Engine Rebuild Kit and Parts Online Catalog.










Engine Rebuild & Assembly Balancing &
Blueprinting
Cylinder Heads
Engine Rebuild Kits Engine Start-up Other Related Web Sites Page 1
Crankshafts Degree Cam Other Related Web Sites Page 2
Purchase warranty & Return Information About the owner of RPM Frequently Asked Questions
MASTER ENGINE REBUILD KITS & PARTS

Home


Page I
Table of Contents
Product Information

....................................................................... Page(s)
Engine Finding Index................................................ 1
Engine Code Index............................................... 2-4
Model Index...................................................... 4-29
Applications.................................................... 1-181
....2.9L thru 6.7L............................................. 29-61
This page 6.7L thru 13.1................................ 62-115
DT360 Engine...................................................... 43
DT408 Engine...................................................... 62
6.9L Engine.......................................................... 69
7.3L / T444E Engine............................................ 80
DT466 Engine.................................................... 116
I530 Engine........................................................ 148
9.0L Engine to 13.1L.......................................... 165
Engine Kit Bill of Material (Parts in Kits)............. 182


Page 1
International/Navistar Truck

Engine Finding Index
Engine............................................Years....Line #
2.9L 175 L-HEAD L6 3" Bore
(12 Valve) M/D Truck .................................... 1

3.5L 214 L-HEAD L6 3.3125" Bore
(12 Valve) M/D Truck ..................................... 2

3.6L 220. OHV L6 3.5625" Bore (12 Valve)
M/D Truck ..................................
1965-68 ......3

3.8L 233. L-HEAD L6 3.3125" Bore
(12 Valve) M/D Truck ..................................... 4

3.9L 240. OHV L6 3.5625" Bore (12 Valve)M/D Truck........................................... 1960-68 ......5

4.1L 250 OHV L6 3.4375" Bore
(12 Valve) M/D Truck...................................... 6

4.3L 264 OHV L6 3.6875" Bore (12 Valve) M/D Truck......................................... 1960-68 ........7

4.4L 266 OHV V8 3.625" Bore (16 Valve) M/D Truck................................ 1960-70 .................8

4.4L 269 OHV L6 3.5625" Bore
(12 Valve) M/D Truck.................................... 9

4.4L 269 OHV L6 3.5625" Bore
(12 Valve) M/D Truck................................... 10

4.6L 282 OHV L6 3.8125" Bore (12 Valve)
M/D Truck.................................
1960-71 ......11

4.6L 282 OHV L6 3.8125" Bore (12 Valve)
H/D Truck..................................
1960-71 ......11

4.9L 301 OHV Diesel L6 3.8125" Bore (12 Valve)
M/D Truck ...................................
1963-70 ...12

5.0L 304 OHV V8 3.875" Bore (16 Valve)
M/D Truck..................................
1960-75 .....13

5.0L 304 OHV V8 3.875" Bore (16 Valve)
H/D Truck...................................
1960-75 .....13

5.0L 304 OHV LPG V8 3.875" Bore (16 Valve)
M/D Truck..................................
1967-74 .....14

5.0L 308 OHV L6 3.8125" Bore (12 Valve)
M/D Truck...................................
1960-71 .....15

5.0L 308 OHV L6 3.8125" Bore (12 Valve)
H/D Truck...................................
1960-71 .....15

5.2L 318 OHV L6 3.875" Bore
(12 Valve) M/D Truck.................................... 16


5.7L 345 OHV V8 3.875" Bore (16 Valve)
M/D Truck...................................
1961-85 .....17

5.7L 345 OHV V8 3.875" Bore (16 Valve)
H/D Truck...................................
1961-85 .....17

5.7L 345 OHV LPG V8 3.875" Bore (16 Valve)
M/D Truck..................................
1967-74 .....18

5.9L 360. OHV Turbo-Diesel L6 4.01" Bore
(12Valve) M/D Truck ..................
1987-93 ...19

5.9L 360. OHV Turbo-Diesel L6 4.01" Bore (12
Valve) H/D Truck.........................
1987-93 ....19

5.9L 361 OHV L6 4.125" Bore
(12 Valve) M/D Truck................................... 20


6.1L 372 OHV L6 4.375" Bore (12 Valve)
M/D Truck..................................
1960-69 .....21

6.1L 372 OHV L6 4.375" Bore (12 Valve)
H/D Truck...................................
1960-69 .....21

6.4L 392 OHV V8 4.125" Bore (16 Valve)
M/D Truck..................................
1969-85 .....22

6.4L 392 OHV V8 4.125" Bore (16 Valve)
H/D Truck...................................
1966-82 .....23

6.6L 401. OHV L6 4.125" Bore (12 Valve)
M/D Truck..................................
1949-69 .....24

6.6L 401. OHV V8 4.125" Bore (16 Valve)
M/D Truck..................................
1960-64 .....25

6.6L 401. OHV V8 4.125" Bore (16 Valve)
H/D Truck...................................
1960-74 .....26

6.6L 404. OHV V8 4.125" Bore (16 Valve)
M/D Truck..................................
1979-81 .....27

6.6L 404. OHV V8 4.125" Bore (16 Valve)
H/D Truck...................................
1975-82 .....28

6.7L 406. OHV L6 4.375" Bore (12 Valve)
M/D Truck..................................
1961-74 .....29

6.7L 406. OHV L6 4.375" Bore (12 Valve)
H/D Truck..................................
1960-74 .....30

6.7L 408. OHV Turbo-Diesel L6 4.3005" Bore (12
Valve) M/D Truck .......................
1993-97 ....31

6.7L 408. OHV Turbo-Diesel L6 4.3005" Bore (12
Valve) H/D Truck........................
1993-97 .....31

6.9L 420. OHV Diesel V8 4" Bore (IDI)
M/D Truck. ...................................1980-90.....32

6.9L 420. OHV Diesel V8 4" Bore (IDI)
H/D Truck . ....................................1980-90....32


7.3L 444 OHV Diesel V8 4.11" Bore (IDI
M/D Truck.................................. 1988-93 .....33


7.3L 444 OHV Turbo-Diesel V8 4.11" Bore (IDI)
M/D Truck ...................................
1993-94 ...34

7.3L 444 OHV Turbo-Diesel V8 4.11" Bore (DI)
M/D Truck ................................. 1994-2003 35


7.3L 446 OHV V8 4.125" Bore (16 Valve)
H/D Truck..................................
1975-81 .....36

7.3L 446 OHV NG V8 4.125" Bore (16 Valve)
H/D Truck...................................
1975-81 .....37

7.4L 450 OHV L6 4.375" Bore (12 Valve)
M/D Truck..................................
1961-73 .....38

7.4L 450 OHV L6 4.375" Bore (12 Valve)
H/D Truck...................................
1960-74 .....39

7.6L 461. OHV V8 4.125" Bore (16 Valve)
M/D Truck..................................
1961-64 .....40

7.6L 461. OHV V8 4.125" Bore (16 Valve)
H/D Truck...................................
1960-64 .....41

7.6L 461. OHV Diesel V8 4.125" Bore (16 Valve)
M/D Truck ..................................
1966-73 ....42

7.6L 461. OHV Diesel V8 4.125" Bore (16 Valve)
H/D Truck...................................
1966-73 .....42

7.6L 466 OHV Diesel L6 4.3005" Bore
(12 Valve) H/D Truck.................
1975-83 .....43

7.6L 466 OHV Turbo-Diesel L6 4.
3005" Bore (12 Valve) M/D Truck
1975-97 ...44

7.6L 466 OHV Turbo-Diesel L6 4.3005" Bore
(12 Valve) H/D Truck.................
1975-97 .....44

7.6L 466 OHV Turbo-Diesel L6 4.3005" Bore
(Intercooled) M/D Truck ..............
1993-2004 45

7.6L 466 OHV Turbo-Diesel L6 4.3005" Bore
(Intercooled) H/D Truck..............
1993-2004 .45

7.6L 466 OHV Turbo-Diesel L6 4.587"
Bore (Big Bore) M/D Truck...........
2000-2007 46

