14027-6 $797.09 5.590" 2.167" 1.015" .866" ( 22 mm ) .8671" 552

  Toyota Supra 3.0 2JZ ( 1993-1998 ) - H-Tuff Series with heavier beam for higher boost applications

15027-6 $889.56 (H-Tuff) 5.590" 2.167" 1.015" .866" ( 22mm ) .8671" 636

15027R6-6 $1,399.95 (H-Tuff Plus) 5.590" 2.167" 1.015" .866" ( 22mm ) .8671" 636

2JZ - PRO SERIES TURBO TUFF "I" BEAM STEEL CONNECTING RODS

Manley Pro Series connecting rods are forged from aircraft quality 4340 vacuum degassed material. Each rod is fully machined in the Manley Lakewood, NJ factory to the highest standards. Our signature "Turbo Tuff" design combines the appropriate weight and rugged strength for ultimate horsepower applications. Each rod is shot peened after machining and magnafluxed. Bores are round and without taper. Bend and twist is tightly controlled. Cap fasteners are 3/8" APR 2000 cap screws.

These rods are also available with ARP 625+ fasteners. To order, affix an "R6" to the part number.

Part #
Your Cost Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

  Toyota Supra 3.0 2JZ ( 1993-1998 )

14402-6 $1,535.64 5.590" 2.167" 1.015" .866" ( 22 mm ) .8671" 645

2JZ - RACE SERIES VALVES

Manley valves have set the standard for excellence in quality, material and design in the performance world for four decades. Manufactured from proven Race Master materials, Manley valves feature chrome stems, hard tips, fully machined surfaces and swirl polished radii. Many applications are Pro Flow design for maximum air flow.

Note: Manley Performance strongly recommends that customers check their valve guide size in order to achieve the proper valve stem to guide clearance. Guides may need to be honed when replacing stock factory valves.

Part #
Your Cost
Type
Head Dia.
Stem
Dia.
O/A Length
Tip Length
Under- head
Angle/
Radius
Margin
Seat Width
Top of Head

  TOYOTA SUPRA 3.0L I/L 6 CYL - DOHC 24 VALVE ( 2JZGE - 2JZGTE ) - 1994 - 1998

11123-12 $300.47 Exh. 29 mm 6 mm/ .2362" 99.1 mm 3.5 mm 25° x 11/32" .065" .080" 20° Dish

11125-12 $300.47 Exh. 30 mm 6 mm/ .2362" 99.1 mm 3.5 mm 25° x 11/32" .065" .080" 20° Dish

11124-12 $300.47 Int. 33.6 mm 6 mm/ .2362" 98.55 mm 3.5 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

11126-12 $300.47 Int. 34.6 mm 6 mm/ .2362" 98.55 mm 3.5 mm Pro Flo: 22° x 5/16" .050" .075" 17° Dish

2JZ - PRO SERIES VALVE SPRINGS RETAINERS LOCKS & KITS

Manley valve springs are wound from super clean alloy. Each design minimizes stress to ensure long service life with high lift camshafts. Titanium retainers are manufactured in our own double spindle CNC machines to exacting tolerances and precise installed height specifications. Valve locks are manufactured in our own Swiss turning centers with rigid control over the all-important angle to ensure precise mating with the retainer.

VALVE SPRINGS

Part #
Your Cost
Qty. O.D./ I.D.
Outer
Inner Seat Pres. Open Pres. Stock/ Max Lift Coil Bind Rate (lbs./in.) Retainer #

  Toyota 2JZGT/2JZGTE

22130-24 $207.45 24 pcs. 1.050"/ .755" 82 @ 1.325" 165 @ .985"
187 @ .895" 0.340"
0.430" 0.845" 245 23130-24 $359.80

  Toyota Supra 2JZGT/2JZGTE 6 cyl. Single Conical Ovate Wire

22135-24 $368.39 24 pcs. 1.126"/ .640" 127 @ 1.325" 239 @ .985"
264 @ .910" 0.340"
0.415" 0.860" 330 23135-24 $359.80

TITANIUM RETAINERS

. Valve Stem
Dia. . Dimensions

Part #
Your Cost
Qty. Spring Deg. A B C Step Height

  Toyota 2JZGT/2JZGTE

23130-24 $359.80 24 pcs. 22130-16 6.0 mm 6° 1.050" .745" .515" .100" Stock

23135-24 $359.80 24 pcs. 22135-16 6.0 mm 6° .875" .627" .465" .095" Stock

VALVE LOCKS

Part #
Your Cost
Qty. Valve Stem Groove Type Angle Wgt. / Pr.

