MASTER ENGINE REBUILD KITS & PARTS

Home
Page 2



Table of contents

Caterpillar	3
Cummins	9
Detroit Diesel	44
Hino	58
Isuzu	59
Mercedes-Benz	60
Navistar	75
Volvo	89
Volvo / Mack	91

Part numbers above each table are In-Frame Kits or
Complete Engine ASSEMBLY OVERHAUL KITS

Page 3
CATERPILLAR 3406 14.6L
CYLINDER KIT OEM: 0R1572. PISTON OEM: 9Y7212.
456-5035

Component	OEM	Description	Qty.
226-1733 $510.27	0R1572	CYLINDER SLEEVE ASSEMBLY	6
MB2848AL $56.41	1175975	MAIN BEARING SET	7
CB1262AL $27.42	9Y9497	CONNECTING ROD BEARINGS	6
TW583S $68.05	1W5252	THRUST WASHER	1
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1

456-5040 $3,205.86

Component	OEM	Description	Qty.
226-1855 $436.32	0R2861	CYLINDER SLEEVE ASSEMBLY	6
CB1262AL $27.42	9Y9497	MAIN BEARING	6
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1

456-5035

Component	OEM	Description	Qty.
226-1733 $510.27	0R1572	CYLINDER SLEEVE ASSEMBLY	6
MB2848AL $56.41	1175975	MAIN BEARING SET	7
CB1262AL $27.42 AM	9Y9497	CONNECTING ROD BEARINGS	6
TW583S $68.05	1W5252	THRUST WASHER	1
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1

CATERPILLAR 3406B
PISTON OEM: 7C3406, 9Y1915, 9Y9889.
FROM S/N 4MG3600 ONWARD AND 8TC1413 ONWARD.
SPACER PLATE
456-5040 $3,205.86

Component	OEM	Description	Qty.
226-1855 $436.32	0R2861	CYLINDER SLEEVE ASSEMBLY	6
CB1262AL $27.42 AM	9Y9497	MAIN BEARING	6
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1

Page 4
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CATERPILLAR 3406B CONT‘D
PISTON OEM: 7E0539. FROM S/N 8TC6476.
SPACER PLATE
456-5043 $6,710.44

Component	OEM	Description	Qty.
226-1901 $526.16	0R2975	CYLINDER SLEEVE ASSEMBLY	6
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1

456-5036 $3,340.74

Component	OEM	Description	Qty.
226-1918 $362.36	0R3782	CYLINDER SLEEVE ASSEMBLY	6
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1

456-5049 $5,211.17

Component	OEM	Description	Qty.
226-1969 $547.94	0R8915	CYLINDER SLEEVE ASSEMBLY	6
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK3535 $845.80	2161252	IN-FRAME OVERHAUL SET	1

Page 5
WITHOUT PISTONS. PISTON OEM: 1352837, 116-1372.
PISTON RINGS OEM: 1W8922. SERIAL PREFIX: 5EK.
456-5051NP $3,434.98

Component	OEM	Description	Qty.
226-4506 $136.24	1979322	CYLINDER SLEEVE	6
CB1622P $34.58 -AM	9Y7735	CONNECTING ROD BEARINGS	6
EK3535 $845.80	2161252	IN-FRAME OVERHAUL SET	1
MB2848AL $56.41	1175975	MAIN BEARING	7
S41890 $70.92	1W8922	PISTON RING SET	6
TW583S $68.05	1W5252	THRUST WASHER	1

PISTON OEM: 116-1372, 133-7537, 149-5566.
SERIAL PREFIX: 5EK, 6TS
456-5052

Component	OEM	Description	Qty.
226-1971	0R8913	CYLINDER SLEEVE ASSEMBLY	6
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING SETS	7
EK3535 $845.80	2161252	IN-FRAME OVERHAUL SET	1
TW583S $68.05	1W5252	THRUST WASHER	1

CATERPILLAR 3406E 14.6L
PISTON OEM: 7C2888. PREFIX: 5EK.
456-5048

Component	OEM	Description	Qty.
226-1973	0R4487	CYLINDER SLEEVE ASSEMBLY	6
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING SETS	7
EK3535 $845.80	2161252	IN-FRAME OVERHAUL SET	1
TW583S $68.05	1W5252	THRUST WASHER	1

Page 6
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CATERPILLAR 3406, 3406E, 3406B
PISTON OEM: 2900017, 9Y-4004, 9Y-9889.
CYLINDER KIT OEM: 0R2694, 0R4515.
FROM S/N 92U28617;
CONNECTING ROD BEARINGS LENGTH 1.535"
456-5031 $3,070.94

Component	OEM	Description	Qty.
226-1734 $479.86	0R2694	CYLINDER SLEEVE ASSEMBLY	6
MB2848AL $56.41	1175975	MAIN BEARING	6
CB1262AL $27.42 AM	9Y9497	CONNECTING ROD BEARINGS	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1

CATERPILLAR 3406M
PISTON OEM: 7E0539. SPACER PLATE.
456-5007 $3,746.70

Component	OEM	Description	Qty.
226-1901 $526.16	0R2975	CYLINDER SLEEVE ASSEMBLY	6
CB1262AL $27.42 AM	9Y9497	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK0102 $1,238.47	1412222	IN-FRAME OVERHAUL SET	1

CATERPILLAR 3408 18 L.
PISTON OEM: 9Y7212. WITHOUT GASKETS
456-5003

Component	OEM	Description	Qty.
226-1733 $510.27	0R1572	CYLINDER SLEEVE	8
CB1262AL $27.42	9Y9497	CONNECTING ROD BEARINGS	8
MB2848AL $56.41	1175975	MAIN BEARING SET	5
TW583S $68.05	1W5252	THRUST WASHER	1

Page 7
CATERPILLAR C15 TWIN TURBO
PISTON OEM: 3564787, 2485514, 2326557, 3066470.
SERIAL NUMBERS: MXS, SDP, NXS, BXS ONWARD.
CYLINDER KIT OEM: 10R3304.
456-5089 $6,056.59

Component	OEM	Description	Qty.
226-2054 $868.41	10R3304	CYLINDER SLEEVE ASSEMBLY	6
CB1933P $33.26	2243246	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK3537 $1,637.60	1685248	IN-FRAME OVERHAUL SET	1

PISTON OEM: 3564787, 2485514, 2326557, 3066470.
CYLINDER KIT OEM: 10R3304. PISTONLESS.
SERIAL NUMBERS: MXS, SDP, NXS, BXS ONWARD.
456-5089NP $4,989.41

Component	OEM	Description	Qty.
226-4506 $136.24	1979322	CYLINDER SLEEVE	6
S42223 $184.05	2370194	PISTON RING SET	6
CB1933P $33.26	2243246	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING SET	7
TW583S $68.05	1W5252	THRUST WASHER	1
EK3537 $1,637.60	1685248	IN-FRAME OVERHAUL SET	1

CATERPILLAR C15
PISTON CROWN OEM: 2250115. RECTANGULAR
OIL PAN GASKET. PREFIX: MBN.
456-5092 $6,809.19

Component	OEM	Description	Qty.
226-2049 $606.00	10R1503	CYLINDER SLEEVE	6
MB2848AL $56.41	1175975	MAIN BEARING SETS	7
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
TW583S $68.05	1W5252	THRUST WASHER	1
EK3537 $1,637.60	1685248	IN-FRAME OVERHAUL SET	1

Page 8
Heavy duty replacement engine parts
overhaul and in-frame engine kits+
CATERPILLAR C15 15.2L
PREFIX: 9NZ, 6NZ, 1LW, 2WS. PISTON CROWN
OEM: 1807352. CYLINDER KIT
OEM: 10R8616. SINGLE TURBO.
456-1078 $8,657.82

Component	OEM	Description	Qty.
226-1969 $547.94	0R8915	CYLINDER SLEEVE	6
CB1622P $34.58 AM	9Y7735	CONNECTING ROD BEARINGS	6
MB2848AL $56.41	1175975	MAIN BEARING SET	7
TW583S $68.05	1W5252	THRUST WASHER	1
HS54643-6 $1,039.65	1384611	CYLINDER HEAD GASKET SET	1
CS546431	1905978	CONVERSION GASKET SET	1
JV1700 $109.57	2024973	REAR MAIN SEAL SET	1
JV5104 $398.95	2341633	TIMING CASE SET	1

Page 9
CUMMINS 4B 3.9 L NATURALLY ASPIRATED
CPL: 591, 681, 721, 725, 843, 895, 1172, 1259, 1312,
1522, 1932. PISTON OEM: 3906223, 3802060
FPIFK4BT3923.
409-5003 $1,745.74

Component	OEM	Description	Qty.
225-3526 $123.11	3802060	PISTON ASSEMBLY	4
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	4
MS1718P $73.89	3802010	MAIN BEARING SET	1
HS4961 $372.06	3802015	CYLINDER HEAD GASKET SET	1
OS32172 $25.22	3900947	OIL PAN SET	1

Heavy duty OVERHAUL KIT.
409-1003 $2,261.94

Component	OEM	Description	Qty.
225-3526 $123.11	3802060	PISTON ASSEMBLY	4
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	4
MS1718P $73.89	3802010	MAIN BEARING SET	1
HS4961 $372.06	3802015	CYLINDER HEAD GASKET SET	1
CS4961 $362.35	3802375	CONVERSION GASKET SET	1

CYLINDER KIT OEM: 10R3304. PISTONLESS.
CPL: 1201, 1202, 1268, 1277, 1287, 1508, 1509, 1631,
1659, 2021, 2272. PISTON ASSEMBLY OEM: 3802160, 3802712
FPIFK4BT3912.
409-5012 $1,786.30

Component	OEM	Description	Qty.
225-3525 $127.48	3802160	PISTON ASSEMBLY	4
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	4
HS4961 $372.06	3802015	CYLINDER HEAD GASKET SET	1
MS1718P $73.89	3802010	MAIN BEARING SET	1
OS32172 $25.22	3900947	OIL PAN SET	1

Page 10
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS 4BT 3.9 L TURBOCHARGED
CPL: 1201, 1202, 1268, 1277, 1287, 1508, 1509, 1631,
1659, 2021, 2272. PISTON OEM: 3802160
HEAVY DUTY OVERHAUL KIT.
409-1012 $1,970.49

Component	OEM	Description	Qty.
225-3525 $127.48	3802160	PISTON ASSEMBLY	4
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	4
MS1718P $73.89	3802010	MAIN BEARING SET	1
HS4961 $372.06	3802015	CYLINDER HEAD GASKET SET	1

CUMMINS 4BT 3.9 L TURBOCHARGED
& AFTERCOOLED
CPL: 1173, 1278, 1520, 1521, 1525, 1526, 2377, 594,
595, 646, 696. PISTON ASSEMBLY OEM: 3802100, 3802711.
HEAVY DUTY OVERHAUL KIT.
FPIFK4BT3911.
409-5018

Component	OEM	Description	Qty.
225-3523 $155.01	3802100	PISTON ASSEMBLY	4
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	4
MS1718P $73.89	3802010	MAIN BEARING SET	1
HS4961 $372.06	3802015	CYLINDER HEAD GASKET SET	1
OS32172 $25.22	3900947	OIL PAN SET	1

CPL: 1173, 1278, 1520, 1521, 1525, 1526, 2377, 594,
595, 646, 696. PISTON OEM: 3802100, 3802711
FPIFK4BT3911.
409-1018 $2,573.65