7.6L 466 OHV Turbo-Diesel L6 4.587" Bore (Big
Bore) H/D Truck.........................
2000-2007 .46

7.8L 478 OHV V8 4.5" Bore (16 Valve)
H/D Truck...................................
1965-76... .47

8.2L 501 OHV L6 4.5" Bore (12 Valve)
M/D Truck...................................
1961-73 ....48

8.2L 501 OHV L6 4.5" Bore (12 Valve)
H/D Truck ..................................1960-74 .....48


8.7L 530 OHV Turbo-Diesel L6 4.587"
Bore (12 Valve) M/D Truck .........
1993-97 ....49

8.7L 530 OHV Turbo-Diesel L6 4.587" Bore (12
Valve) H/D Truck........................
1993-97 .....49

8.7L 530 OHV Turbo-Diesel L6 4.587" Bore
(Intercooled) M/D Truck ..............
1995-2005 50

8.7L 530 OHV Turbo-Diesel L6 4.587" Bore
(Intercooled) H/D Truck...............
1995-2005 .50

8.8L 537 OHV V8 4.625" Bore (16 Valve)
H/D Truck..................................
1977-81 .......51

9.0L 549 OHV V8 4.5" Bore (16 Valve)
M/D Truck................................. 1961-64 .....52


9.0L 549 OHV V8 4.5" Bore (16 Valve)
H/D Truck.................................. 1961-76 ....53


9.0L 549 OHV Diesel V8 4.5" Bore (16 Valve)
M/D Truck..................................
1969-79 .....54

9.0L 549 OHV Diesel V8 4.5" Bore (16 Valve)
H/D Truck...................................
1968-79 .....54

9.0L 549 OHV LPG V8 4.5"
Bore (16 Valve) M/D Truck .........................55


9.0L 549 OHV LPG V8 4.5"
Bore (16 Valve) H/D Truck...........................55


9.0L 551 OHV Diesel V8 4.5" Bore (16 Valve)
M/D Truck.................................
1980-88 .....56

9.0L 551 OHV Diesel V8 4.5" Bore (16 Valve)
H/D Truck..................................
1980-88 .....56

9.3L 570 OHV Turbo-Diesel L6 4.587" Bore
(Intercooled) M/D Truck ..............
2004-2007 57

9.3L 570 OHV Turbo-Diesel L6 4.587" Bore
(Intercooled) H/D Truck..............
2004-2007 .57

9.3L 570 OHV Turbo-Diesel L6 4.587" Bore
(Intercooled) M/D Truck ...........
2004-2007.. 58

9.3L 570 OHV Turbo-Diesel L6 4.587" Bore
(Intercooled) H/D Truck..........
2004-2007 ....58

9.4L 573 OHV Diesel V8 4.5" Bore (16 Valve) ...........................H/DTruck........ 1968-71 .....59

9.4L 573 OHV Turbo-Diesel V8 4.5" Bore
(International Tractor Eng.)
H/D Truck.................................. 1968-71 .....60


9.9L 605 OHV V8 4.625" Bore (16 Valve)
H/D Truck...................................
1977-81 .....61

9.9L 605 OHV NG V8 4.625" Bore (16 Valve)
H/D Truck...................................
1977-81 .....62

13.1L 800 OHV Diesel V8 5.3125" Bore
(16 Valve) H/D Truck.......................................63



Page 62
DT-408 Engine
Overview
The DT-408 diesel engine was first introduced in 1993.
It is used in On-Highway truck and bus applications.
This engine is also part of the PLN or “Pump Line Nozzle” engine family that includes the DT-466P (NGD) and I530P (NGD) engines. These three engines share many internal engine parts.
Engine Type...........................................Diesel, 4-cycle
Configuration.....................................In-Line 6-Cylinder
Displacement..................................... 408. cu. In. (6.7L)
Bore and Stroke.................................. 4.301 x 4.680 in
.......................................................(109.2 x 118.9 mm)
Combustion System.............................. Direct Injection
Total Engine Weight (Dry).................. 1250. lb. (567.5 kg)
The DT-408 can be identified by the permanent engine
number stamped on the center top left side of the
engine crankcase. The first three positions indicate the
engine displacement. The fourth digit indicates either
turbocharged, air-to-air charge air cooled or mechanical
fuel Injection engine. The fifth digit indicates the use of
the engine, for example M would indicate that the engine
was built for truck use. The rest of the digits represent
the specific engine serial number. A typical serial number
would look like this: 408GM456789.


Page 63
International/Navistar Truck
31 M/D Truck DT408 Eng. H/D Truck DT408 Eng.
6.7L 408. OHV Turbo-Diesel L6 (12 Valve), 4.3005" Bore 1993-97

CYL. HEAD & PARTS

Ref # Qty Gaskets Years Part No. Size Desc.
3 1 Valve Cover Gasket 93-97 FP1817510 $57.11 . .
5 1 Head Gasket 93-97 FP1817562 $101.70 . .
. 1 Head Gaskt Set 93-97 FP1822328 $192.26 . .
Ref # Qty VALVE Years Part No. Size Desc.
19

6.

Intake 93-97 FP1818580 $17.32 . 5/16" valve stem
20

6.

Exhaust 93-97 FP1824838 $33.28 . 5/16" valve stem
24 24 Keeper 93-97 FP1810944 $1.22 . 5/16" valve stem
Ref # Qty VALVE SEAT Years Part No. Size Desc.
25

6.

Exh. 93-97 FP575450 STD I.D. Top taper 1.524"; 1.6285" O.D., 1.3480" ID, .3650" Depth
25

6.

Int. 93-97 FP575043 STD I.D. Top taper 1.787"; 1.9990" OD, 1.7120" ID, .3860" Depth
Ref # Qty VALVE GUIDE Years Part No. Size Desc.
26 12 Guide 93-97 FP1820264 $4.36 . .315" ID, .565" O.A.L.
Ref # Qty VALVE SEAL Years Part No. Size Desc.
41 12 Valve stem Seal 93-97 FP1822245 $2.54 * . Exh. & Int.; To Ser. No. 956463; 5/16" Stem

(continued on next page)

Page 64
International/Navistar Truck
31 (cont.) M/D Truck DT408 Eng. H/D Truck DT408 Eng.
6.7L 408. OHV Turbo-Diesel L6 (12 Valve), 4.3005" Bore 1993-97
Camshaft GROUP
Ref # Qty Camshaft TIMING Years Part No. Size Desc.
42   1 Woodruff Key 97-93 FP218211 $2.70 . Cam gear; 1/4" x 3/4"
Ref # Qty Camshaft / Lifter Years Part No. Size Desc.
54  12 Lifter 97-93 FP1809570 $69.85 . Roller type
FUEL SYSTEM & PARTS
. Qty FUEL Injection Years Part No. Size Desc.
.   1 Injector Nozzle Seat Gasket 97-93 FP675477 $1.18 . .060" thick
.   6. Grommet 97-93 FP682810 $1.56 . Dust cover
.   6. Fuel Injector Sleeve 97-93 FP675442 $11.91 . .
. Qty Turbo- Charger Years Part No. Size Desc.
.   1 Turbocharger Oil Inlet Gasket 97-93 FP253660 $1.81 . .
.   1 Turbocharger Mounting Gasket 97-93 FP1822120 $10.34 . .
(continued on next page)

Page 65
31
(cont.)
M/D Truck DT408 Eng. H/D Truck DT408 Eng.
6.7L
408. OHV Turbo-Diesel L6 (12 Valve), 4.3005" Bore 1993-97
COOLING SYSTEM


Ref # Qty WATER PUMP Years Part No. Size Desc.
1 1 Water Pump - Heavy Duty 93-97 FP1817687 . w/7 bolt mounting flange

(continued on next page)

Page 66
31
(cont.)
M/D Truck DT408 Eng. H/D Truck DT408 Eng.
6.7L
408. OHV Turbo-Diesel L6 (12 Valve), 4.3005" Bore 1993-97
ENGINE BLOCK & PARTS


Ref # Qty Gaskets Years Part No. Size Desc.
5 1 Oil Pan Gasket . FP1826587 $44.28 . .
. 1 Chemicals . FP1816593 $34.85 . Oil pan; RTV Sealant
. 1 Oil Seal Kit . FP690437 $33.31 . Oil pump; Incl. seal & wear sleeve
Ref # Qty Cam Bearings Years Part No. Size Desc.
19 1 Cam Set . FP680117 $38.02 STD .