Toyota

13014-8 $51.77 8 pr. 6.0 mm / .2362" Bead Loc® 6° 1.3 gms

SPRING AND RETAINER KITS

Part #
Your Cost
Qty. Max Net Lift Spring # Retainer #

Toyota Supra, 2JZ 6 cyl.

26130 $510.53 1 kit .430" 22130 23130

26130K $657.86 1 kit (Includes 13014-8 $51.77 valve locks) .430" 22130 23130

26135 $655.37 1 kit .415" 22135 23135

26135K $802.68 1 kit (Includes 13014-8 $51.77 valve locks) .415" 22135 23135

1FZFE - RACE SERIES VALVES

Manley valves have set the standard for excellence in quality, material and design in the performance world for four decades. Manufactured from proven Race Master materials, Manley valves feature chrome stems, hard tips, fully machined surfaces and swirl polished radii. Many applications are Pro Flow design for maximum air flow.

Note: Manley Performance strongly recommends that customers check their valve guide size in order to achieve the proper valve stem to guide clearance. Guides may need to be honed when replacing stock factory valves.

Part #
Your Cost
Type
Head Dia.
Stem
Dia.
O/A Length
Tip Length
Under- head
Angle/
Radius
Margin
Seat Width
Top of Head

  Toyota Land Cruiser 4.5L I6 - DOHC 24 Valve (1FZ-FE) 1993-1998

11167-12 $413.59 Exh. 32.0 mm 7 mm/ .2740" 99 mm 3.8 mm 15° x 1/2" .065" .080" Flat Face

11169-12 $413.59 Exh. 33.2 mm 7 mm/ .2740" 99 mm 3.8 mm 15° x 1/2" .065" .080" Flat Face

11189-12 $413.59 Exh. 33.5 mm 7 mm/ .2740" 99 mm 3.8 mm 15° x 1/2" .065" .080" Flat Face

11191-12 $413.59 Exh. 33.5 mm 7 mm/ .2740" 99 mm 3.8 mm 15° x 1/2" .065" .080" 9° Dish

11173-12 $413.59 Exh. 34.0 mm 7 mm/ .2740" 99 mm 3.8 mm 15° X 1/2" .065" .080" Flat Face

11175-12 $413.59 Exh. 34.0 mm 7 mm/ .2740" 99 mm 3.8 mm 15° X 1/2" .065" .080" 9° Dish

11166-12 $413.59 Int. 38.0 mm 7 mm/ .2740" 100 mm 3.8 mm Pro Flo: 10° X 3/8" .050" .075" Flat Face

11168-12 $413.59 Int. 39.2 mm 7 mm/ .2740" 100 mm 3.8 mm Pro Flo: 10° X 3/8" .050" .075" Flat Face

11186-12 $413.59 Int. 39.5 mm 7 mm/ .2740" 100 mm 3.8 mm Pro Flo: 10° x 3/8" .050" .075" Flat Face

11188-12 $413.59 Int. 39.5 mm 7 mm/ .2740" 100 mm 3.8 mm Pro Flo: 10° x 3/8" .050" .075" 5° Dish

11170-12 $413.59 Int. 40.0 mm 7 mm/ .2740" 100 mm 3.8 mm Pro Flo: 10° X 3/8" .050" .075" Flat Face

11172-12 $413.59 Int. 40.0 mm 7 mm/ .2740" 100 mm 3.8 mm Pro Flo: 10° X 3/8" .050" .075" 5° Dish

FA20 - PLATINUM SERIES LIGHTWEIGHT PISTON KITS

Manley pistons are machined of high strength 2618 material. Each design is lightweight yet robust enough to deliver long service life. Offset wrist pin design is utilized for quiet start-ups. Perfect ring groove to skirt squareness is achieved through our unique "one fixturing" manufacturing method that assures maximum horsepower. All pistons come with moly coated skirts and will accommodate +1mm valve sizes. Round wire locks, premium chrome moly wrist pins (P/N 42251), premium steel top ring, Napier style second ring and higher tension oil ring sets from Total Seal are included with every kit at no additional charge. 9310 alloy .210" wall upgraded wrist pins (P/N 42551) are available. Recommended clearance: .003" for mildly boosted and .0035" for highly boosted measured .850" from the bottom of the oil ring groove.