Component	OEM	Description	Qty.
225-3523 $155.01	3802100	PISTON ASSEMBLY	4
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	4
MS1718P $73.89	3802010	MAIN BEARING SET	1
HS4961 $372.06	3802015	CYLINDER HEAD GASKET SET	1
CS4961 $362.35	3802375	CONVERSION GASKET SET	1

CUMMINS 6B 5.9L ISBe 12 VALVE (CHRYSLER)
CPL: 2998. PISTON ASSEMBLY OEM: 4089259, 4089140.
PISTON FP4089259, M4089259, 111542..
409-5032 $3,281.21

Component	OEM	Description	Qty.
225-3672 $224.58	4089140	PISTON ASSEMBLY	6
226-4490 $33.18	3900396	CYLINDER SLEEVE	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
MS2329P $123.11	4025224	MAIN BEARING SET	1
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1

Page 11
CUMMINS 6B 5.9L ISB235 ISB 24 VALVE
CPL: 2902, 2686. PISTON ASSEMBLY OEM:
3800781. PISTON OEM: 3946153
FPIFKISB68124V
409-5026 $2,905.79

Component	OEM	Description	Qty.
225-3355 $156.51	3800781	PISTON ASSEMBLY	6
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	6
HS54174-1 $362.41	3800853	CYLINDER HEAD GASKET SET	1
MS2328P $112.96	3802070	MAIN BEARING SET	1
OS32139 $39.62	05003694AC	OIL PAN SET	1

CPL: 2902, 2686. PISTON ASSEMBLY OEM:
3800781. PISTON OEM: 3946153
FPIFKISB68124V.
409-1026 $3,230.38

Component	OEM	Description	Qty.
225-3355 $156.51	3800781	PISTON ASSEMBLY	6
CB1413P $14.38 AM	3901170	CONNECTING ROD BEARINGS	6
HS54174-1 $362.41	3800853	CYLINDER HEAD GASKET SET	1
MS2328P $112.96	3802070	MAIN BEARING SET	1
CS54174 $219.23	.	CONVERSION GASKET SET	1

CUMMINS 6B 5.9L ISBe 12 VALVE (CHRYSLER)
CPL: 2998. PISTON ASSEMBLY OEM: 4089259,
4089140. PISTON FP4089259, M4089259, 111542..
409-5032 $3,281.21

Component	OEM	Description	Qty.
225-3672 $224.58	4089140	PISTON ASSEMBLY	6
226-4490 $33.18	3900396	CYLINDER SLEEVE	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
MS2329P $123.11	4025224	MAIN BEARING SET	1
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1

Page 12
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS 6B 5.9L ISB305 ISBe (CHRYSLER)
CPL: 2998. PISTON ASSEMBLY OEM: 4089259, 4089140
Heavy duty OVERHAUL KIT.
409-1032 $3,526.33

Component	OEM	Description	Qty.
225-3672 $224.58	4089140	PISTON ASSEMBLY	6
226-4490 $33.18	.	CYLINDER SLEEVE	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
CS54556 $262.21	05093229AA	CONVERSION GASKET SET	1
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1
MS2329P $123.11	4025224	MAIN BEARING SET	1

CUMMINS 6B 5.9L 24 VALVE ISB (CHRYSLER)
CPL: 2650, 1091, 1000, 8423, 8344. PISTON ASSEMBLY
OEM: 4089669. PISTON OEM: 3970192.
FPIFKISB66924V.
409-5033 $2,859.23

Component	OEM	Description	Qty.
225-3673 $168.14	4089669	PISTON ASSEMBLY	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1
MS2329P $123.11	4025224	MAIN BEARING SET	1
OS32278 $71.34	05086854AA	OIL PAN SET	1

Page 13
CUMMINS 6B 5.9L ISB32 (CHRYSLER)
CPL: 2650, 1091, 1000, 8423, 8344. PISTON
ASSEMBLY OEM: 4089669. PISTON OEM: 3970192.
FPIFKISB66924V.
409-1033 $3,244.88

Component	OEM	Description	Qty.
225-3673 $168.14	4089669	PISTON ASSEMBLY	6
226-4490 $33.18	3900396	CYLINDER SLEEVE	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
CS54556 $262.21	05093229AA	CONVERSION GASKET SET	1
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1
MS2329P $123.11	4025224	MAIN BEARING SET	1

CUMMINS 6B 6.7L ISB200 DODGE RAM 2500-5500 (PX6)
CPL: 2715, 2583, 3697. PISTON OEM: 4936946, 4938619, 5336103.
FPIFKISB66567L
789-1015 $3,891.60

Component	OEM	Description	Qty.
224-3732 $127.48	4936946	PISTON	6
42140 $260.87	4955366	PISTON RING SET	1
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
MS2328P $112.96	3802070	MAIN BEARING SET	1
HS54774-1 $454.50	4955354	CYLINDER HEAD GASKET SET	1
VS50543 $309.99	05179091AB	VALVE COVER GASKET SET	1
CS547741	4955355	CONVERSION GASKET SET	1

Page 14
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS 6B 5.9L ISB (CHRYSLER)
CPL: 8410. PISTON OEM: 3949807, 3958675.
789-1002

Component	OEM	Description	Qty.
224-3674 $150.74	3949807	PISTON	6
S42170 $49.14	3804947	PISTON RING SET	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
MS2328P $112.96	3802070	MAIN BEARING SET	1
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1
CS54556 $262.21	05093229AA	CONVERSION GASKET SET	1
SH1981-AM	3940059	CAMSHAFT BEARING	1

CUMMINS 6B 5.9L ISB, QSB (CHRYSLER)
PISTON OEM: 3965497, 3949808.
FPIFKISB65924V
789-1001

Component	OEM	Description	Qty.
224-3672 $211.57	3949808	PISTON	6
S42170 $49.14	3804947	PISTON RING SET	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
MS2328P $112.96	3802070	MAIN BEARING SET	1
HS54556 $387.88	05093228AB	CYLINDER HEAD GASKET SET	1
CS54556 $262.21	05093229AA	CONVERSION GASKET SET	1
SH1981-AM	3940059	CAMSHAFT BEARING	1

Page 15
CUMMINS 210 / 215 / 235 ISB
CPL: 2075, 2076, 2077, 2415, 2495, 2496, 2497, 2906,
2907, 8034, 8035. PISTON OEM: 3946051, 946052.
FPIFKISB63924V
789-1006 $3,782.86

Component	OEM	Description	Qty.
224-3354 $155.02	3946050	PISTON	6
S42170 $49.14	3804947	PISTON RING SET	6
CB1873AP $13.05	04429175AB	CONNECTING ROD BEARINGS	6
MS2328P $112.96	3802070	MAIN BEARING SET	1
HS54174-2 $375.10	00K05011933AB	CYLINDER HEAD GASKET SET	1
CS54174 $219.23	.	CONVERSION GASKET SET	1

CUMMINS 5.9L ISB
CPL: 102, 104, 151, 196, 1527, 1549, 1550, 1824, 1825,
1863, 1959. PISTON OEM: 3922572, 3922571, 3802490.
PISTON FP-3922571-WP
789-1003

Component	OEM	Description	Qty.
224-3520 $123.09	3922572	PISTON	6
S42221 $37.63	3938177	PISTON RING SET	6
CB1413P $14.38	3901170	CONNECTING ROD BEARINGS	6
MS2328P $112.96	3802070	MAIN BEARING SET	1
SH1404 $14.33	3901306	CAMSHAFT BEARING	1
HS4068 $197.06	3802025	CYLINDER HEAD GASKET SET	1
CS4068 $251.08	3802029	CONVERSION GASKET SET	1

Page 16
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS NT400 FORMULA, 14L
CPL: 449, 481, 482, 500, 510, 531, 1171, 1179, 1183, 1194,
1197, 1411. CYLINDER KIT OEM: 3801771. PISTON OEM:
3801773, 3051556. PISTON RINGS OEM: 3803471, 4081811
FP855N4
459-5024 $2,805.66

Component	OEM	Description	/Qty.
226-1745 $468.22	.	CYLINDER SLEEVE ASSEMBLY	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
CB1226P-AM	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1

CUMMINS NT855, NT400 14L TURBO CHARGED
& AFTERCOOLED
CPL: 250, 254, 266, 277, 294, 298, 306, 315, 320, 338,
353, 1205. PISTON OEM: 3051554.
CYLINDER KIT OEM: 3804351 NTC 290 BCI.
FP CYLINDER KIT OEM: FP3801776 $290.76
459-5017

Component	OEM	Description	Qty.
226-1771 $339.08	3801776	CYLINDER SLEEVE ASSEMBLY	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
CB1226P $30.29	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1

CPL: 675. CYLINDER KIT OEM: 3801797.
PISTON OEM: 3042318. CYLINDER KIT FP: FP-3801797.
FP855-PPDN-18
459-5036

Component	OEM	Description	Qty.
226-1880 $291.28	3801797	CYLINDER SLEEVE ASSEMBLY	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK35201	3801332	IN-FRAME OVERHAUL SET	1



Page 17
CUMMINS NT855, NT400 14L TURBOCHARGED
& AFTERCOOLED CONT'D
CPL: 449, 481, 482, 500, 891, 1171, 1183, 1194, 1197,
1350, 1381, 1557. CYLINDER KIT OEM: 3801823.
PISTON OEM: 3801819, 3048808.
FP855-PPDN
459-5052 $2,234.29

Component	OEM	Description	Qty.
226-1835 $331.83	2261835	CYLINDER SLEEVE ASSEMBLY	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1

CUMMINS NT855 BIG CAM TURBOCHARGED
& AFTERCOOLED
CPL: 1, 10, 11, 12, 101, 108, 109, 120, 123, 204, 1181.
PISTON OEM: 3095739, 3804414.
OVERHAUL KIT OEM: 3804514, 3803549.
FP855TT39
459-5010 $4,016.36

Component	OEM	Description	Qty.
226-1905 $326.06	3804444	CYLINDER SLEEVE ASSEMBLY	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1
MS1687P $166.66	3030216	MAIN BEARING SET	1

CPL: 1, 10, 11, 12, 101, 108, 109, 120, 123, 1181,
1204. PISTON OEM: 3051555.
FP855-N
459-5020 $2,849.16

Component	OEM	Description	Qty.
226-1772 $339.08	3801779	CYLINDER SLEEVE ASSEMBLY	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1
MS1687P $166.66	3030216	MAIN BEARING SET	1

1
1

Page 18
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS NT855 BIG CAM TURBOCHARGED
& AFTERCOOLED CONT'D
CPL: 1, 10, 11, 12, 101, 108, 109, 120, 123, 1181,
1204. PISTON OEM: 3051555.
FP855SP
459-5020NP $2,250.31

Component	OEM	Description	Qty.
226-4414 $81.06	183050	CYLINDER SLEEVE	6
S41888 $69.43	3014149	PISTON RING SET	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
EK35181	3804276	IN-FRAME OVERHAUL SET	1

CPL: 449, 481, 482, 500, 510, 531, 1171, 1179, 1183,
1194, 1197, 1411. PISTON OEM: 3051556, 3801773.
FP855N4
459-5023 $2,789.66

Component	OEM	Description	Qty.
226-1773 $465.35	3801780	CYLINDER SLEEVE ASSEMBLY	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1
MS1687P $166.66	3030216	MAIN BEARING SET	1

CPL: 10, 11, 12, 13, 144, 146, 147, 152, 1204, 1415,
1416. PISTON OEM: 3045948, 3801534.
FP855-PPDN-48
459-5038 $2,184.98