(continued on next page)

Page 67
31
(cont.)
M/D Truck DT408 Eng. H/D Truck DT408 Eng.
6.7L
408. OHV Turbo-Diesel L6 (12 Valve), 4.3005" Bore 1993-97
Crankshaft /OIL PUMP


Ref # Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.

6.

1 Oil seal kit 93-97 FP690437 $33.31 . Incl. seal & wear sleeve
Ref # Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
54 1 Oil seal kit 93-97 FP181 . Incl. seal & wear sleeve
. 1 Wear sleeve 93-97 FP181 . .
Ref # Qty Main bearings Years Part No. Size Desc.
38

6.

Plain main bearing 93-97 FP182 STD Position 1-2-3-4-5-6
38

6.

Plain main bearing 93-97 FP182 10 Position 1-2-3-4-5-6
38

6.

Plain main bearing 93-97 FP182 20 Position 1-2-3-4-5-6
38

6.

Plain main bearing 93-97 FP182 30 Position 1-2-3-4-5-6
39 1 Flanged Main Brg. 93-97 FP182 STD Position 7.
39 1 Flanged Main Brg. 93-97 FP182 10 Position 7.
39 1 Flanged Main Brg. 93-97 FP182 20 Position 7.
39 1 Flanged Main Brg. 93-97 FP182 30 Position 7.
Ref # Qty OIL PUMP Years Part No. Size Desc.
34 1 Gasket 93-97 FP1816722 $2.91 . Oil suction tube gasket

(continued on next page)

Page 68
31
(cont.)
M/D Truck DT408 Eng. H/D Truck DT408 Eng.
6.7L
408. OHV Turbo-Diesel L6 (12 Valve), 4.3005" Bore 1993-97
CYLINDER COMPONENTS
Ref # Qty Liners Years Part No. Size Desc.
2   6. Liner w/o Sealing Ring 97-93 FP1815674 $104.75 . .
3   6. Cylinder Kit Complete 94-93 FP1822332 $375.08 STD DT408 NGD Engs.; All HP Engs.
4   6. Cyl. Liner Sealing Ring Kit 97-93 FP1822322 $12.37 . .
4   6. Sealing Ring, Liner 97-93 FP1817633 $5.04 . .
4   6. Sealing Ring, Liner 97-93 FP1842115 $10.56 . PTFE
Ref # Qty Pistons Years Part No. Size Desc.
13   6. Piston Body w/o Pin 94-93 FP1822217 $165.23 STD DT408 NGD Engs.; All HP Engs.
19   6. Pin 97-93 FP1818552 $20.56 . .
11  12 Piston Pin Retainer 97-93 FP1818702 $1.56 . .
29   6. Pin Bushing 97-93 FP1818598 $20.54 . .
Ref # Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
27   6. Rod Pair 97-93 FP1822389 $20.61 STD .
27   6. Rod Pair 97-93 FP1822486 $17.32 10 .
27   6. Rod Pair 97-93 FP1822487 $22.24 20 .
Ref # Qty PISTON RINGS Years Part No. Size Desc.
33   6. Ring Set Single Cylinder 97-93 FP1817247 $42.74 . .
KITS . . . .
. Qty Overhaul Kit Years Part No. Size Desc.
.   1 In-Frame Overhaul Kit 97-93

FP

IFKDT408NGD

. .
.   1 In-Frame Overhaul Kit 97-93 FP1826322 $1,529.39 Equal to IH/Navistar "Work Kit"



Page 69
6.9L Engine
Overview
The 6.9 LITER diesel engine was first introduced in 1983.
It is used in On-Highway truck and bus applications.
Engine Type....................................... Diesel, 4-cycle
Configuration..........................................................V8
Displacement..........................420 cu. In. (6.9 Liters)
Bore and Stroke..............................4.000 x 4.180 in.
.....................................................(101.6 x 106.2 mm)
Combustion System...........................Direct Injection
Total Engine Weight (Dry).................860 lb. (390 kg)
The 6.9L can be identified by the permanent engine
number stamped on the front top left side of the
engine. The first three positions indicate the engine
displacement. The fourth digit indicates either naturally
aspirated or turbocharged. The fifth and sixth digits
indicate the use of the engine, for example M2 would
indicate that the engine was built for truck use. The
seventh digit indicates what country the engine was built
in, for example the letter U indicates that the engine was
built in the U.S.A. The rest of the digits represent the
specific engine serial number. Early 6.9L engines with
serial numbers below 59208 are known as 6.9A series
and engines with serial number 59209 and higher are
known as B engines. A typical serial number would look
like this: 69LDM2U456789.


International/Navistar Truck
6.9L In-Frame Overhaul -
Early engines
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK6.9E FP1805944WR 8 Std. Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805946WR 8 20 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805947WR 8 30 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805944WR 40 8 40 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1802200 $22.13 8 Std. Rod Bearing Pair .
FP1802201 $22.13 8 10 Rod Bearing Pair .
FP1802202 $20.61 8 20 Rod Bearing Pair .
FP1802203 $22.13 8 30 Rod Bearing Pair .
FP1802220 $60.29 1 Std. Main Bearing, Flanged .
FP1802221 $60.29 1 10 Main Bearing, Flanged .
FP1802222 $60.29 1 20 Main Bearing, Flanged .
FP1802223 $60.29 1 30 Main Bearing, Flanged .
FP1802216 $25.28 4 Std. Main Bearing, Plain .
FP1802217 $25.28 4 10 Main Bearing, Plain .
FP1802218 $25.28 4 20 Main Bearing, Plain .
FP1802219 $25.28 4 30 Main Bearing, Plain .
260-6054 1 . Oil Pan Gasket Set .
FP1811049 $158.79 1 . Head Gasket Set .
FP1813067 $106.34 1 . Valley Pan Gasket Set .
FP1807974 $29.99 1 . Thermostat Kit 192 degree Thermostat

Page 70
International/Navistar Truck
6.9L In-Frame Overhaul –
Late engines

Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK6.9L FP1805816WR $220.96 8 Std. Piston w/Pin, Retainer & Rings For engines with S/N 59209 and above
FP1805818WR $220.96 8 20 Piston w/Pin, Retainer For engines with S/N 59209
FP1805819WR $215.57 8 30 Piston w/Pin, Retainer For engines with S/N 59209
FP1805816WR $220.96 40 8 40 Piston w/Pin, Retainer For engines with S/N 59209
FP1802200 $22.13 8 Std. Rod Bearing Pair .
FP1802201 $22.13 8 10 Rod Bearing Pair .
FP1802202 $20.61 8 20 Rod Bearing Pair .
FP1802203 $22.13 8 30 Rod Bearing Pair .
FP1802220 $60.29 1 Std. Main Bearing, Flanged .
FP1802221 $60.29 1 10 Main Bearing, Flanged .
FP1802222 $60.29 1 20 Main Bearing, Flanged .
FP1802223 $60.29 1 30 Main Bearing, Flanged .
FP1802216 $25.28 4 Std. Main Bearing, Plain .
FP1802217 $25.28 4 10 Main Bearing, Plain .
FP1802218 $25.28 4 20 Main Bearing, Plain .
FP1802219 $25.28 4 30 Main Bearing, Plain .
260-6054 1 . Oil Pan Gasket Set .
FP1811049 $158.79 1 . Head Gasket Set .
FP1813067 $106.34 1 . Valley Pan Gasket Set .
FP1807974 $29.99 1 . Thermostat Kit 192 degree Thermostat



Page 71
International/Navistar Truck
6.9L Complete Engine Overhaul -
Early engines
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK6.9EOH FP1805944WR 8 Std. Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805946WR 8 20 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805947WR 8 30 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805944WR 40 8 40 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1804000 $14.15   . Piston Pin Bushing .
FP1802200 $22.13 Std. Rod Bearing Pair .
FP1802201 $22.13 8 10 Rod Bearing Pair .
FP1802202 $20.61 . 20 Rod Bearing Pair .
FP1802203 $22.13 30 Rod Bearing Pair .
FP1802220 $60.29 . Std. Main Bearing, Flanged .
FP1802221 $60.29 10 Main Bearing, Flanged .
FP1802222 $60.29 . 20 Main Bearing, Flanged .
FP1802223 $60.29 30 Main Bearing, Flanged .
FP1802216 $25.28   Std. Main Bearing, Plain .
FP1802217 $25.28 10 Main Bearing, Plain .
FP1802218 $25.28 . 20 Main Bearing, Plain .
FP1802219 $25.28 30 Main Bearing, Plain .
PGN6.9C . . Overhaul Gasket Set .
FP1804003 $4.28 . Connecting Rod Bolt .
FP1805866 $1.29 . . Connecting Rod Nut .
FP1807974 $29.99 . Thermostat Kit 192 degree Thermostat

Page 72
International/Navistar Truck
6.9L Complete Engine Overhaul -
Late engine
Kit Number Component No.