Part # Bore Size (mm) Over Size Rod Length
Strk
Comp. Dist. Dome Vol. (cc) Comp. Ratio Piston Type Piston Wt / Gms Included Ring Set

  Toyota Scion FR-S 2013-Up - .866"/22mm x 2.250" Pin x .150" Wall

632600CA-1 $181.33 * 86.00 STD 5.090" 86 1.285" -11.4 10.0 Dish TBA 46861-4

632600CB-1 $181.33 * 86.00 STD 5.090" 86 1.285" -11.4 10.0 Dish TBA 46861-4

632601C-4 $725.34 86.10 +.1mm 5.090" 86 1.285" -11.4 10.0 Dish TBA 46861-4

*These pistons feature skirt diameters that correspond to the OEM Grade A or B bores resulting in a piston to wall clearance range of .0023" - .0031". Check the bore grades on the top of your block and order the appropriate quantities of Grade A or B pistons. (Sold as -1 individual pieces, not sets.)

FA20 - H-TUFF H-TUFF PLUS RODS

Manufactured from 4340 forgings
Heat treated, stress relieved, shot peened and 100% individually magnafluxed
Weight matched sets " 1.5 grams
Cap fasteners are 3/8" ARP 2000 for the H-Tuff and 3/8" ARP Custom Age 625" for the H-Tuff Plus
Flywheel horsepower range for the these rods in a 4 cylinder application is 750 with the ARP 2000 bolts and 950 with ARP 625" bolts.
Bridges the gap between our standard, proven H-Beams and top of the line, best of the best Turbo Tuff® Series rods
H-Tuff delivers a stronger rod with greater safety margin to handle elevated boost and higher power levels for a modest price premium over standard H-Beams
H-Tuff design incorporates wider beam and increased cross-sectional thickness in critical areas

Part #
Your Cost H-Tuff Plus
Part # Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

   FA20 BRZ 2.0L 2013-Up/WRX 2015-Up

15084-4 $645.04 15084R6-4 $986.72 5.090" 2.087" .843" .866" (22mm) .8671" TBA

FA20 - PRO SERIES TURBO TUFF "I" BEAM STEEL CONNECTING RODS

Manley Pro Series connecting rods are forged from aircraft quality 4340 vacuum degassed material. Each rod is fully machined in the Manley Lakewood, NJ factory to the highest standards. Our signature "Turbo Tuff" design combines the appropriate weight and rugged strength for ultimate horsepower applications. Each rod is shot peened after machining and magnafluxed. Bores are round and without taper. Bend and twist is tightly controlled. Cap fasteners are 3/8" APR 2000 cap screws.

These rods are also available with ARP 625" fasteners. To order, affix an "R6" to the part number.

Part #
Your Cost Center
to
Center Big End Bore Big End Width Pin Dia. Pin Bore Gram Weight

FA20 BRZ 2.0L 2013-Up / WRX 2015-Up

14431-4 $1,123.24 5.090" 2.087" .843" .866" (22mm) .8671" 575

Top of Page

HOME

Engine Rebuild & Assembly	Balancing & Blueprinting	Cylinder Heads
Engine Rebuild Kits	Engine Start-up	Other Related Web Sites Page 1
Crankshafts	Degree Cam	Other Related Web Sites Page 2
Purchase warranty & Return Information	About the owner of RPM	Frequently Asked Questions
MASTER ENGINE REBUILD KITS & PARTS

Part # Your Cost	Type	Head Dia.	Stem Dia.	O/A Length	Tip Length	Under- head Angle/ Radius	Margin	Seat Width	Top of Head
TOYOTA 4AG ( ATLANTIC )
11113-8 $200.31	Exh.	27.5 mm	6 mm/ .2362"	99.75 mm	3.5 mm	25° x 11/32"	.065"	.080"	20° Dish
11114-8 $200.31	Int.	32 mm	6 mm/ .2362"	99.6 mm	3.5 mm	Pro Flo: 22° x 5/16"	.050"	.075"	17° Dish

Part # Your Cost	Center to Center	Big End Bore	Big End Width	Pin Dia.	Pin Bore	Gram Weight
Celica 1986-1999 MR2 1990-1999 3S-GTE DOHC
14008-4 $531.40	5.428"	2.008"	1.055"	.866" (22mm)	.8671"	564