Component	OEM	Description	Qty.
226-1831 $324.70	3801817	CYLINDER SLEEVE ASSEMBLY	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
EK35181	3804276	IN-FRAME OVERHAUL SET	1

Page 19
CPL: 121, 471, 506, 529, 579, 581, 585, 612, 633,
636, 674, 743. PISTON OEM: 3042320, 3801535.
FP855-N-5
459-5042

Component	OEM	Description	Qty.
226-1770 $378.25	3801774	CYLINDER SLEEVE ASSEMBLY	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK35181	3804276	IN-FRAME OVERHAUL SET	1
MS1687P $166.66	3030216	MAIN BEARING SET	1

CPL: 838, 840, 1187, 1352. PISTON OEM: 3069212, 3803344.
FP855-PPDN-12
459-5230 $2,184.98

Component	OEM	Description	Qty.
226-1821 $323.29	3803346	CYLINDER SLEEVE ASSEMBLY	6
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK3523 $395.80	3349820	IN-FRAME OVERHAUL SET	1
MS1687P $166.66	3030216	MAIN BEARING SET	1

CUMMINS NT855 14LT NTC400 TURBOCHARGED
& AFTERCOOLED
CPL: 827, 1185, 1188, 1211. CYLINDER KIT OEM:
3801956. PISTON OEM: 3801954, 3052794.
FP855PPDN94
459-5272

Component	OEM	Description	Qty.
226-1841 $326.19	3801956	PISTON ASSEMBLY	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
CB1226P $30.29 AM	3150011	CONNECTING ROD BEARINGS	6
EK3523 $395.80	3349820	IN-FRAME OVERHAUL SET	1

Page 20
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS N14 CELECT PLUS TURBOCHARGED
& AFTERCOOLED
CPL: 1809, 1844, 1852, 1896, 1921, 1924, 1987, 2003,
2025, 2033, 2143, 2391, 2591. PISTON OEM: 3803741,
3087634. OVERHAUL KIT OEM: 4024880.
FPN14AR34
459-5443 $6,028.94

Component	OEM	Description	Qty.
226-2039 $708.86	3803742	CYLINDER SLEEVE ASSEMBLY	6
CB1616P $20.21 AM	3055145	CONNECTING ROD BEARINGS	6
MS1687P $166.66	3030216	CONNECTING ROD BEARINGS	1
EK3539 $570.67	4089372	IN-FRAME OVERHAUL SET	1

CUMMINS N14 TURBOCHARGED
& AFTERCOOLED
CPL:1809, 1844, 1852, 1896, 1921, 1924, 1987, 2003,
2025, 2033, 2143. PISTON OEM: 3803741.
OVERHAUL KIT OEM: 4024880.
FPN14AR34SP
459-5443NP $2,271.95

Component	OEM	Description	Qty.
226-4414 $81.06	183050	CYLINDER SLEEVE	6
S41887 $127.48	3803358	PISTON RING SET	6
CB1616P $20.21 AM	3055145	CONNECTING ROD BEARINGS	6
MS1687P $166.66	3030216	MAIN BEARING SET	1
EK3539 $570.67	4089372	IN-FRAME OVERHAUL SET	1

CPL: 1374, 1380, 1395, 1405, 1507, 1529, 1530, 1532,
1607, 1652, 1878. PISTON OEM: 3803758, 3081269,
3803429. OVERHAUL KIT OEM: 4024878
FPN14-PPDN69
459-5187 $4,763.05

Component	OEM	Description	Qty.
226-1903 $517.53	3803759	CYLINDER SLEEVE ASSEMBLY	6
CB1616P $20.21 AM	3055145	CONNECTING ROD BEARINGS	6
MS1687P $166.66	3030216	CONNECTING ROD BEARINGS	1
HS5858AH $481.61	3803444	CYLINDER HEAD GASKET SET	1
OS21996 $109.61	178788	OIL PAN SET	1

Page 21
CUMMINS N14 MECHANICAL
OVERHAUL KIT OEM: 4024877.
CYLINDER KIT OEM: 3803755.
PISTON OEM: 3081268.
FPN14-PPDN68
459-5188

Component	OEM	Description	Qty.
226-1911 $331.95	3803755	CYLINDER SLEEVE ASSEMBLY	6
MS1687P $166.66	3030216	CONNECTING ROD BEARINGS	1
CB1616P $20.21 AM	3055145	MAIN BEARING SET	1
HS54123 $441.88	3803375	CYLINDER HEAD GASKET SET	1
OS21996 $109.61	178788	OIL PAN SET	1

CUMMINS L10 SUITABLE FOR STC,
CELECT NARROW L10
CPL: 1164, 1198, 1208, 1234, 1359, 1378, 1412, 1413,
1414, 1429, 1443. PISTON OEM: 3803965, 3044448.
FPIFKL-1048
459-5414 $3,555.24

Component	OEM	Description	Qty.
226-1851 $256.49	.	CYLINDER SLEEVE ASSEMBLY	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
OS32209 $38.08	3882433	OIL PAN SET	1
HS54146-1 $308.32	3801141	CYLINDER HEAD GASKET SET	1

CPL: 1223, 1224, 1225, 1226, 1346, 1441, 1442, 1619,
1620, 1621, 1622. PISTON OEM: 3803967, 3803626, 3055622.
FPIFKL-1022
459-5417 $3,400.19

Component	OEM	Description	Qty.
226-1852 $311.55	3800800	CYLINDER SLEEVE ASSEMBLY	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
HS54146-1 $308.32	3801141	CYLINDER HEAD GASKET SET	1
MS1716P $204.32	4025125	MAIN BEARING SET	1

Page 22
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS L10
CPL: 1164, 1198, 1208, 1234, 1359, 1378, 1412, 1413,
1414, 1429, 1443. PISTON OEM: 3803965, 3044448.
FPIFKL-1048
459-5431 $3,597.39

Component	OEM	Description	Qty.
226-1851 $256.49	3800801	CYLINDER SLEEVE ASSEMBLY	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
OS32209 $38.08	3882433	OIL PAN SET	1
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1

CPL: 1223, 1224, 1225, 1226, 1346, 1441, 1442, 1619,
1620, 1621, 1622. PISTON OEM: 3055622, 3803967, 3803626.
FPIFKL-1022
459-5434 $1,899.30

Component	OEM	Description	Qty.
226-1852 $311.55	3800800	CYLINDER SLEEVE ASSEMBLY	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32209 $38.08	3882433	OIL PAN SET	1

Page 23
CUMMINS M11, ISM, QSM/L10
PISTONLESS. OVERHAUL KIT OEM: 4090008.
PISTON RINGS OEM: 3803705, 3803977.
CONNECTING ROD BEARING OEM: 3016760.
FLANGED THRUST WASHER.
459-5508 $3,085.47

Component	OEM	Description	Qty.
224-3820X $69.41	3081334	PISTON SKIRT	6
226-4546 $130.36	3034816	CYLINDER SLEEVE	6
S41934 $79.55	3803705	PISTON RING SET	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
MS2318P $236.23	4025120	MAIN BEARING SET	1
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

CUMMINS M11, ISM, QSM
PISTONLESS. OVERHAUL KIT OEM: 4090008.
PISTON RINGS OEM: 3803705, 3803977.
CONNECTING ROD BEARING OEM: 3016760.
FLANGED THRUST WASHER.
ISM140-017
459-5511 $1,362.94

Component	OEM	Description	Qty.
226-4546 $130.36	3034816	CYLINDER SLEEVE	6
S41934 $79.55	3803705	PISTON RING SET	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
MS2318P $236.23	4025120	MAIN BEARING SET	1
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

Page 24
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS M11, ISM, QSM MECHANICAL
PISTON CROWN OEM: 3103753.
FPIF4089865A
459-5542 $2,921.53

Component	OEM	Description	Qty.
226-2153 $524.80	CK3103752	CYLINDER SLEEVE ASSEMBLY	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
MS2318P $236.23	4025120	MAIN BEARING SET	1
OS32219 $61.80	3401290	OIL PAN SET	1
CB1382P $18.65	3016760	CONNECTING ROD BEARINGS	6

CPL: 1855, 1827, 1828, 1829, 1830, 1841, 1855, 1856,
1857, 1875, 1885, 2037, 2036.
PISTON CROWN OEM: 3896030, 3896031, 4004757,
4059900, 4059902, 4059902.
CYLINDER KIT OEM: 4025162.
OVERHAUL KIT OEM: 4025297.
MAIN BEARING OEM: 4025125.
FPIFKM11EA
459-5543 $3,508.94

Component	OEM	Description	Qty.
226-2154 $530.54	4025162	CYLINDER SLEEVE ASSEMBLY	6
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
MB3979WL $9.48	4926017	THRUST WASHERS	2
MS1716P $204.32	4025125	MAIN BEARING SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

Page 25
CUMMINS M11, MECHANICAL
CPL: 1855, 1827, 1828, 1829, 1830, 1841, 1855, 1856,
1857, 1875, 1885, 2037, 2036.
PISTON CROWN OEM: 3896030, 3896031, 4004757,
4059900, 4059902, 4059902.
CYLINDER KIT OEM: 4025162.
OVERHAUL KIT OEM: 4025297. MAIN BEARING OEM: 4025125.
FPIFKM11EA
459-5543NP $2,483.68

Component	OEM	Description	Qty.
226-4546 $130.36	3034816	CYLINDER SLEEVE	6
S41934 $79.55	3803705	PISTON RING SET	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
CB1382P $18.65 AM	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1
MB3979WL $9.48	4926017	THRUST WASHERS	2

CUMMINS M11, ISM, QSM
CPL: 2830. CYLINDER KIT OEM: 4024940.
PISTON OEM: 5469001, 4022532. NARROW BEARING.
FPIF4024940A
459-5545

Component	OEM	Description	Qty.
226-2156 $501.51	4024940	CYLINDER SLEEVE ASSEMBLY	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
CB1382P $18.65	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

Page 26
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS M11, ISM, QSM 10.8L
CYLINDER KIT OEM: 4025160, 3800769.
PISTON ASSEMBLY OEM: 4025159.
PISTON CROWN OEM: 4059904, 5469046.
459-5546

Component	OEM	Description	Qty.
226-2157	4025160	CYLINDER SLEEVE ASSEMBLY	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
CB1382P $18.65	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

CUMMINS ISM
CPL: 2199, 2200, 2350, 2376, 2562, 2563, 2576, 2607,
2608, 2610, 2611, 2612, 2614, 2615.
OVERHAUL KIT OEM: 4090008.
PISTON ASSEMBLY OEM: 4025158.
CYLINDER KIT OEM: 4025164.
FPIFKISMA58
459-5547 $3,397.18

Component	OEM	Description	Qty.
226-2158 $503.02	4025164	CYLINDER SLEEVE ASSEMBLY	6
MS1716P $204.32	4025125	MAIN BEARING SET	1
CB1382P $18.65	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

Page 27
CUMMINS ISM 10.8L
CPL: 2725, 2727, 2728, 2729,2730, 2731, 2800, 3280,
3281, 3330, 8271, 8272, 8272, 8273, 8274, 8309, 8377,
8427, 8503, 8504, 8506, 8556, 8557, 8558, 8559, 8560,
8561, 8562, 8563, 8572. O
VERHAUL KIT OEM: 4918787.
PISTON ASSEMBLY OEM: 4089386.
PISTON CROWN OEM: 3102807. MODERN EGR.
ISM102-017
459-5548 $3,645.21

Component	OEM	Description	Qty.
226-2159 $553.83	CK3102808	CYLINDER SLEEVE ASSEMBLY	6
MS2318P $236.23	4025120	MAIN BEARING SET	1
CB1382P $18.65	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