QTY.

PART Size PART Desc. Part Appliction
FPIFK6.9EOH FP1805944WR 8 Std. Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805946WR 8 20 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805947WR 8 30 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1805944WR 40 8 40 Piston w/Pin, Retainer & Rings For engines with S/N 59208 and below
FP1804000 $14.15 . . Piston Pin Bushing .
FP1802200 $22.13 Std. Rod Bearing Pair .
FP1802201 $22.13 . 10 Rod Bearing Pair .
FP1802202 $20.61 20 Rod Bearing Pair .
FP1802203 $22.13 . 30 Rod Bearing Pair .
FP1802220 $60.29 Std. Main Bearing, Flanged .
FP1802221 $60.29   10 Main Bearing, Flanged .
FP1802222 $60.29 20 Main Bearing, Flanged .
FP1802223 $60.29 . 30 Main Bearing, Flanged .
FP1802216 $25.28 Std. Main Bearing, Plain .
FP1802217 $25.28 . 10 Main Bearing, Plain .
FP1802218 $25.28 20 Main Bearing, Plain .
FP1802219 $25.28 . 30 Main Bearing, Plain .
PGN6.9C . Overhaul Gasket Set .
FP1804003 $4.28 . . Connecting Rod Bolt .
FP1805866 $1.29 . Connecting Rod Nut .
FP1807974 $29.99 1 . Thermostat Kit 192 degree Thermostat

Page 73
International/Navistar Truck
32 M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L
420. OHV Diesel V8 (IDI), 4" Bore 1980-90
CYL. HEAD & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
3   2 Valve Cover Gasket 88-82 FP1804052 $17.32 . .
5   2 Head Gasket 88-82 FP1804259 $92.08 . .
.   1 Head gasket set 88-82 FP1811049 $158.79 . Int. manifold gskt. not incl.
Ref # Qty VALVE Years Part No. Size Desc.
19   8 Intake 88-82 FP1804330 $23.71 . Chrome plated stem; 1.8770" Head Dia., .3719" Stem Dia., 5.6880" O.A.L.
20   8 Exhaust 88-82 FP1811191 $22.05 . Chrome plated stem; 1.5950" Head Dia., .3719" Stem Dia., 5.6700" O.A.L.
24  32 Keeper 88-82 FP41339 $1.16 . 1 groove; Square cut key groove
24  32 Keeper 88-82 VK138 $1.02 . 1 groove; Square cut key groove; Carton pack 32
24  32 Keeper 88-82 VK138R $0.48 . 1 groove; Square cut key groove; Hardened
Ref # Qty VALVE SEAT Years Part No. Size Desc.
25   8 Exh. 88-83 FP1805249 $12.05 . 1.6690" OD, 1.3700" ID, .2710" Depth
25   8 Int. 88-83 FP1805250 $11.27 . 1.9425" OD, 1.6875" ID, .2480" Depth
Ref # Qty VALVE GUIDE Years Part No. Size Desc.
26  16 Guide 88-83 FP1805407 $5.12 . Exh. & Int.; .3750" ID, 2.6000" O.A.L.
Ref # Qty VALVE SPRING Years Part No. Size Desc.
27  16 Spring 88-83 FP317365 . Incl. damper; 2.0500" Free Height
Ref # Qty PUSH RODS Years Part No. Size Desc.
.  16 Push Rod 88-82 FP1804338 $4.28 . Install w/copper colored ball toward rocker arm; 9.9890" O.A.L.
Ref # Qty VALVE MISC. Years Part No. Size Desc.
32  16 Rotocap 88-83 FP1804467 $18.91 . .
Ref # Qty VALVE SEAL Years Part No. Size Desc.
41  16 Valve Stem Seal 88-83 FP681234 $1.02 . Umbrella type
41  16 Valve Stem Seal 88-83 FP1804420 $6.15 . Umbrella type; Fits Std. to .015" O/S valve stem; Rubber.
(continued on next page)

Page 74
International/Navistar Truck
32 (cont.) M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L
420. OHV Diesel V8 (IDI), 4" Bore 1980-90
CYL. HEAD & PARTS (cont.)
Ref # Qty ROCKER PARTS Years Part No. Size Desc.
.   8 Arm Assy. 88-82 R1119 $64.74 . Incl. 2-arms, 2-pivots & 1-retainer
67  16 Arm 88-82 R949 $19.41 . Incl. 1-rocker arm
IGNITION
. Qty IGNITION Years Part No. Size Desc.
.   8 Glow Plug 88-82 FP1819649 $26.89 . From Ser. No. 246734; Exc. Ser. Nos. 256300 through 256314, 256493, 268092 through 268106
.   8 Glow Plug 88-82 FP1804211 $26.93 . To Ser. No. 246733 and Ser. Nos. 256300 through 256314, 256493, 268092 through 268106
INT & EXH MANIFOLDS
. Qty Int. & Exh. Manifolds Years Part No. Size Desc.
.   1 Valley Pan Gasket Set 90-80 FP1813067 $106.34 . .
Camshaft GROUP
Ref # Qty TIMING Years Part No. Size Desc.
.   1 Gear Set 88-82 221-3342S $436.72 . Incl. 1 221-3342S $436.72
Ref # Qty Camshaft / Lifter Years Part No. Size Desc.
47   1 Camshaft 88-82 CS771 $557.08 . .
54  16 Lifter 88-82 FP1804353 $23.75 . Hyd. rlr.
.   1 Prelube 88-82 55-400 $7.22 . 4 oz. bottle; 1.5 oz. packet No. 55-403 $2.30 also avail.
FUEL SYSTEM & PARTS
. Qty FUEL FILTERS & PUMP Years Part No. Size Desc.
.   1 Mechanical Fuel Pump 88-83 FP1804495 $120.65 . .
(continued on next page)

Page 75
International/Navistar Truck
32
(cont.)
M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L
420. OHV Diesel V8 (IDI), 4" Bore 1980-90
COOLING SYSTEM


Ref # Qty WATER PUMP Years Part No. Size Desc.
1   1 Water Pump - Heavy Duty 88-83 FP1809374 $322.67 . .
12   1 Water Pump Gasket 88-83 FP1804136 $19.00 . .
Ref # Qty Thermostat Years Part No. Size Desc.
20   1 Thermostat 88-82 FP1807945 $28.45 . 192 Deg.
21   1 Thermostat Kit 88-82 FP1807974 $29.99 . 192 Deg.; Incl. gskt.
22   1 Thermostat Gasket 88-82 FP1804032 $5.04 . .
(continued on next page)

Page 76
International/Navistar Truck
32
(cont.)
M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L 420. OHV Diesel V8 (IDI), 4" Bore 1980-90
ENGINE BLOCK & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
3   1 Front Crankcase Cover Gasket 88-82 FP1804480 $37.92 . .
6.   1 Oil Pan Gasket Set 90-80 260-6054 . .
.   1 Chemicals 88-82 FP446839 $12.37 . Front cover; RTV Sealant
Ref # Qty GASKET SETS Years Part No. Size Desc.
.   1 Lower Gasket Set 88-82 FP1802213 $92.05 . .
.   1 Kit Gasket Set 90-80 260-1672 $230.46 . Int. manifold gskt. not incl.; Premium valve stem seals incl.
Ref # Qty Cam Bearings Years Part No. Size Desc.
19   1 Cam Set 88-82 FP1804475 $60.32 STD .
Ref # Qty FREEZE PLUGS Years Part No. Size Desc.
.   1 Stainless Block Plug Kit 88-84 381-8056 $34.34 . Incl. 7. centerless ground OD, stainless steel block plugs
(continued on next page)