Part # Your Cost	Extreme Duty Part # Your Cost	Bore Size (mm)	Over Size	Rod Length	Strk	Comp. Distance	Dome Vol. (cc)	Cyl. Head (cc)	Comp. Ratio	Piston Type	Piston Wt / Gms	Included Ring Set
Toyota Supra Turbo 93-98 - 2JZGTE 3.0L .866"/22mm x 2.250" Pin x .150" Wall
86mm STD STROKE (3.0L)
609000C-6 $1,077.64	609000CE-6 $1,269.32	86	STD	5.590"	86	1.338"	-10	45	9:1	Dish	347	46861-6 $244.08
609005C-6 $1,077.64	609005CE-6 $1,269.32	86.5	+.5mm	5.590"	86	1.338"	-10	45	9:1	Dish	353	46866-6 $244.08
609015C-6 $1,077.64	609015CE-6 $1,269.32	87	+1.0mm	5.590"	86	1.338"	-10	45	9:1	Dish	359	46871-6 $244.08
609100C-6 $1,077.64	609100CE-6 $1,269.32	86	STD	5.590"	86	1.338"	-2.5	45	10:1	Flat Top	347	46861-6 $244.08
609105C-6 $1,077.64	609105CE-6 $1,269.32	86.5	+.5mm	5.590"	86	1.338"	-2.5	45	10:1	Flat Top	354	46866-6 $244.08
609115C-6 $1,077.64	609115CE-6 $1,269.32	87	+1.0mm	5.590"	86	1.338"	-2.5	45	10:1	Flat Top	360	46871-6 $244.08
94mm STROKER (3.4L)
629100C-6 $1,077.64	629100CE-6 $1,269.32	86	STD	5.590"	94	1.180"	-16	45	9:1	Dish	315	46861-6 $244.08
629105C-6 $1,077.64	629105CE-6 $1,269.32	86.5	+.5mm	5.590"	94	1.180"	-16	45	9:1	Dish	322	46866-6 $244.08
629115C-6 $1,077.64	629115CE-6 $1,269.32	87	+1.0mm	5.590"	94	1.180"	-16	45	9:1	Dish	329	46871-6 $244.08
629000C-6 $1,077.64	629000CE-6 $1,269.32	86	STD	5.590"	94	1.180"	-8	45	10:1	Dish	315	46861-6 $244.08
629005C-6 $1,077.64	629005CE-6 $1,269.32	86.5	+.5mm	5.590"	94	1.180"	-8	45	10:1	Dish	322	46866-6 $244.08
629015C-6 $1,077.64	629015CE-6 $1,269.32	87	+1.0mm	5.590"	94	1.180"	-8	45	10:1	Dish	328	46871-6 $244.08

Part # Your Cost	Bore Size (mm)	Over Size	Rod Length	Strk	Comp. Dist.	Dome Vol. (cc)	Cyl. Head (cc)	Comp. Ratio	Piston Type	Piston Wt / Gms	Included Ring Set
86mm STD STROKE (3.0L)
609202CE-6 $1,531.44	86.25	+.25mm	5.590"	86	1.328"	-8	45	9.0	Dish	TBA	47862-6 $244.08
609205CE-6 $1,531.44	86.50	+.5mm	5.590"	86	1.328"	-8	45	9.0	Dish	TBA	47865-6 $244.08
609207CE-6 $1,531.44	86.75	+.75mm	5.590"	86	1.328"	-8	45	9.0	Dish	TBA	47867-6 $244.08
609210CE-6 $1,531.44	87.00	+1.0mm	5.590"	86	1.328"	-8	45	9.0	Dish	TBA	47870-6 $244.08
609302CE-6 $1,531.44	86.25	+.25mm	5.590"	86	1.328"	-1	45	10.0	Dome	TBA	47862-6 $244.08
609305CE-6 $1,531.44	86.50	+.5mm	5.590"	86	1.328"	-1	45	10.0	Dome	TBA	47865-6 $244.08
609307CE-6 $1,531.44	86.75	+.75mm	5.590"	86	1.328"	-1	45	10.0	Dome	TBA	47867-6 $244.08
609310CE-6 $1,531.44	87.00	+1.0mm	5.590"	86	1.328"	-1	45	10.0	Dome	TBA	47870-6 $244.08
94mm STROKER (3.4L)
629202CE-6 $1,531.44	86.25	+.25mm	5.590"	94	1.170"	-14	45	9.0	Dish	TBA	47862-6 $244.08
629205CE-6 $1,531.44	86.50	+.5mm	5.590"	94	1.170"	-14	45	9.0	Dish	TBA	47865-6 $244.08
629207CE-6 $1,531.44	86.75	+.75mm	5.590"	94	1.170"	-14	45	9.0	Dish	TBA	47867-6 $244.08
629210CE-6 $1,531.44	87.00	+1.0mm	5.590"	94	1.170"	-14	45	9.0	Dish	TBA	47870-6 $244.08
629302CE-6 $1,531.44	86.25	+.25mm	5.590"	94	1.170"	-6	45	10.0	Dish	TBA	47862-6 $244.08
629305CE-6 $1,531.44	86.50	+.5mm	5.590"	94	1.170"	-6	45	10.0	Dish	TBA	47865-6 $244.08
629307CE-6 $1,531.44	86.75	+.75mm	5.590"	94	1.170"	-6	45	10.0	Dish	TBA	47867-6 $244.08
629310CE-6 $1,531.44	87.00	+1.0mm	5.590"	94	1.170"	-6	45	10.0	Dish	TBA	47870-6 $244.08