WITHOUT PISTONS
CPL: 2725, 2727, 2728, 2729,2730, 2731, 2800, 3280,
3281, 3330, 8271, 8272, 8272, 8273, 8274, 8309, 8377,
8427, 8503, 8504, 8506, 8556, 8557, 8558, 8559, 8560,
8561, 8562, 8563, 8572.
OVERHAUL KIT OEM: 4918787.
PISTON ASSEMBLY OEM: 4089386.
PISTON CROWN OEM: 3102807. MODERN EGR
ISM102-017
459-5548NP $2,756.36

Component	OEM	Description	Qty.
226-4616 $128.86	4089388	CYLINDER SLEEVE	6
S42421 $50.65	4089385	PISTON RING SET	6
MS2318P $236.23	4025120	MAIN BEARING SET	1
CB1382P $18.65	3016760	CONNECTING ROD BEARINGS	6
HS54146-2 $371.87	4025157	CYLINDER HEAD GASKET SET	1
OS32219 $61.80	3401290	OIL PAN SET	1

Page 28
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS 6C 8.3 ISC, QSC SERIES C
CPL: 602, 603, 753, 819, 828, 829, 942, 955, 985,
1248, 1274, 1275, 1281, 1356, 1464, 1603, 1616.
PISTON OEM: 3923163.
FP6C8300
459-5450 $3,687.25

Component	OEM	Description	Qty.
226-1948 $218.82	3802400	CYLINDER SLEEVE ASSEMBLY	6
MS1740P $259.38	3802210	MAIN BEARING SET	6
CB1409P $14.33	3901430	CONNECTING ROD BEARINGS	1
HS54126 $309.84	3800750	CYLINDER HEAD GASKET SET	1
OS32205 $47.49	3906611	OIL PAN SET	1

CPL: 604, 605, 754, 755, 830, 831, 890, 892, 893, 959,
982, 984, 1212, 1222, 1269, 1270, 1273, 1321, 1377,
1419, 1539, 1547, 1604, 1612, 1633, 1639, 1804,
1826, 2380. PISTON OEM: 3923164, 3914368.
FP6C8301
459-5491 $3,748.08

Component	OEM	Description	Qty.
226-4496 $111.59	3907792	CYLINDER SLEEVE	6
224-3326 $159.40	3923164	PISTON	6
S41677 $55.03	3802429	PISTON RING SET	6
MS1740P $259.38	3802210	MAIN BEARING SET	1
CB1409P $14.33	3901430	CONNECTING ROD BEARINGS	1
HS54126 $309.84	3800750	CYLINDER HEAD GASKET SET	1
OS32205 $47.49	3906611	OIL PAN SET	1

Page 29
CUMMINS ISC 315 PX8 PACCAR
IN-FRAME KIT WITHOUT CYLINDER HEAD GASKET
CPL: 8159, 8220, 8430, 8494, 8692, 8697, 8698,
8728, 8729, 8730. PISTON OEM: 4933120.
ISC103-001
459-5550NG $3,401.56

Component	OEM	Description	Qty.
224-3786 $165.14	4933120	PISTON	6
226-4566 $147.74	3800328	CYLINDER SLEEVE	6
S42163 $50.65	4089644	PISTON RING SET	6
MS1740P $259.38	3802210	MAIN BEARING SET	1
CB1409P $14.33 AM	3901430	CONNECTING ROD BEARINGS	6
OS32205 $47.49	3906611	OIL PAN SET	1

CUMMINS ISX
150MM NON APR CYLINDER LINER
WITH PINK O-RING. DUAL CAMSHAFT.
PISTONLESS, NON EGR.
CONNECTING ROD BEARING OEM: 4925971, 4089405, 4059447.
HEAD GASKET SET OEM: 4025300, 4352144, 4955595.
FPIFKISXSP, ISX141-113
4595497

Component	OEM	Description	Qty.
226-4635 $140.49	.	CYLINDER SLEEVE	6
S42153 $114.46	2881682	PISTON RING SET	6
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
HS54775-1 $600.96	4352144	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 30
Heavy duty replacement engine parts
overhaul and in-frame engine kits
CUMMINS ISX CONT'D
150MM NON APR CYLINDER LINER
WITH PINK O-RING. DUAL CAMSHAFT.
PISTONLESS, EGR.
CONNECTING ROD BEARING OEM: 4925971, 4089405, 4059447.
FPIFKISXSPEGR
459-5498 $4,233.86

Component	OEM	Description	Qty.
226-4635 $140.49	4309389	CYLINDER SLEEVE	6
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-2 $783.79	4352145	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
OS32376 $249.53	3679943	OIL PAN SET	1
S42153 $114.46	2881682	PISTON RING SET	6

150MM APR CYLINDER LINER
WITH PINK O-RING. DUAL CAMSHAFT.
NON EGR. CPL: 1771, 2440, 2627, 2628, 2629, 2631,
2632, 2803, 2814, 2933, 2934, 8046, 8047, 8048, 8083,
8242, 8243, 8244, 8255, 8257, 8258.
PISTON OEM: 2882635. OVERHAUL KIT OEM: 4376171.
FPIFKISX1535150
459-5512 $5,067.63

Component	OEM	Description	Qty.
225-3971 $430.56	2881873	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
6018151	.	OIL FILTER BYPASS VALVE	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-1 $600.96	4025300	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 31

150MM APR CYLINDER LINER
WITH PINK O-RING. DUAL CAMSHAFT.
CPL: 927, 1434, 2733, 2734, 2919, 2965, 3167, 3458,
3774, 8125, 8281, 8282, 8283, 8284, 8285, 8286, 8517,
8518, 8519, 8521, 8522, 8660.
PISTON OEM: 4367173.
OVERHAUL KIT OEM: 4376174. S
TRAIGHT-CUT CONNECTING ROD BEARING
459-5516 $5,077.77

Component	OEM	Description	Qty.
225-3973 $526.29	4376244	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-2 $783.79	4352145	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1
6018151		OIL FILTER BYPASS VALVE	1

150MM APR CYLINDER LINER
WITH PINK O-RING. DUAL CAMSHAFT. EGR.
CPL: 1437, 2732, 3229, 3459, 3775, 8287, 8288, 8520, 8523, 8550.
PISTON OEM: 2882630.
OVERHAUL KIT OEM: 4376175, 5693815.
FPIFKISX1530150SMB
459-5518 $5,067.63

Component	OEM	Description	Qty.
225-3969 $526.29	4367161	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
6018151	.	OIL FILTER BYPASS VALVE	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-2 $783.79	4352145	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 32
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
CUMMINS ISX CONT'D
152MM NON APR CYLINDER LINER WITH BLUE O-RING.
DUAL CAMSHAFT. NON EGR STRAIGHT-CUT
CONNECTING ROD BEARING
459-55501NP $3,933.78

Component	OEM	Description	Qty.
S42153 $114.46	2881682	PISTON RING SET	6
226-4638 $150.66	2881719	CYLINDER SLEEVE	6
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
HS54775-1 $600.96	4025300	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	6

152MM APR CYLINDER LINER
WITH BLUE O-RING. DUAL CAMSHAFT.
NON EGR. CPL: 1771, 2440, 2627, 2628, 2629, 2631,
2632, 2803, 2814, 2933, 2934, 8046, 8047, 8048, 8083,
8242, 8243, 8244, 8255, 8257, 8258.
PISTON OEM: 2882635.
OVERHAUL KIT OEM: 4376167, 4376429.
STRAIGHT-CUT CONNECTING ROD BEARING
459-5513 $5,067.63

Component	OEM	Description	Qty.
225-3971 $430.56	2881873	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
HS54775-1 $600.96	4025300	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1
6018151	.	OIL FILTER BYPASS VALVE	1

Page 33
152MM NON APR CYLINDER LINER
WITH BLUE O-RING. DUAL CAMSHAFT.
PISTONLESS, NON EGR.
CONNECTING ROD BEARING OEM: 2882087.
FRACTURED ROD
459-55502NP $4,001.94

Component	OEM	Description	Qty.
226-4638 $150.66	2881719	CYLINDER SLEEVE	6
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
S42153 $114.46	2881682	PISTON RING SET	6
HS54775-1 $600.96	4025300	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

152MM APR CYLINDER LINER
WITH BLUE O-RING. NON EGR.
CPL: 1771, 2440, 2627, 2628, 2629, 2631, 2632, 2803,
2814, 2933, 2934, 8046, 8047, 8048, 8083, 8242, 8243,
8244, 8255, 8257, 8258.
PISTON OEM: 2882635.
OVERHAUL KIT OEM: 4376167, 4376429.
STRAIGHT-CUT CONNECTING ROD BEARING
459-1513 $9,169.63

Component	OEM	Description	Qty.
225-3971 $430.56	2881873	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
6018151	.	OIL FILTER BYPASS VALVE	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
CS547751	3102234	CONVERSION GASKET SET	1
HS54775-1 $600.96	4025300	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1

Page 34
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
CUMMINS ISX CONT'D
152MM NON APR CYLINDER LINER
WITH BLUE O-RING. DUAL CAMSHAFT.
PISTONLESS, EGR. STRAIGHT-CUT
CONNECTING ROD BEARING
459-5550NP $4,364.37

Component	OEM	Description	Qty.
226-4638 $150.66	2881719	CYLINDER SLEEVE	6
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
S42153 $114.46	2881682	PISTON RING SET	6
HS54775-2 $783.79	4352145	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

152MM APR CYLINDER LINER WITH BLUE O-RING.
DUAL CAMSHAFT. EGR.
CPL: 1437, 2732, 3229, 3459, 3775, 8287, 8288, 8520, 8523, 8550.
PISTON OEM: 2882630.
OVERHAUL KIT OEM: 5405988.
FPIFKISX1530152SMB
459-5519 $4,168.53

Component	OEM	Description	Qty.
225-3969 $526.29	4367161	PISTON ASSEMBLY	6
226-4643 $168.03	3685235	CYLINDER SLEEVE	6
6018151	.	OIL FILTER BYPASS VALVE	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-2 $783.79	4352145	CYLINDER HEAD GASKET SET	1
MS2297P $315.98	3800298	MAIN BEARING SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 35
152MM APR CYLINDER LINER WITH BLUE O-RING.
DUAL CAMSHAFT.
CPL: 927, 1434, 2733, 2734, 2919, 2965, 3167, 3458,
3774, 8125, 8281, 8282, 8283, 8284, 8285, 8286, 8517,
8518, 8519, 8521, 8522, 8660.
PISTON OEM: 4367173.
OVERHAUL KIT OEM: 4376174.
STRAIGHT-CUT CONNECTING ROD BEARING
459-5517 $4,167.16

Component	OEM	Description	Qty.
225-3973 $526.29	4376244	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-2 $783.79	4352145	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

CUMMINS ISX15 15.0L
150MM APR CYLINDER LINER WITH PINK O-RING.
SINGLE CAMSHAFT.
CPL: 3348, 3349, 3376, 3490, 3491, 3687, 3688.
PISTON OEM: 3688099.
PISTON RINGS OEM: 4376565.
OVERHAUL KIT OEM: 5579450, 5473065, 4376177.
CONNECTING ROD BEARINGS OEM: 4925971, 4089405, 4059447.
STRAIGHT-CUT CONNECTING ROD BEARING
459-5521 $4,615.15