Page 77
International/Navistar Truck
32
(cont.)
M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L 420. OHV Diesel V8 (IDI), 4" Bore 1980-90
Crankshaft/OIL PUMP
Ref # Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
47   1 Oil Seal 88-83 FP1804009 $36.35 . Viton®
.   1 Oil Seal Kit 88-82 5066 44.99 . (Seal & Sleeve)
Ref # Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
7.   1 Oil Seal 88-83 FP1816559 $39.69 . .
7.   1 Oil Seal 88-82 39608 53.23 . PTFE
7.   1 Oil Seal 88-82 3893V 85.70 . Viton®
8   1 Oil Seal Kit 88-83 FP1819733 $63.38 . .
9   1 Wear Sleeve 88-83 FP1816569 $36.35 . .
Ref # Qty Main bearings Years Part No. Size Desc.
.   1 Main Set 88-82 5110M $279.15   Std-10
20-30
.
38   4 Plain Main Brg. 88-82 FP1802216 $25.28 STD Position 1-2-4-5
38   4 Plain Main Brg. 88-82 FP1802217 $25.28 10 Position 1-2-4-5
38   4 Plain Main Brg. 88-82 FP1802218 $25.28 20 Position 1-2-4-5
38   4 Plain Main Brg. 88-82 FP1802219 $25.28 30 Position 1-2-4-5
39   1 Flanged Main Brg. 88-82 FP1802220 $60.29 STD Position 3
39   1 Flanged Main Brg. 88-82 FP1802221 $60.29 10 Position 3
39   1 Flanged Main Brg. 88-82 FP1802222 $60.29 20 Position 3
39   1 Flanged Main Brg. 88-82 FP1802223 $60.29 30 Position 3
Ref # Qty OIL PUMP Years Part No. Size Desc.
11   1 Oil Pump 88-83 FP1805398 $279.68 . .
(continued on next page)

Page 78
International/Navistar Truck
32
(cont.)
M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L 420. OHV Diesel V8 (IDI), 4" Bore 1980-90
CYLINDER COMPONENTS
Ref # Qty Pistons Years Part No. Size Desc.
13   8 Piston Body w/o Pin 88-84 FP1805851 $136.89 STD From Ser. No. 59208
13   8 Piston Body w/o Pin 88-84 FP1441102 $138.20 20 From Ser. No. 59208
13   8 Piston Body w/o Pin 88-84 FP1805854 $142.91 30 From Ser. No. 59208
13   8 Piston Body w/o Pin 88-84 FP180585140 $136.89 40 From Ser. No. 59208
13   8 Piston Body w/o Pin 83-82 FP1805231 $151.34 20 To Ser. No. 59207
13   8 Piston Body w/o Pin 83-82 FP1805232 $153.60 30 To Ser. No. 59207
13   8 Piston Body w/o Pin 83-82 FP180521240 $151.34 40 To Ser. No. 59207
13   8 Piston Body w/o Pin 83-82 FP1805851 $136.89 STD To Ser. No. 59207; Replace in sets only
13   8 Piston Body w/o Pin 83-82 FP1441102 $138.20 20 To Ser. No. 59207; Replace in sets only
13   8 Piston Body w/o Pin 83-82 FP1805854 $142.91 30 To Ser. No. 59207; Replace in sets only
13   8 Piston Body w/o Pin 83-82 FP180585140 $136.89 40 To Ser. No. 59207; Replace in sets only
14   8 Piston Kit w/Pin & Retainers 88-84 FP1805816 $156.89 STD From Ser. No. 59208
14   8 Piston Kit w/Pin & Retainers 88-84 FP1805818 $156.89 20 From Ser. No. 59208
14   8 Piston Kit w/Pin & Retainers 88-84 FP1805819 $160.42 30 From Ser. No. 59208
14   8 Piston Kit w/Pin & Retainers 83-82 FP1805816 $156.89 STD To Ser. No. 59207; Replace in sets only
14   8 Piston Kit w/Pin & Retainers 83-82 FP1805818 $156.89 20 To Ser. No. 59207; Replace in sets only
14   8 Piston Kit w/Pin & Retainers 83-82 FP1805819 $160.42 30 To Ser. No. 59207; Replace in sets only
15   8 Piston w/Pin, Retainer, Rings 88-84 FP1805816WR $220.96 STD From Ser. No. 59208
15   8 Piston w/Pin, Retainer, Rings 88-84 FP1805818WR $220.96 20 From Ser. No. 59208
15   8 Piston w/Pin, Retainer, Rings 88-84 FP1805819WR $215.57 30 From Ser. No. 59208
15   8 Piston w/Pin, Retainer, Rings 83-82 FP1805816WR $220.96 STD To Ser. No. 59207; Replace in sets only
15   8 Piston w/Pin, Retainer, Rings 83-82 FP1805818WR $220.96 20 To Ser. No. 59207; Replace in sets only
15   8 Piston w/Pin, Retainer, Rings 83-82 FP1805819WR $215.57 30 To Ser. No. 59207; Replace in sets only
16   8 Cast Piston 88-84 FPH729CP $78.92 STD From 10/3/83; Hypereutectic; 2-5/64", 1-7/64" Ring Groove, 1.937" CD, 1.1100" Pin Dia., Ricardo Cup Head; DUROSHIELD® skirt coated piston
16   8 Cast Piston 88-84 FPH729CP20 $78.92 20 From 10/3/83; Hypereutectic; 2-5/64", 1-7/64" Ring Groove, 1.937" CD, 1.1100" Pin Dia., Ricardo Cup Head; DUROSHIELD® skirt coated piston
(continued on next page)

Page 79
International/Navistar Truck
32
(cont.)
M/D Truck 6.9L Diesel Eng. H/D Truck 6.9L Diesel Eng.
6.9L
420. OHV Diesel V8 (IDI), 4" Bore 1980-90
CYLINDER COMPONENTS (cont.)
Ref # Qty Pistons (cont.) Years Part No. Size Desc.
16   8 Cast Piston 88-84 FPH729CP30 $78.92 30 From 10/3/83; Hypereutectic; 2-5/64", 1-7/64" Ring Groove, 1.937" CD, 1.1100" Pin Dia., Ricardo Cup Head; DUROSHIELD® skirt coated piston
16   8 Cast Piston - Individual 88-84 FPWH729CP $78.48 STD From 10/3/83; Hypereutectic; 2-5/64", 1-7/64" Ring Groove, 1.937" CD, 1.1100" Pin Dia., Ricardo Cup Head; DUROSHIELD® skirt coated piston
16   8 Cast Piston - Individual 88-84 FPWH729CP20 $78.48 20 From 10/3/83; Hypereutectic; 2-5/64", 1-7/64" Ring Groove, 1.937" CD, 1.1100" Pin Dia., Ricardo Cup Head; DUROSHIELD® skirt coated piston
16   8 Cast Piston - Individual 88-84 FPWH729CP30 $78.48 30 From 10/3/83; Hypereutectic; 2-5/64", 1-7/64" Ring Groove, 1.937" CD, 1.1100" Pin Dia., Ricardo Cup Head; DUROSHIELD® skirt coated piston
19   8 Pin 88-82 FP1804321 $18.97 . .
11  16 Piston Pin Retainer 88-82 FP1804308 $2.73 . .
29   8 Pin Bushing 88-82 FP1804000 $14.15 . .
Ref # Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
23  16 Con. Rod Bolt 88-83 FP1804003 $4.28 . .
24  16 Con. Rod Nut 88-83 FP1805866 $1.29 . .
27   8 Rod Pair 88-82 FP1802200 $22.13 STD .
27   8 Rod Pair 88-82 FP1802201 $22.13 10 .
27   8 Rod Pair 88-82 FP1802202 $20.61 20 .
27   8 Rod Pair 88-82 FP1802203 $22.13 30 .
Ref # Qty PISTON RINGS Years Part No. Size Desc.
33   8 Ring Set Single Cylinder 88-84 FP1802210 $29.26 20 .
33   8 Ring Set Single Cylinder 88-84 FP1802211 $36.57 30 .
33   8 Ring Set Single Cylinder 88-84 FP1802212 $39.48 40 .
33   8 Ring Set Single Cylinder 88-84 FP1802208 $30.15 STD 2-5/64, 1-7/64; 2nd ring gap is .060-.075" like O.E. ring
33   8 Ring Set Single Cylinder 83-82 FP1802210 $29.26 20 Use w/FP1441102 or FP1805818
33   8 Ring Set Single Cylinder 83-82 FP1802208 $30.15 STD Use w/FP1805851 or FP1805816; 2-5/64, 1-7/64; 2nd ring gap is .060-.075" like O.E. ring
33   8 Ring Set Single Cylinder 83-82 FP1802212 $39.48 40 Use w/FP1805851-40 or FP1805816-40
33   8 Ring Set Single Cylinder 83-82 FP1802211 $36.57 30 Use w/FP1805854 or FP1805819 $160.42
KITS
. Qty Overhaul Kit Years Part No. Size Desc.
.   1 In-Frame Overhaul Kit 88-82 FPIFK69L $1,885.99 . .
.   1 Complete Overhaul Kit 88-82 FPIFK69LOH $2,001.93 . .