Part # Your Cost	Qty.	O.D./ I.D. Outer Inner	Seat Pres.	Open Pres.	Stock/ Max Lift	Coil Bind	Rate (lbs./in.)	Retainer #
Toyota 2JZGT/2JZGTE
22130-24 $207.45	24 pcs.	1.050"/ .755"	82 @ 1.325"	165 @ .985" 187 @ .895"	0.340" 0.430"	0.845"	245	23130-24 $359.80
Toyota Supra 2JZGT/2JZGTE 6 cyl. Single Conical Ovate Wire
22135-24 $368.39	24 pcs.	1.126"/ .640"	127 @ 1.325"	239 @ .985" 264 @ .910"	0.340" 0.415"	0.860"	330	23135-24 $359.80

.			Valve Stem Dia.	.	Dimensions
Part # Your Cost	Qty.	Spring	Valve Stem Dia.	Deg.	A	B	C	Step	Height
Toyota 2JZGT/2JZGTE
23130-24 $359.80	24 pcs.	22130-16	6.0 mm	6°	1.050"	.745"	.515"	.100"	Stock
23135-24 $359.80	24 pcs.	22135-16	6.0 mm	6°	.875"	.627"	.465"	.095"	Stock

Part # Your Cost	Qty.	Valve Stem	Groove Type	Angle	Wgt. / Pr.
Toyota
13014-8 $51.77	8 pr.	6.0 mm / .2362"	Bead Loc®	6°	1.3 gms

Part # Your Cost	Qty.	Max Net Lift	Spring #	Retainer #
Toyota Supra, 2JZ 6 cyl.
26130 $510.53	1 kit	.430"	22130	23130
26130K $657.86	1 kit (Includes 13014-8 $51.77 valve locks)	.430"	22130	23130
26135 $655.37	1 kit	.415"	22135	23135
26135K $802.68	1 kit (Includes 13014-8 $51.77 valve locks)	.415"	22135	23135

Part #	Bore Size (mm)	Over Size	Rod Length	Strk	Comp. Dist.	Dome Vol. (cc)	Comp. Ratio	Piston Type	Piston Wt / Gms	Included Ring Set
Toyota Scion FR-S 2013-Up - .866"/22mm x 2.250" Pin x .150" Wall

632600CA-1 $181.33 *	86.00	STD	5.090"	86	1.285"	-11.4	10.0	Dish	TBA	46861-4
632600CB-1 $181.33 *	86.00	STD	5.090"	86	1.285"	-11.4	10.0	Dish	TBA	46861-4
632601C-4 $725.34	86.10	+.1mm	5.090"	86	1.285"	-11.4	10.0	Dish	TBA	46861-4

Part # Your Cost	H-Tuff Plus Part #	Center to Center	Big End Bore	Big End Width	Pin Dia.	Pin Bore	Gram Weight
FA20 BRZ 2.0L 2013-Up/WRX 2015-Up
15084-4 $645.04	15084R6-4 $986.72	5.090"	2.087"	.843"	.866" (22mm)	.8671"	TBA