Component	OEM	Description	Qty.
225-3981 $845.28	2881758	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 36
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
CUMMINS ISX15 15.0L CONT'D
150MM APR CYLINDER LINER WITH PINK O-RING.
SINGLE CAMSHAFT
CPL: 3348, 3349, 3376, 3490, 3491, 3687, 3688.
PISTON OEM: 3688099.
PISTON RINGS OEM: 4376565.
OVERHAUL KIT OEM: 5579450, 5473065, 4376177.
CONNECTING ROD BEARINGS OEM: 2882087..
FRACTURED ROD.
459-55211

Component	OEM	Description	Qty.
225-3981 $845.28	2881758	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

150MM APR CYLINDER LINER WITH PINK O-RING.
SINGLE CAMSHAFT
CPL: 3350, 3356, 3606, 3765, 3766, 3794, 3797,
3938, 3939, 4584, 4585, 4587, 4588.
PISTON OEM: 3688100.
OVERHAUL KIT OEM: 5579454, 5473069, 4376178.
STRAIGHT-CUT CONNECTING ROD BEARING.
459-5523 $4,612.39

Component	OEM	Description	Qty.
225-3982 $851.02	4376567	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 37
150MM APR CYLINDER LINER WITH PINK O-RING.
SINGLE CAMSHAFT.
CPL: 3350, 3356, 3606, 3765, 3766, 3794, 3797, 3938,
3939, 4584, 4585, 4587, 4588.
PISTON OEM: 3688100.
OVERHAUL KIT OEM: 5579454, 5473069, 4376178.
CONNECTING ROD BEARING OEM: 2882087.
FRACTURED ROD
459-55231

Component	OEM	Description	Qty.
225-3982 $851.02	4376567	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

150MM APR CYLINDER LINER
WITH PINK O-RING. SINGLE CAMSHAFT.
CPL: 3657, 3719, 3724, 3937, 4583, 4586.
PISTON RINGS OEM: 2881756.
OVERHAUL KIT OEM: 4376179, 5579460, 5473074.
PISTON OEM: 3687897.
CONNECTING ROD BEARING OEM: 4925971, 4089405.
STRAIGHT-CUT CONNECTING ROD BEARING
459-5525 $5,385.10

Component	OEM	Description	Qty.
225-3980 $859.65	4376566	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 38
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
CUMMINS ISX15 15.0L CONT'D
150MM APR CYLINDER LINER WITH PINK O-RING.
SINGLE CAMSHAFT.
CPL: 3657, 3719, 3724, 3937, 4583, 4586.
PISTON RINGS OEM: 2881756.
OVERHAUL KIT OEM: 4376179, 5579460, 5473074.
PISTON OEM: 3687897.
CONNECTING ROD BEARING OEM: 2882087.
FRACTURED ROD.
459-55251

Component	OEM	Description	Qty.
225-3980 $859.65	4376566	PISTON ASSEMBLY	6
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

150MM APR CYLINDER LINER WITH PINK O-RING.
SINGLE CAMSHAFT.
PISTONLESS. HEAD GASKET SET OEM: 2881767,
4352146, 4376104.
PISTON RINGS OEM: 4376565, 5405718.
FRACTURED ROD.
459-55521NP $4,481.86

Component	OEM	Description	Qty.
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
S42416 $118.84	5405718	PISTON RING SET	6
MS2297P $315.98	3800298	MAIN BEARING SETS	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 39
150MM APR CYLINDER LINER
WITH PINK O-RING. SINGLE CAMSHAFT.
PISTONLESS. HEAD GASKET SET OEM: 2881767,
4352146, 4376104.
PISTON RINGS OEM: 4376565, 5405718.
STRAIGHT-CUT CONNECTING ROD BEARING.
459-5552NP $4,413.67

Component	OEM	Description	Qty.
226-4641 $204.32	3690557	CYLINDER SLEEVE	6
S42416 $118.84	5405718	PISTON RING SET	6
MS2297P $315.98	3800298	MAIN BEARING SETS	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

152MM APR CYLINDER LINER
WITH BLUE O-RING. SINGLE CAMSHAFT.
CPL: 3348, 3349, 3376, 3490, 3491, 3687, 3688.
PISTON OEM: 3688099. PISTON RINGS OEM: 4376565.
OVERHAUL KIT OEM: 5579451, 5473066, 4376427.
CONNECTING ROD BEARINGS OEM: 4925971,
4089405, 4059447.
STRAIGHT-CUT CONNECTING ROD BEARING.
459-5522 $4,680.47

Component	OEM	Description	Qty.
225-3981 $845.28	2881758	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 40
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
CUMMINS ISX15 15.0L CONT'D
152MM APR CYLINDER LINER
WITH BLUE O-RING. SINGLE CAMSHAFT.
CPL: 3348, 3349, 3376, 3490, 3491, 3687, 3688.
PISTON OEM: 3688099. PISTON RINGS OEM: 4376565.
OVERHAUL KIT OEM: 5579451, 5473066, 4376427.
CONNECTING ROD BEARINGS OEM: 2882087.
FRACTURED ROD
459-55221

Component	OEM	Description	Qty.
225-3981 $845.28	2881758	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

152MM APR CYLINDER LINER
WITH BLUE O-RING. SINGLE CAMSHAFT.
CPL: 3350, 3356, 3606, 3765, 3766, 3794,
3797, 3938, 3939, 4584, 4585, 4587, 4588.
PISTON OEM: 3688100.
OVERHAUL KIT OEM: 5579455, 5473070, 5405987.
STRAIGHT-CUT CONNECTING ROD BEARING
459-5524 $4,678.96

Component	OEM	Description	Qty.
225-3982 $851.02	4376567	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 41
152MM APR CYLINDER LINER WITH BLUE O-RING.
SINGLE CAMSHAFT.
CPL: 3350, 3356, 3606, 3765, 3766, 3794, 3
797, 3938, 3939, 4584, 4585, 4587, 4588.
PISTON OEM: 3688100.
OVERHAUL KIT OEM: 5579455, 5473070, 5405987.
CONNECTING ROD BEARING OEM: 2882087. FRACTURED ROD
459-55241

Component	OEM	Description	Qty.
225-3982 $851.02	4376567	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

152MM APR CYLINDER LINER WITH BLUE O-RING.
SINGLE CAMSHAFT.
CPL: 3657, 3719, 3724, 3937, 4583, 4586.
PISTON RINGS OEM: 2881756.
OVERHAUL KIT OEM: 5405986, 5579461, 5473075.
PISTON OEM: 3687897.
CONNECTING ROD BEARING OEM: 4925971, 4089405, 4059447.
STRAIGHT-CUT CONNECTING ROD BEARING.
459-5526 $5,385.10

Component	OEM	Description	Qty.
225-3980 $859.65	4376566	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1908P $33.22	4089405	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 42
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
CUMMINS ISX15 15.0L CONT'D
152MM APR CYLINDER LINER
WITH BLUE O-RING. SINGLE CAMSHAFT.
CPL: 3657, 3719, 3724, 3937, 4583, 4586.
PISTON RINGS OEM: 2881756.
OVERHAUL KIT OEM: 5405986, 5579461, 5473075.
PISTON OEM: 3687897.
CONNECTING ROD BEARING OEM: 2882087.
FRACTURED ROD.
459-55261

Component	OEM	Description	Qty.
225-3980 $859.65	4376566	PISTON ASSEMBLY	6
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
MS2297P $315.98	3800298	MAIN BEARING SET	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1

152MM APR CYLINDER LINER
WITH BLUE O-RING. SINGLE CAMSHAFT.
PISTONLESS. HEAD GASKET SET OEM: 2881767, 4352146, 4376104.
PISTON RINGS OEM: 4376565, 5405718.
STRAIGHT-CUT CONNECTING ROD BEARING.
459-5553NP $4,544.20

Component	OEM	Description	Qty.
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
S42416 $118.84	5405718	PISTON RING SET	6
MS2297P $315.98	3800298	MAIN BEARING SETS	1
CB1908P $33.22	4059447	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 43
152MM APR CYLINDER LINER
WITH BLUE O-RING. SINGLE CAMSHAFT.
HEAD GASKET SET OEM: 2881767, 4352146, 4376104.
PISTON RINGS OEM: 4376565, 5405718.
FRACTURED ROD.
459-55531NP $6,049.34

Component	OEM	Description	Qty.
226-4643 $168.03	4373362	CYLINDER SLEEVE	6
S42416 $118.84	5405718	PISTON RING SET	6
MS2297P $315.98	3800298	MAIN BEARING SETS	1
CB1994P $37.57	2882087	CONNECTING ROD BEARINGS	6
HS54775-3 $925.17	4376104	CYLINDER HEAD GASKET SET	1
OS32376 $249.53	3679943	OIL PAN SET	1

Page 44
Heavy duty replacement engine parts -
overhaul and in-frame engine kits
DETROIT DIESEL SERIES 60 11.1L, 12.7L DDEC III
OVERHAUL KIT OEM: 23532565.
CYLINDER KIT OEM: 23532555, 23523951.
NARROW BEARING
FPS6090
468-5128 $5,799.94

Component	OEM	Description	Qty.
226-1933 $869.93	23523951	CYLINDER SLEEVE ASSEMBLY	6
CB1792P $43.38	23515581	CONNECTING ROD BEARINGS	6
MS2093P $295.67		MAIN BEARING SET	1
TW600S $34.70	8929085	THRUST WASHER	1
SH1986-AM	8929690	CAMSHAFT BEARING	7
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
VS50278 $61.80	23516322	VALVE COVER GASKET SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
GS33448 $17.30	23511870	INJECTOR O-RINGS	6
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1

OVERHAUL KIT OEM: 23532565.
REFERENCE CYLINDER KIT OEM: 23532555.
WIDE BEARING.
FPS6055, S60102-001
468-5129 $7,774.78

Component	OEM	Description	Qty.
226-1933 $869.93	23523951	CYLINDER SLEEVE ASSEMBLY	6
CB1792P $43.38	23515581	CONNECTING ROD BEARINGS	6
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
MS2093P $295.67	.	MAIN BEARING SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
TW600S $34.70	8929085	THRUST WASHER	1

Page 45
OVERHAUL KIT OEM: 23532565.
REFERENCE CYLINDER KIT OEM: 23532555.
WIDE BEARING
FPS60SP47
468-5129NP $2,643.23

Component	OEM	Description	Qty.
226-4636 $260.88	23531249	CYLINDER SLEEVE	6
CB1792P $43.38	23515581	CONNECTING ROD BEARINGS	6
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
MS2093P $295.67	.	MAIN BEARING SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
S41891 $63.67	23503747	PISTON RING SET 2.5MM	6
TW600S $34.70	8929085	THRUST WASHER	1

OVERHAUL KIT OEM: 23532565.
REFERENCE CYLINDER KIT OEM: 23532555.
WIDE BEARING.
FPS60SP47
468-1129NP $3,475.53

Component	OEM	Description	Qty.
226-4636 $260.88	23531249	CYLINDER SLEEVE	6
CB1792P $43.38	23515581	CONNECTING ROD BEARINGS	6
FS54157 $397.42	23532332	FULL GASKET KIT	1
MS2093P $295.67	.	MAIN BEARING SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
S41891 $63.67	23503747	PISTON RING SET 2.5MM	6
TW600S $34.70	8929085	THRUST WASHER	1

Page 46
Heavy duty replacement engine parts
overhaul and in-frame engine kits
DETROIT DIESEL SERIES 60 12.7L DDEC IV
OVERHAUL KIT OEM: 23532577.
CYLINDER KIT OEM: 23530669, 23532554.
PISTON RINGS 3MM. PISTON OEM: 23530668, 23532552.
FPS6054P, S60106-0015
468-5097 $6,903.39