Page 80

Overview
The 7.3 LITER diesel engine was first introduced in
1988. The 7.3 Liter designation was used until 1995.
In late 1993, the 7.3L DIT/T444E version of the engine
family was introduced and continues today as the
T444E. Both versions are used in On-Highway truck
and bus applications.
Engine Type.......................................... Diesel, 4-cycle
Configuration.............................................................V8
Displacement.............................444 cu. In. (7.3 Liters)
Bore and Stroke.................................4.110 x 4.180 in.
.......................................................(104.4 x 106.2 mm)
Combustion System...................7.3L = Direct Injection
....................................................and Indirect Injection
.......................................T444E = Direct Injection only.
Total Engine Weight (Dry)...........7.3L = 860 lb. (390 kg)
...............................................T444E = 930 lb. (422 kg)

The 7.3L can be identified by the permanent engine
number stamped on the front top left side of the engine.
The first three positions indicate the engine displacement.
The fourth digit indicates either naturally aspirated or
turbocharged. The fifth and sixth digits indicate the use
of the engine, for example M2 would indicate that the
engine was built for truck use. The seventh digit indicates
what country the engine was built in, for example the
letter U indicates that the engine was built in the U.S.A.
The rest of the digits represent the specific engine serial
number. The 7.3L engine serial numbers begin with
500001. A typical serial number would look like this:
73LFM2U456789.
The T444E can be identified by the serial number stamped
on the lower rear left hand side of the engine crankcase,
just right of the lube oil filter header. The 7.3DIT/T444E
engine serial numbers begin with 000500.



Page 81
International/Navistar Truck
7.3L In-Frame Overhaul -
Early engines
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK7.3E FP1813119WR 8 Std. Piston w/Pin, Retainer & Rings To Serial No 598753
FP1813120WR 8 10 Piston w/Pin, Retainer & Rings To Serial No 598753
FP1813121WR $205.24 8 20 Piston w/Pin, Retainer & Rings To Serial No 598753
FP1813122WR 8 30 Piston w/Pin, Retainer & Rings To Serial No 598753
FP1802200 $22.13 8 Std. Rod Bearing Pair .
FP1802201 $22.13 8 10 Rod Bearing Pair .
FP1802202 $20.61 8 20 Rod Bearing Pair .
FP1802203 $22.13 8 30 Rod Bearing Pair .
FP1802220 $60.29 1 Std. Main Bearing, Flanged .
FP1802221 $60.29 1 10 Main Bearing, Flanged .
FP1802222 $60.29 1 20 Main Bearing, Flanged .
FP1802223 $60.29 1 30 Main Bearing, Flanged .
FP1802216 $25.28 4 Std. Main Bearing, Plain .
FP1802217 $25.28 4 10 Main Bearing, Plain .
FP1802218 $25.28 4 20 Main Bearing, Plain .
FP1802219 $25.28 4 30 Main Bearing, Plain .
260-6054 1 . Oil Pan Gasket Set .
FP1811050 $302.00 1 . Head Gasket Set .
FP1813067 $106.34 1 . Valley Pan Gasket Set .
FP1807974 $29.99 1 . Thermostat Kit 192 degree Thermostat

Page 82
International/Navistar Truck
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK7.3L FP1816674WR $197.06 8 Std. Piston w/Pin, Retainer & Rings From Serial No 598754
FP1816676WR $185.91 8 20 Piston w/Pin, Retainer & Rings From Serial No 598754
FP1816677WR $184.13 8 30 Piston w/Pin, Retainer & Rings From Serial No 598754
FP1802200 $22.13 8 Std. Rod Bearing Pair .
FP1802201 $22.13 8 10 Rod Bearing Pair .
FP1802202 $20.61 8 20 Rod Bearing Pair .
FP1802203 $22.13 8 30 Rod Bearing Pair .
FP1802220 $60.29 1 Std. Main Bearing, Flanged .
FP1802221 $60.29 1 10 Main Bearing, Flanged .
FP1802222 $60.29 1 20 Main Bearing, Flanged .
FP1802223 $60.29 1 30 Main Bearing, Flanged .
FP1802216 $25.28 4 Std. Main Bearing, Plain .
FP1802217 $25.28 4 10 Main Bearing, Plain .
FP1802218 $25.28 4 20 Main Bearing, Plain .
FP1802219 $25.28 4 30 Main Bearing, Plain .
260-6054 1 . Oil Pan Gasket Set .
FP1811050 $302.00 1 . Head Gasket Set .
FP1813067 $106.34 1 . Valley Pan Gasket Set .
FP1807974 $29.99 1 . Thermostat Kit 192 degree Thermostat


Page 83
International/Navistar Truck
T444E In-Frame Overhaul
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFKT444E $2,480.77 FP1830953 $204.92 8 Std. Piston w/Pin, Retainer & Rings .
FP1830954 $213.14 8 20 Piston w/Pin, Retainer .
FP1830955 $206.67 8 30 Piston w/Pin, Retainer .
FP1830956 $215.20 8 40 Piston w/Pin, Retainer .
FP1812301 $18.86 8 Std. Rod Bearing Pair .
FP1812302 $18.94 8 10 Rod Bearing Pair .
FP1812303 $18.86 8 20 Rod Bearing Pair .
FP1812304 $17.43 8 30 Rod Bearing Pair .
FP1812325 $45.95 1 Std. Main Bearing, Flanged .
FP1812326 $63.49 1 10 Main Bearing, Flanged .
FP1812327 $61.87 1 20 Main Bearing, Flanged .
FP1812328 $58.64 1 30 Main Bearing, Flanged .
FP1812321 $25.36 4 Std. Main Bearing, Plain .
FP1812322 $25.36 4 10 Main Bearing, Plain .
FP1812323 $25.36 4 20 Main Bearing, Plain .
FP1812324 $25.36 4 30 Main Bearing, Plain .
PGT444S 1 . In-Frame Gasket Set .