Component	OEM	Description	Qty.
226-2106 $465.23	23530669	CYLINDER SLEEVE ASSEMBLY	6
CB1836P $36.06 AM	.	CONNECTING ROD BEARINGS	6
MS2093P $295.67	.	MAIN BEARING SET	1
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
TW600S $34.70	8929085	THRUST WASHER	1

OVERHAUL KIT OEM: 23532577.
CYLINDER KIT OEM: 23530669, 23532554.
PISTON RINGS 3MM.
FPS60PSP
468-5097NP $3,452.36

Component	OEM	Description	Qty.
226-4636 $260.88	23531249	CYLINDER SLEEVE	6
S42303 $96.95	23531251	PISTON RING SET 3MM	6
CB1836P $36.06 AM	.	CONNECTING ROD BEARINGS	6
MS2093P $295.67	.	MAIN BEARING SET	1
TW600S $34.70	8929085	THRUST WASHER	1
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
OS32204 $57.03	8929102	OIL PAN SET	1

Page 47
OVERHAUL KIT OEM: 23532577.
CYLINDER KIT OEM: 23530669, 23532554.
PISTON RINGS 3MM.
FPS6054P, S60106-001
468-1097 $6,649.61

Component	OEM	Description	Qty.
226-2106 $465.23	23530669	CYLINDER SLEEVE ASSEMBLY	6
CB1836P $36.06 AM	.	CONNECTING ROD BEARINGS	6
FS54157 $397.42	23532332	FULL GASKET KIT	1
MS2093P $295.67	.	MAIN BEARING SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
TW600S $34.70	8929085	THRUST WASHER	1

DETROIT DIESEL SERIES 60 14.0L DDEC V
ARTICULATED PISTON. OVERHAUL KIT OEM: 23537081.
REFERENCE CYLINDER KIT OEM: 23530665,
PISTON OEM: 23530664.
PISTON RINGS OEM: 23531252.
FPIFKS6014L65
468-5110 $7,260.05

Component	OEM	Description	Qty.
226-2045 $610.39	23530665	CYLINDER SLEEVE ASSEMBLY	6
CB1902P $25.93 AM	23526141	CONNECTING ROD BEARINGS	6
MS2310P $210.19	.	MAIN BEARING SET	1
TW696S $112.96	23530554	THRUST WASHER	1
OS32382 $61.82	23505992	OIL PAN SET	1

Page 48
Heavy duty replacement engine parts
overhaul and in-frame engine kits
DETROIT DIESEL SERIES 60 14.0L DDEC V CONT'D
PISTONLESS. OVERHAUL KIT OEM: 23537081.
REFERENCE CYLINDER KIT OEM: 23530665,
REFERENCE PISTON OEM: 23530664.
PISTON RINGS OEM: 23531252.
FPIFKS6014LSP
468-5110NP $3,881.46

Component	OEM	Description	Qty.
226-4632 $127.48	23535511	CYLINDER SLEEVE	6
CB1902P $25.93 AM	23526141	CONNECTING ROD BEARINGS	6
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
MS2310P $210.19	.	MAIN BEARING SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
S42133 $98.54	23531252	PISTON RING SET	6
TW696S $112.96	23530554	THRUST WASHER	1

MONOTHERM PISTON.
OVERHAUL KIT OEM: 23538418.
CYLINDER KIT OEM: 23533596, 2353891.
PISTON OEM: 23537126, 23533594.
4 THRUST WASHER MAIN BEARING SET.
FPIFKS6014LM, S60110-017, MCIF23538418
468-5133 $3,993.21

Component	OEM	Description	Qty.
226-2099 $600.24	23533596	CYLINDER SLEEVE	6
MS2310P $210.19		MAIN BEARING SET	1
MS2346P $127.48	23535010	MAIN BEARING SET	1
TW696S $112.96	23530554	THRUST WASHER	1
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
SH1986 $21.63	.	CAMSHAFT BEARING	7
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
VS50404 $61.95	23522269	VALVE COVER GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1
THD788 $34.73	.	Thermostat	2
GS33366 $73.06	.	INJECTOR O-RINGS	6

Page 49
PISTONLESS.
OVERHAUL KIT OEM: 23538418.
CYLINDER KIT OEM: 23533596, 2353891.
PISTON OEM: 23537126, 23533594.
4 THRUST WASHER MAIN BEARING SET.
FPIFKS6014LSP, MCIF23538418
468-5133NP $5,229.95

Component	OEM	Description	Qty.
226-4632 $127.48	23535511	CYLINDER SLEEVE	6
2231976	23539051	PISTON PIN	6
2235511	23521781	SNAP RING	6
2234000	23528493	PISTON COOLING NOZZLE	6
S4226-2 $95.57	23537529	PISTON RING SET	6
MS2310P $210.19	.	MAIN BEARING SET	1
MS2346P $127.48	23535010	MAIN BEARING SET	1
TW696S $112.96	23530554	THRUST WASHER	1
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
SH1986 $21.63	.	CAMSHAFT BEARING	7
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
VS50404 $61.95	23522269	VALVE COVER GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1
GS33633 $15.77	23535700	INJECTOR O-RINGS	1

Page 50
Heavy duty replacement engine parts
overhaul and in-frame engine kits
DETROIT DIESEL SERIES 60 14.0L DDEC V CONT'D
7 MAIN BEARING JOURNAL.
CYLINDER KIT OEM: 23530661.
PISTON OEM: 23530596.
THRUST WASHER OEM: 8929085.
468-5116

Component	OEM	Description	Qty.
226-2043 $610.39	23530661	CYLINDER SLEEVE ASSEMBLY	6
MS2093P $295.67	8929680	MAIN BEARING SET	1
TW600S $34.70	8929085	THRUST WASHER	1
CB1902P $25.93	23526141	CONNECTING ROD BEARINGS	6
SH1986 $21.63	.	CAMSHAFT BEARING	7
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
VS50278 $61.80	23516322	VALVE COVER GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1
THD788 $34.73		Thermostat	2
GS33633 $15.77	23535700	INJECTOR O-RINGS	1

6 MAIN BEARING JOURNAL.
CYLINDER KIT OEM: 23530661.
PISTON OEM: 23530596.
THRUST WASHER OEM: 8929085
468-5112

Component	OEM	Description	Qty.
226-2043 $610.39	.	CYLINDER SLEEVE ASSEMBLY	6
MS2313P $256.61	.	MAIN BEARING SET	1
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1
TW600S $34.70	8929085	THRUST WASHER	1

Page 51
7 MAIN BEARING JOURNAL.
CYLINDER KIT OEM: 23530661.
PISTON OEM: 23530596.
THRUST WASHER OEM: 23530555.
MAIN BEARING OEM: 8929670.
468-5108

Component	OEM	Description	Qty.
226-2043 $610.39	.	CYLINDER SLEEVE ASSEMBLY	6
MS2310P $210.19	.	MAIN BEARING SET	1
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
TW696S $112.96	23530554	THRUST WASHER	1
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1

Articulated Piston.
Heavy Duty Overhaul Kit. OEM 23537081.
Reference cylinder KIT OEM: 23530665,
PISTON OEM: 23530664
PISTON RINGS OEM: 23531252.
FPIFKS6014L65
468-1110 $7,561.62

Component	OEM	Description	Qty.
226-2045 $610.39	23530665.	CYLINDER SLEEVE ASSEMBLY	6
MS2310P $210.19	.	MAIN BEARING SET	1
CB1902P $25.93	BEARINGS	CONNECTING ROD	6
TW696S $112.96	23530554	THRUST WASHER	1
FS54157A $604.04	23536443	FULL GASKET KIT	1
OS32382 $61.82	23505992	OIL PAN SET	1

Page 52
Heavy duty replacement engine parts
overhaul and in-frame engine kits
DETROIT DIESEL 11.1 / 12.7L
OVERHAUL KIT OEM: 23532592.
PISTON OEM: 23519624.
CYLINDER KIT OEM: 23532590.
WIDE CONNECTING ROD BEARING.
FPS6090
468-5131 $9,952.60

Component	OEM	Description	Qty.
226-2094 $761.18	23519625	CYLINDER SLEEVE ASSEMBLY	6
MS2093P $295.67	.	MAIN BEARING SETS	1
CB1792P $43.38	23515581	CONNECTING ROD BEARINGS	6
TW600S $34.70	8929085	THRUST WASHER	1
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
OS32382 $61.82 (OPTIONAL)	.	OIL PAN SET	1

OVERHAUL KIT OEM: 23532592.
PISTON OEM: 23519624.
CYLINDER KIT OEM: 23532590.
CONNECTING ROD BEARING OEM: 8929553, 8929710.
NARROW CONNECTING ROD BEARING.
FPS6090A
468-5132 $10,481.95

Component	OEM	Description	Qty.
226-2094 $761.18	23519625	CYLINDER SLEEVE ASSEMBLY	6
MS2093P $295.67	.	MAIN BEARING SETS	1
CB1662P $31.80	8929553	CONNECTING ROD BEARINGS	6
TW600S $34.70	8929085	THRUST WASHER	1
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
OS32382 $61.82 (OPTIONAL)	.	OIL PAN SET	1

Page 53
DETROIT DIESEL 14.0L DDEC VI
EPA07. OVERHAUL KIT OEM: 23539316,
PISTON OEM: 23536674, 23537531.
CYLINDER KIT OEM: 23536256.
FPIFKS6014LM56, S60116-033
468-5150 $4,822.50

Component	OEM	Description	Qty.
226-2119 $634.90	23536256	CYLINDER SLEEVE ASSEMBLY	6
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
MS2310P $210.19	.	MAIN BEARING SET	1
TW696S $112.96	23530554	THRUST WASHER	1
SH1986 $21.63	.	CAMSHAFT BEARING	7
HS54157A $575.44	23538506	CYLINDER HEAD GASKET SET	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
GS33843 $34.92	.	INJECTOR O-RINGS	1
VS50404 $61.95	23522269	VALVE COVER GASKET SET	1
VS50728 $55.49	VS50728 $55.49	VALVE COVER GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1
THD788 $34.73	Thermostat	2

PISTONLESS.
OVERHAUL KIT OEM: 23539316.
PISTON OEM: 23536674, 23537531.
CYLINDER KIT OEM: 23536256
468-5150NP $4,044.02

Component	OEM	Description	Qty.
226-4632 $127.48	23535511	CYLINDER SLEEVE	6
S4226-2 $95.57	23537529	PISTON RING SET	6
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
MS2310P $210.19	.	MAIN BEARING SET	1
TW696S $112.96	23530554	THRUST WASHER	1
HS54157A $575.44	23538506	CYLINDER HEAD GASKET SET	1
VS50404 $61.95	23522269	VALVE COVER GASKET SET	1
VS50728 $55.49	.	VALVE COVER GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1

Page 54
Heavy duty replacement engine parts
overhaul and in-frame engine kits
DETROIT DIESEL SERIES 60 12.7L
24 VALVE DDEC IV / DDEC V
OVERHAUL KIT OEM: 23532577.
PREMIUM. CYLINDER KIT OEM:23532562.
PISTON OEM: 23530668, 23532552.
PISTON RINGS OEM: 23531251.
BLACK OIL PAN GASKET.
BLACK OIL PAN GASKET DDEC IV AND DDEC V.
468-1100 $3,948.15

Component	OEM	Description	Qty.
226-2106 $465.23	23530669	CYLINDER SLEEVE ASSEMBLY	6
MS2093P $295.67	..	CONNECTING ROD BEARINGS	1
TW600S $34.70	8929085	THRUST WASHER	1
CB1836P $36.06	.	CONNECTING ROD BEARINGS	6
SH1986 $21.63	.	CAMSHAFT BEARING	7
FS54157 $397.42	23532332	FULL GASKET KIT	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
VS50404 $61.95	23522269	VALVE COVER GASKET SET	1
OS32382 $61.82	23505992	OIL PAN SET	1
GS33448 $17.30	23511870	INJECTOR O-RINGS	6
THD788 $34.73	.	Thermostat	2
67745 $63.50	.	TIMING COVER SEAL	1
67744 $74.59	.	REAR MAIN SEAL & SLEEVE	1

Page 55
DETROIT DIESEL SERIES 60 12.7L 24 VALVE
OVERHAUL KIT OEM: 23532574 PREMIUM.
CYLINDER KIT OEM:23532561, 23533204.
PISTON CROWN OEM: 23532465.
FPS6061P
468-5094 $3,984.56

Component	OEM	Description	Qty.
226-2104 $462.33	23532561	CYLINDER SLEEVE ASSEMBLY	6
MS2093P $295.67	.	CONNECTING ROD BEARINGS	1
TW600S $34.70	8929085	THRUST WASHER	1
CB1836P $36.06	.	CONNECTING ROD BEARINGS	6
SH1986 $21.63	.	CAMSHAFT BEARING	7
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
VS50278 $61.80	23516322	VALVE COVER GASKET SET	1
OS32204 $57.03	8929102	OIL PAN SET	1
GS33448 $17.30	23511870	INJECTOR O-RINGS	6

DETROIT DIESEL SERIES 60 12.7L DDEC IV
4 THRUST WASHERS.
OVERHAUL KIT OEM: 23537130.
CYLINDER KIT OEM:23533595.
PISTON OEM: 23533041, 23533593.
FPS6095P
468-5149 $5,350.44

Component	OEM	Description	Qty.
226-2126 $661.07	.	CYLINDER SLEEVE ASSEMBLY	6
MS2375P $329.08	23533691	MAIN BEARING SET	1
TW696S $112.96	23530554	THRUST WASHER	1
CB1902P $25.93	.	CONNECTING ROD BEARINGS	6
SH1986 $21.63	.	CAMSHAFT BEARING	7
HS54157 $371.98	23501572	CYLINDER HEAD GASKET SET	1
GS33539 $266.91	23530768	CYLINDER HEAD BOLTS	1
OS32382 $61.82	23505992	OIL PAN SET	1
THD788 $34.73	.	Thermostat	2
GS33633 $15.77	23535700	INJECTOR O-RINGS	1

Page 56
Heavy duty replacement engine parts
overhaul and in-frame engine kits
DETROIT DIESEL DD15 MRK1 OM472LA
PISTONLESS. OM472.900, .901, .902.
REFERENCE PISTON KIT OEM: A4720302717.
CYLINDER HEAD GASKET OEM: A4710161520.
468-5154NP $9,655.42

Component	OEM	Description	Qty.
226-4646	A4720111810	CYLINDER SLEEVE	6
S42438	A4720300424	PISTON RING SET	6
CB2003P	A4720300960	CONNECTING ROD BEARINGS	6
MH4720300240	A4720300740	MAIN BEARING SET	7
TW741S $479.75	A4720300445	THRUST WASHER	1
HS5534-7	A4710161520	CYLINDER HEAD GASKET SET	1
MH4720140322	A4720140322	OIL PAN SET	1

DETROIT DIESEL DD15 MRK2 OM472LA
PISTONLESS. OM472.903, .904, .907.
REFERENCE PISTON KIT OEM: A4720302317.
CYLINDER HEAD GASKET OEM: A4720161420.
468-5155NP $10,120.80

Component	OEM	Description	Qty.
226-4646	A4720111810	CYLINDER SLEEVE	6
S42438	A4720300424	PISTON RING SET	6
CB2003P	A4720300960	CONNECTING ROD BEARINGS	6
MH4720300240	A4720300740	MAIN BEARING SET	7
TW741S $479.75	A4720300445	THRUST WASHER	1
HS5534-8	A4720161420	CYLINDER HEAD GASKET SET	1
MH4720140322	A4720140322	OIL PAN SET	1

Page 57
DETROIT DIESEL DD15 MRK3 OM472LA
PISTONLESS. OM472.906, .908, .909, .910.
REFERENCE PISTON KIT OEM: A4720302317.
CYLINDER HEAD GASKET OEM: A4720162220.
468-5156NP $7,847.31

Component	OEM	Description	Qty.
226-4655	A4720111910	CYLINDER SLEEVE	6
S42439	A4720300624	PISTON RING SET	6
CB2003P	A4720300960	CONNECTING ROD BEARINGS	6
MH4720300240	A4720300740	MAIN BEARING SET	7
TW741S $479.75	A4720300445	THRUST WASHER	1
HS5534-9	A4720162220	CYLINDER HEAD GASKET SET	1

Page 58
Heavy duty replacement engine parts
overhaul and in-frame engine kits
HINO J05E
3MM FLANGED CYLINDER SLEEVE.
CYLINDER KIT OEM: S1301-E0101-T.
CONNECTING ROD BEARING OEM: 13201-2120A.
MAIN BEARING OEM: 11019-1470A.
THRUST WASHER OEM: 11011-1380.
FULL GASKET KIT OEM: S0401-04243.
496-1000 $5,620.00

Component	OEM	Description	Qty.
HMK-T01E0101T-KX	S1301-E0101-T	CYLINDER SLEEVE ASSEMBLY	4
CB2027P	13201-2120A	CONNECTING ROD BEARINGS	4
MB4122P	11019-1470A	MAIN BEARING SET	5
TW754S	11011-1380	THRUST WASHER	1
FS55447	S0401-04243	FULL GASKET KIT	1

8MM FLANGED CYLINDER SLEEVE.
CYLINDER KIT OEM: S0401-30270-T.
CONNECTING ROD BEARING OEM: 13201-2120A.
MAIN BEARING OEM: 11019-1470A.
THRUST WASHER OEM: 11011-1380.
FULL GASKET KIT OEM: S0401-04243.
496-1001 $4,399.29

Component	OEM	Description	Qty.
HMK-T0130270T-KX	S0401-30270-T	CYLINDER SLEEVE ASSEMBLY	4
CB2027P	13201-2120A	CONNECTING ROD BEARINGS	4
MB4122P	11019-1470A	MAIN BEARING SET	5
TW754S	11011-1380	THRUST WASHER	1
FS55447	S0401-04243	FULL GASKET KIT	1

Page 59
ISUZU 4JJ1-TC ELF 200, ELF300
CYLINDER KIT OEM: 8-98043704-0-T
476-5000 $3,304.45

Component	OEM	Description	Qty.
IMKT837040TKX	8-98043704-0-T	CYLINDER SLEEVE ASSEMBLY	4
CB2025A(4)	.	CONNECTING ROD BEARINGS	1
MS2409A	.	MAIN BEARING SET	1
TW753S	.	THRUST WASHER	1

ISUZU 4HK1-TC ELF-400,500,600
EXCAVATOR MOUNTED ENGINE
JS200/220 JCB AND CASE 210.
476-5001 $5,912.94

Component	OEM	Description	Qty.
IMKT545803T	5878145803	CYLINDER SLEEVE ASSEMBLY	4
CB1993P (4)	8976163580	CONNECTING ROD BEARINGS	1
MS2372P	8-97372076-0	MAIN BEARING SET	1
TW732S	8-94399277-0	THRUST WASHER	1
HS55076 $1,015.93	5-87817-734-0	CYLINDER HEAD GASKET SET	1
OS32527	212 678 44	OIL PAN SET	1

Part numbers above each table are In-Frame Kits or
Complete Engine ASSEMBLY OVERHAUL KITS

Page 60
Heavy duty replacement engine parts
Overhaul and In-frame engine kits
MERCEDES-BENZ OM366A / LA
PISTON OEM: A3660302617 (E48510). 390900405, 390900407.
BEFORE EPA
486-1004 $1,697.83

Component	OEM	Description	Qty.
224-3836 $79.68	366 030 00 17	PISTON	6
226-4609 $44.89	352 011 12 10	CYLINDER SLEEVE	6
3007KM	366 030 00 24	PISTON RINGS	1
CB1952P(6) $81.06	364 030 03 60	CONNECTING ROD BEARINGS	1
FS54836 $414.78	906 030 40 17	FULL GASKET KIT	1
MS2333P $195.68	366 030 00 40	MAIN BEARING SET	1

PISTON OEM: A3660307317, 3660301018,
3660377301, EURO1 (E48520).
486-1007 $2,648.99

Component	OEM	Description	Qty.
224-3837 $92.70	364 030 10 17	PISTON	6
226-4609 $44.89	352 011 12 10	CYLINDER SLEEVE	6
3007KM	366 030 00 24	PISTON RINGS	1
CB1952P(6) $81.06	364 030 03 60	CONNECTING ROD BEARINGS	1
FS54836 $414.78	906 030 40 17	FULL GASKET KIT	1
MS2333P $195.68	366 030 00 40	MAIN BEARING SET	1

PISTON OEM: 3660309717, 3660379701,
3660301418, 3660301818, 3660307217 (E48560).
EPA 91
486-1012 $2,622.83

Component	OEM	Description	Qty.
226-2081 $169.53	904 030 00 40	CYLINDER SLEEVE ASSEMBLY	6
CB1952P(6) $81.06	364 030 03 60	CONNECTING ROD BEARINGS	1
FS54836 $414.78	906 030 40 17	FULL GASKET KIT	1

Page 61
PISTON OEM: 390 037 05 01 (E48550).
EPA 94
486-1015 $2,622.83

Component	OEM	Description	Qty.
226-2082 $169.53	.	CYLINDER SLEEVE ASSEMBLY	6
CB1952P(6) $81.06	364 030 03 60	CONNECTING ROD BEARINGS	1
FS54836 $414.78	906 030 40 17	FULL GASKET KIT	1
MS2333P $195.68	366 030 00 40	MAIN BEARING SET	1

MERCEDES-BENZ OM447LA
PISTON OEM: 447 037 20 01.
486-1029 $8,209.83

Component	OEM	Description	Qty.
224-3840	.	PISTON	6
226-4607 $146.25	447 011 01 10	CYLINDER SLEEVE	6
CB1901P(6)	447 030 12 60	CONNECTING ROD BEARINGS	1
HS54757 $63.50	422 053 01 96	CYLINDER HEAD GASKET SET	6
MS2345P	447 030 00 40	MAIN BEARING SET	1
S42220 $105.71	926 030 28 17	PISTON RING SET	6

Page 62
Heavy duty replacement engine parts
Overhaul and In-frame engine kits
MERCEDES-BENZ OM460LA
EPA98. OM460.926, .907, .908, .913, .926.
CYLINDER KIT OEM: A4600302237, A4600303237.
HEAD GASKET WITH INSERTS.
486-1045 $11,782.48