Page 84
International/Navistar Truck
7.3L Complete Engine Overhaul -
Early engines
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK7.3EOH FP1813119WR 8 Std. Piston w/Pin, Retainer & Rings To Serial No 598753
FP1813120WR 8 10 Piston w/Pin, Retainer & Rings To Serial No 598753
FP1813121WR $205.24 8 20 Piston w/Pin, Retainer & Rings To Serial No 598753
FP1813122WR 8 30 Piston w/Pin, Retainer & Rings To Serial No 598753
FP1804000 $14.15 8 . Piston Pin Bushing .
FP1802200 $22.13 8 Std. Rod Bearing Pair .
FP1802201 $22.13 8 10 Rod Bearing Pair .
FP1802202 $20.61 8 20 Rod Bearing Pair .
FP1802203 $22.13 8 30 Rod Bearing Pair .
FP1802220 $60.29 1 Std. Main Bearing, Flanged .
FP1802221 $60.29 1 10 Main Bearing, Flanged .
FP1802222 $60.29 1 20 Main Bearing, Flanged .
FP1802223 $60.29 1 30 Main Bearing, Flanged .
FP1802216 $25.28 4 Std. Main Bearing, Plain .
FP1802217 $25.28 4 10 Main Bearing, Plain .
FP1802218 $25.28 4 20 Main Bearing, Plain .
FP1802219 $25.28 4 30 Main Bearing, Plain .
PGN7.3C 1 . Overhaul Gasket Set .
FP1813067 $106.34   . Valley Pan Gasket Set .
FP1804003 $4.28 . Connecting Rod Bolt .
FP1805866 $1.29 . . Connecting Rod Nut .
FP1807974 $29.99 . Thermostat Kit 192 degree Thermostat


Page 85
International/Navistar Truck
7.3L Complete Engine Overhaul - Late engines
Kit Number Component No. QTY. PART Size PART Desc. Part Appliction
FPIFK7.3LOH FP1816674WR $197.06 8 Std. Piston w/Pin, Retainer & Rings From Serial No 598754
FP1816676WR $185.91 8 20 Piston w/Pin, Retainer & Rings From Serial No 598754
FP1816677WR $184.13 8 30 Piston w/Pin, Retainer & Rings From Serial No 598754
FP1804000 $14.15 . . Piston Pin Bushing .
FP1802200 $22.13 Std. Rod Bearing Pair .
FP1802201 $22.13 . 10 Rod Bearing Pair .
FP1802202 $20.61 20 Rod Bearing Pair .
FP1802203 $22.13 . 30 Rod Bearing Pair .
FP1802220 $60.29 Std. Main Bearing, Flanged .
FP1802221 $60.29 . 10 Main Bearing, Flanged .
FP1802222 $60.29 20 Main Bearing, Flanged .
FP1802223 $60.29   30 Main Bearing, Flanged .
FP1802216 $25.28 Std. Main Bearing, Plain .
FP1802217 $25.28 . 10 Main Bearing, Plain .
FP1802218 $25.28 20 Main Bearing, Plain .
FP1802219 $25.28 . 30 Main Bearing, Plain .
PGN7.3C . Overhaul Gasket Set .
FP1813067 $106.34 . . Valley Pan Gasket Set .
FP1804003 $4.28 . Connecting Rod Bolt .
FP1805866 $1.29 . . Connecting Rod Nut .
FP1807974 $29.99 . Thermostat Kit 192 degree Thermostat

Page 86
International/Navistar Truck
33 M/D Truck 7.3L Diesel Eng.
7.3L
444 OHV Diesel V8 (IDI), 4.11" Bore 1988-93
CYL. HEAD & PARTS
.
Ref # Qty Gaskets Years Part No. Size Desc.
3   1 Valve Cover Gasket 93-88 FP1804052 $17.32 . .
5   2 Head Gasket 93-88 FP1809057 $93.71 . .
.   1 Head gasket set 93-88 FP1811050 $302.00 . Int. manifold gskt. not incl.
Ref # Qty VALVE Years Part No. Size Desc.
19   8 Intake 93-88 FP1804330 $23.71 . Chrome plated stem; 1.8770" Head Dia., .3719" Stem Dia., 5.6880" O.A.L.
20   8 Exhaust 93-88 FP1811191 $22.05 . Chrome plated stem; 1.5950" Head Dia., .3719" Stem Dia., 5.6700" O.A.L.
24  32 Keeper 93-88 FP41339 $1.16 . 1 groove; Square cut key groove
24  32 Keeper 93-88 VK138 $1.02 . 1 groove; Square cut key groove; Carton pack 32
24  32 Keeper 93-88 VK138R $0.48 . 1 groove; Square cut key groove; Hardened
Ref # Qty VALVE SEAT Years Part No. Size Desc.
25   8 Exh. 93-88 FP1805249 $12.05 . 1.6690" OD, 1.3700" ID, .2710" Depth
25   8 Int. 93-88 FP1805250 $11.27 . 1.9425" OD, 1.6875" ID, .2480" Depth
Ref # Qty VALVE GUIDE Years Part No. Size Desc.
26  16 Guide 93-88 FP1805407 $5.12 . Exh. & Int.; .3750" ID, 2.6000" O.A.L.
Ref # Qty VALVE SPRING Years Part No. Size Desc.
27  16 Spring 93-88 FP317365 . Incl. damper; 2.0500" Free Height
Ref # Qty PUSH RODS Years Part No. Size Desc.
.  16 Push Rod 93-88 FP1804338 $4.28 . Install w/copper colored ball toward rocker arm; 9.9890" O.A.L.
Ref # Qty VALVE MISC. Years Part No. Size Desc.
32  16 Rotocap 93-88 FP1804467 $18.91 . .
Ref # Qty VALVE SEAL Years Part No. Size Desc.
41   8 Valve Stem Seal 93-88 FP681234 $1.02 . Int.; Umbrella type
(continued on next page)

Page 87
International/Navistar Truck
33
(cont.)
M/D Truck 7.3L Diesel Eng.
7.3L
444 OHV Diesel V8 (IDI), 4.11" Bore 1988-93
CYL. HEAD & PARTS (cont.)
Ref # Qty VALVE SEAL (cont.) Years Part No. Size Desc.
41   8 Valve Stem Seal 93-88 FP1804420 $6.15 . Int.; Umbrella type; Fits Std. to .015" O/S valve stem; Rubber.
Ref # Qty ROCKER PARTS Years Part No. Size Desc.
.   8 Arm Assy. 93-88 R1119 $64.74 . Incl. 2-arms, 2-pivots & 1-retainer
44  16 Arm 93-88 R949 $19.41 . Incl. 1-rocker arm
INT & EXH MANIFOLDS
. Qty Int. & Exh. Manifolds Years Part No. Size Desc.
.   1 Valley Pan Gasket Set 93-88 FP1813067 $106.34 . .
Camshaft GROUP
.
Ref # Qty TIMING Years Part No. Size Desc.
.   1 Gear Set 93-88 221-3342S $436.72 . Incl. 1 221-3342S $436.72
Ref # Qty Camshaft / Lifter Years Part No. Size Desc.
47   1 Camshaft 93-88 CS771 $557.08 . .
54  16 Lifter 93-88 FP1804353 $23.75 . Hyd. rlr.
.   1 Prelube 93-88 55-400 $7.22 . 4 oz. bottle; 1.5 oz. packet No. 55-403 $2.30 also avail.
FUEL SYSTEM & PARTS
. Qty FUEL FILTERS & PUMP Years Part No. Size Desc.
.   1 Mechanical Fuel Pump 93-88 FP1804495 $120.65 . .
(continued on next page)

Page 88
International/Navistar Truck
33 (cont.) M/D Truck 7.3L Diesel Eng.
7.3L
444 OHV Diesel V8 (IDI), 4.11" Bore 1988-93
COOLING SYSTEM
.
Ref # Qty WATER PUMP Years Part No. Size Desc.
1   1 Water Pump - Heavy Duty 93-88 FP1809374 $322.67 . .
12   1 Water Pump Gasket 93-88 FP1804136 $19.00 . .
Ref # Qty Thermostat Years Part No. Size Desc.
20   1 Thermostat 93-88 FP1807945 $28.45 . 192 Deg.
21   1 Thermostat Kit 93-88 FP1807974 $29.99 . 192 Deg.; Incl. gskt.
22   1 Thermostat Gasket 93-88 FP1804032 $5.04 . .
(continued on next page)