Component	OEM	Description	Qty.
223-4004 $114.35	460 180 00 43	PISTON COOLING NOZZLE	6
226-2095 $688.72	460 030 00 37	CYLINDER SLEEVE ASSEMBLY	6
CB1970P	460 030 07 60	CONNECTING ROD BEARINGS	6
CS54978 $702.68	460 010 05 05	CONVERSION GASKET SET	1
GS33713 $31.59	541 997 04 45	INJECTOR O-RINGS	6
HS54979 $133.48	460 010 12 20	CYLINDER HEAD GASKET SET	6
KX801D $28.93	.	FUEL FILTER	1
MS19914 $201.83	460 140 01 09	INTAKE / EXHAUST MANIFOLD GASKET	1
MS2332P $603.13	457 030 03 40	MAIN BEARING SET	1
OS32450 $157.35	457 014 02 22	OIL PAN SET	1
OX348D $41.89	460 010 05 05	OIL FILTER	1
TX1883D $31.68	457 010 82 20	THERMOSTAT	2

Page 63
EPA04. OM460.934.
CYLINDER KIT OEM: A460 030 13 37.
HEAD GASKET WITHOUT INSERTS
486-1046 $13,935.85

Component	OEM	Description	Qty.
223-4005 $82.43	460 180 03 43	PISTON COOLING NOZZLE	6
226-2096 $688.72	460 030 13 37	CYLINDER SLEEVE ASSEMBLY	6
CB1970P	460 030 07 60	CONNECTING ROD BEARINGS	6
CS54978 $702.68	460 010 05 05	CONVERSION GASKET SET	1
GS33713 $31.59	541 997 04 45	INJECTOR O-RINGS	6
HS54978 $112.73	457 010 82 20	CYLINDER HEAD GASKET SET	6
KX801D $28.93	.	FUEL FILTER	1
MS19915 $227.23	460 140 00 09	INTAKE / EXHAUST MANIFOLD GASKET	1
MS2332P $603.13	457 030 03 40	MAIN BEARING SET	1
OS32450 $157.35	457 014 02 22	OIL PAN SET	1
OX348D $41.89	460 010 05 05	OIL FILTER	1
TX1883D $31.68	457 010 82 20	THERMOSTAT	2

Page 64
Heavy duty replacement engine parts
Overhaul and In-frame engine kits
MERCEDES-BENZ OM460LA CONT'D
EPA04, EPA07.
CYLINDER KIT OEM: A4600303537.
APR CYLINDER SLEEVE. OM460.926.
HEAD GASKET WITH INSERTS
486-1048 $6,226.16

Component	OEM	Description	Qty.
223-4006 $92.68	906 014 04 22	PISTON COOLING NOZZLE	6
226-2097 $688.72	4600303537	CYLINDER SLEEVE ASSEMBLY	6
CB1970P	460 030 07 60	CONNECTING ROD BEARINGS	6
CS54978 $702.68	460 010 05 05	CONVERSION GASKET SET	1
GS33713 $31.59	541 997 04 45	INJECTOR O-RINGS	6
HS54979 $133.48	460 010 12 20	CYLINDER HEAD GASKET SET	6
KX801D $28.93	.	FUEL FILTER	1
MS19915 $227.23	460 140 00 09	INTAKE / EXHAUST MANIFOLD GASKET	1
MS2332P $603.13	457 030 03 40	MAIN BEARING SET	1
OS32450 $157.35	457 014 02 22	OIL PAN SET	1
OX348D $41.89	460 010 05 05	OIL FILTER	1
TX1883D $31.68	457 010 82 20	THERMOSTAT	2

Page 65
EPA98. SERIES:
OM460.907, .908, .913, .926.
CYLINDER KIT OEM: A4600302237, A4600303237.
HEAD GASKET WITH INSERTS
486-5045 $11,563.63

Component	OEM	Description	Qty.
223-4004 $114.35	460 180 00 43	PISTON COOLING NOZZLE	6
226-2095 $688.72	460 030 00 37	CYLINDER SLEEVE ASSEMBLY	6
CB1970P	460 030 07 60	CONNECTING ROD BEARINGS	6
GS33713 $31.59	541 997 04 45	INJECTOR O-RINGS	6
HS54979 $133.48	460 010 12 20	CYLINDER HEAD GASKET SET	6
KX801D $28.93	.	FUEL FILTER	1
MS19914 $201.83	460 140 01 09	INTAKE / EXHAUST MANIFOLD GASKET	1
MS2332P $603.13	457 030 03 40	MAIN BEARING SET	1
OS32450 $157.35	457 014 02 22	OIL PAN SET	1
OX348D $41.89	460 010 05 05	OIL FILTER	1
TX1883D $31.68	457 010 82 20	THERMOSTAT	2

EPA04.
CYLINDER KIT OEM: 4600303537, 4600301937.
APR CYLINDER SLEEVE.
OVERHAUL KIT OEM: 4600102000.
HEAD GASKET WITHOUT INSERTS
486-5047 $5,222.68

Component	OEM	Description	Qty.
226-2097 $688.72	4600301237	CYLINDER SLEEVE ASSEMBLY	6
223-4006 $92.68	906 014 04 22	PISTON COOLING NOZZLE	6
MS2332P $603.13	457 030 03 40	MAIN BEARING SET	1
CB1970P(6) $271.02	457 014 02 22	CONNECTING ROD BEARINGS	1
HS54978 $112.73	457 010 82 20	CYLINDER HEAD GASKET SET	6
MS19915 $227.23	460 140 00 09	INTAKE / EXHAUST MANIFOLD GASKET	1
OS32450 $157.35	457 014 02 22	OIL PAN SET	1
TX1883D $31.68	457 010 82 20	THERMOSTAT	2
KX801D $28.93		FUEL FILTER	1
OX348D $41.89	460 010 05 05	OIL FILTER	1
GS33713 $31.59	541 997 04 45	INJECTOR O-RINGS	6

Page 66
Heavy duty replacement engine parts
Overhaul and In-frame engine kits
MERCEDES-BENZ OM460LA CONT'D
EPA04, EPA07.
CYLINDER KIT OEM: A4600303437, 4600303537.
APR CYLINDER SLEEVE. OM460.933, .934, .941, .975.
OVERHAUL KIT OEM: 4600102400.
HEAD GASKET WITH INSERTS
486-5048 $5,276.36

Component	OEM	Description	Qty.
226-2097 $688.72	4600301237	CYLINDER SLEEVE ASSEMBLY	6
223-4006 $92.68	906 014 04 22	PISTON COOLING NOZZLE	6
MS2332P $603.13	457 030 03 40	MAIN BEARING SET	1
CB1970P	460 030 07 60	CONNECTING ROD BEARINGS	6
HS54979 $133.48	460 010 12 20	CYLINDER HEAD GASKET SET	6
MS19915 $227.23	460 140 00 09	EXHAUST MANIFOLD GASKET	1
OS32450 $157.35	457 014 02 22	OIL PAN SET	1
TX1883D $31.68	457 010 82 20	THERMOSTAT	2
KX801D $28.93		FUEL FILTER	1
OX348D $41.89	460 010 05 05	OIL FILTER	1
GS33713 $31.59	541 997 04 45	INJECTOR O-RINGS	6

MERCEDES-BENZ OM612LA
PISTON OEM: A6110371101. SPRINTER.
486-1000 $2,654.75

Component	OEM	Description	Qty.
224-3364WR $223.20	611 037 11 01	PISTON WITH RINGS	5
95-3614 $465.71	366 030 00 40	EXHAUST SYSTEM GASKET	1
CB1842P(5) $24.59	5086 153AA	CONNECTING ROD BEARINGS	1
MS2248P $175.33	05102127AA	MAIN BEARING SET	1
TW620	6010300062	THRUST WASHER	1

Page 67
MERCEDES-BENZ OM647LA
PISTON OEM: A6460300917. SPRINTER.
486-1035 $2,559.15

Component	OEM	Description	Qty.
224-3585WR $223.21	5161 392AB	PISTON WITH RINGS	5
95-3614 $465.71	366 030 00 40	EXHAUST SYSTEM GASKET	1
CB1842P(5) $24.59	5086 153AA	CONNECTING ROD BEARINGS	1
MS2248P $175.33	05102127AA	MAIN BEARING SET	1

MERCEDES-BENZ OM904LA
EPA98, EURO 2, 3. PISTON OEM: 9060300517, A9060303217.
40MM PISTON PIN
486-1016 $2,624.37

Component	OEM	Description	Qty.
224-3841 $181.16	906 030 05 17	PISTON	4
226-4606 $73.79	906 011 01 10	CYLINDER SLEEVE	4
42210 $73.81	003 030 97 24	PISTON RING SET	2
CB1888P(4) $121.73	904 030 00 60	CONNECTING ROD BEARINGS	1
HS54837 $454.66	904 010 45 21	CYLINDER HEAD GASKET SET	1
MS2282P $159.40	904 030 00 40	MAIN BEARING SET	1

EPA98, EURO 2, 3.
PISTON OEM: 9060306017
NON GASKETS. SERIES: 904.904, .906, .907, .908,
.909, .910, .911, .912, .914, .915, .916, .917, .918,
.919, .920, .921 .921, .922, .923, .926, .929, .930, .
931, .932.. 42MM PISTON PIN
486-1019NG $1,702.21

Component	OEM	Description	Qty.
224-3842	906 030 40 17	PISTON	4
226-4606 $73.79	906 011 01 10	CYLINDER SLEEVE	4
42210 $73.81	003 030 97 24	PISTON RING SET	2
CB1888P(4) $121.73	904 030 00 60	CONNECTING ROD BEARINGS	1
MS2282P $159.40	904 030 00 40	MAIN BEARING SET	1

Page 68
Heavy duty replacement engine parts
Overhaul and In-frame engine kits
MERCEDES-BENZ OM904LA CONT'D
EPA98, EURO 2, 3.
PISTON OEM: 9060306017.
SERIES: 904.904, .906, .907, .908, .909, .910, .911, .
912, .914, .915, .916, .917, .918, .919, .920, .921 .
921, .922, .923, .926, .929, .930, .931, .932.
42MM PISTON PIN
486-1019 $2,335.89

Component	OEM	Description	Qty.
224-3842	906 030 40 17	PISTON	4
226-4606 $73.79	906 011 01 10	CYLINDER SLEEVE	4
42210 $73.81	003 030 97 24	PISTON RING SET	2
CB1888P(4) $121.73	904 030 00 60	CONNECTING ROD BEARINGS	1
HS54837 $454.66	904 010 45 21	CYLINDER HEAD GASKET SET	1
MS2282P $159.40	904 030 00 40	MAIN BEARING SET	1

MERCEDES-BENZ OM906LA
EPA98. EURO 2, 3.
PISTON OEM: 9060300517. 40MM PISTON PIN.
486-1022 $3,849.68

Component	OEM	Description	Qty.
224-3841 $181.16	906 030 05 17	PISTON	6
42210 $73.81	003 030 97 24	PISTON RING SET	3
226-4606 $73.79	906 011 01 10	CYLINDER SLEEVE	6
MS2283P $175.33	904 030 00 40	MAIN BEARING SET	1
CB1888P(6) $140.58	904 030 00 60	CONNECTING ROD BEARINGS	1
HS54838 $815.62	906 010 04 21	CYLINDER HEAD GASKET SET	1

EPA98. EURO 2, 3.
PISTON OEM: 9060306017, 9060305217. 902.919,
.919, 904.906. 907. 908, .909, .910, .911.
WITHOUT GASKETS. 42MM PISTON PIN.
486-1025NG $2,469.29

Component	OEM	Description	Qty.
224-3842	906 030 40 17	PISTON	6
226-4606 $73.79	906 011 01 10	CYLINDER SLEEVE	6
42210 $73.81	003 030 97 24	PISTON RING SET	3
CB1888P(6) $140.58	904 030 00 60	CONNECTING ROD BEARINGS	1
MS2283P $175.33	904 030 00 40	MAIN BEARING SET	1