Page 89
International/Navistar Truck
33
(cont.)
M/D Truck 7.3L Diesel Eng.
7.3L
444 OHV Diesel V8 (IDI), 4.11" Bore 1988-93
ENGINE BLOCK & PARTS
.
Ref # Qty Gaskets Years Part No. Size Desc.
3   1 Front Crankcase Cover Gasket 93-88 FP1804480 $37.92 . .
6.   1 Oil Pan Gasket Set 93-88 260-6054 . .
Ref # Qty GASKET SETS Years Part No. Size Desc.
.   1 Lower Gasket Set 93-88 FP1802213 $92.05 . .
.   1 Kit Gasket Set 93-88 260-1673 $189.04 . Int. manifold gskt. not incl.; Premium valve stem seals incl.
Ref # Qty Cam Bearings Years Part No. Size Desc.
19   1 Cam Set 93-88 FP1804475 $60.32 STD .
Ref # Qty FREEZE PLUGS Years Part No. Size Desc.
.   1 Stainless Block Plug Kit 93-88 381-8056 $34.34 . Incl. 7. centerless ground OD, stainless steel block plugs
(continued on next page)

Page 90
International/Navistar Truck
33
(cont.)
M/D Truck 7.3L Diesel Eng.
7.3L
444 OHV Diesel V8 (IDI), 4.11" Bore 1988-93
Crankshaft/OIL PUMP
.
Ref # Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
47   1 Oil Seal 93-88 FP1804009 $36.35 . Viton®
.   1 Oil Seal Kit 93-88 5066 44.99 . (Seal & Sleeve)
Ref # Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
7.   1 Oil Seal 93-88 FP1816559 $39.69 . .
7.   1 Oil Seal 93-88 39608 53.23 . PTFE
7.   1 Oil Seal 93-88 3893V 85.70 . Viton®
8   1 Oil Seal Kit 93-88 FP1819733 $63.38 . .
9   1 Wear Sleeve 93-88 FP1816569 $36.35 . .
Ref # Qty Main bearings Years Part No. Size Desc.
.   1 Main Set 93-88 5110M $279.15   Std-10
20-30
.
38   4 Plain Main Brg. 93-88 FP1802216 $25.28 STD Position 1-2-4-5
38   4 Plain Main Brg. 93-88 FP1802217 $25.28 10 Position 1-2-4-5
38   4 Plain Main Brg. 93-88 FP1802218 $25.28 20 Position 1-2-4-5
38   4 Plain Main Brg. 93-88 FP1802219 $25.28 30 Position 1-2-4-5
39   1 Flanged Main Brg. 93-88 FP1802220 $60.29 STD Position 3
39   1 Flanged Main Brg. 93-88 FP1802221 $60.29 10 Position 3
39   1 Flanged Main Brg. 93-88 FP1802222 $60.29 20 Position 3
39   1 Flanged Main Brg. 93-88 FP1802223 $60.29 30 Position 3
Ref # Qty OIL PUMP Years Part No. Size Desc.
11   1 Oil Pump 93-88 FP1805398 $279.68 . .
(continued on next page)

Page 91
International/Navistar Truck
33
(cont.)
M/D Truck 7.3L Diesel Eng.
7.3L
444 OHV Diesel V8 (IDI), 4.11" Bore 1988-93
CYLINDER COMPONENTS
.
Ref # Qty Pistons Years Part No. Size Desc.
13   8 Piston Body w/o Pin 93-88 FP1816562 $149.33 STD From Ser. No. 598754
13   8 Piston Body w/o Pin 93-88 FP1816658 $144.18 20 From Ser. No. 598754
13   8 Piston Body w/o Pin 93-88 FP1441703 $142.80 30 From Ser. No. 598754
13   8 Piston Body w/o Pin 93-88 FP1809109 $146.01 20 To Ser. No. 598753
13   8 Piston Body w/o Pin 93-88 FP1809110 $147.43 30 To Ser. No. 598753
14   8 Piston Kit w/Pin & Retainers 93-88 FP1816674 $155.72 STD From Ser. No. 598754
14   8 Piston Kit w/Pin & Retainers 93-88 FP1816676 $150.94 20 From Ser. No. 598754
14   8 Piston Kit w/Pin & Retainers 93-88 FP1816677 $149.50 30 From Ser. No. 598754
14   8 Piston Kit w/Pin & Retainers 93-88 FP1813121 $152.84 20 To Ser. No. 598753
14   8 Piston Kit w/Pin & Retainers 93-88 FP1813122 $147.81 30 To Ser. No. 598753
15   8 Piston w/Pin, Retainer, Rings 93-88 FP1816674WR $197.06 STD From Ser. No. 598754
15   8 Piston w/Pin, Retainer, Rings 93-88 FP1816676WR $185.91 20 From Ser. No. 598754
15   8 Piston w/Pin, Retainer, Rings 93-88 FP1816677WR $184.13 30 From Ser. No. 598754
15   8 Piston w/Pin, Retainer, Rings 93-88 FP1813121WR $205.24 20 To Ser. No. 598753
15   8 Piston w/Pin, Retainer, Rings 93-88 FP1813122WR 30 To Ser. No. 598753
19   8 Pin 93-88 FP1804321 $18.97 . .
11  16 Piston Pin Retainer 93-88 FP1804308 $2.73 . .
29   8 Pin Bushing 93-88 FP1804000 $14.15 . .
Ref # Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
23  16 Con. Rod Bolt 93-88 FP1804003 $4.28 . .
24  16 Con. Rod Nut 93-88 FP1805866 $1.29 . .
27   8 Rod Pair 93-88 FP1802200 $22.13 STD .
27   8 Rod Pair 93-88 FP1802201 $22.13 10 .
27   8 Rod Pair 93-88 FP1802202 $20.61 20 .
27   8 Rod Pair 93-88 FP1802203 $22.13 30 .
Ref # Qty PISTON RINGS Years Part No. Size Desc.
33   8 Ring Set Single Cylinder 93-88 FP1813173 $42.69 20 From Ser. No. 598754
33   8 Ring Set Single Cylinder 93-88 FP1813174 $33.20 30 From Ser. No. 598754
33 8 Ring Set Single Cylinder 88-93 FP1813171 $41.12 STD From Ser. No. 598754; 1-.118, 1-.136; 2nd ring gap is .030-.075" like O.E. ring
33 8 Ring Set Single Cylinder 88-93 FP1809146 $56.19 STD To Ser. No. 798753
33 8 Ring Set Single Cylinder 88-93 FP1809147 $71.39 10 To Ser. No. 798753
33 8 Ring Set Single Cylinder 88-93 FP1809148 $71.39 20 To Ser. No. 798753
33 8 Ring Set Single Cylinder 88-93 FP1809149 30 To Ser. No. 798753
KITS
. Qty Overhaul Kit Years Part No. Size Desc.
. 1 In-Frame Overhaul Kit 88-93 FPIFK73L $1,925.23 . From Ser. No. 598754
. 1 In-Frame Overhaul Kit 88-93 FPIFK73E $1,903.52 . To Ser. No. 798753
. 1 Complete Overhaul Kit 88-93 FPIFK73LOH $2,031.97 . From Ser. No. 598754
. 1 Complete Overhaul Kit 88-93 FPIFK73EOH $2,028.89 . To Ser. No. 598753


International/Navistar Truck
34 M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (IDI), 4.11" Bore 1993-94
CYL. HEAD & PARTS


Ref # Qty Gaskets Years Part No. Size Desc.
3 2 Valve Cover Gasket 93-94 FP1804052 $17.32 . .
5 2 Head Gaskt 93-94 FP1809057 $93.71 . .
. 1 Head Gasket Set 93-94 FP1811050 $302.00 . Int. manifold gskt. not incl.
Ref # Qty VALVE Years Part No. Size Desc.
10 8 Intake 93-94 FP1804330 $23.71 . Chrome plated stem; 1.6770" Head ia., .3719" Stem Dia., 5.6880" O.A.L.
24 32 Keeper 93-94 FP41339 $1.16 . 1 groove; Square cut key groove
Ref # Qty VALVE SEAT Years Part No. Size Desc.
25 8 Exhaut 93-94 FP1805249 $12.05 . 1.6690" OD, 1.3700" ID, 02710" Depth

(continued on next page)

Page 93
International/Navistar Truck
34
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (IDI), 4.11" Bore 1993-94
CYL. HEAD & PARTS (cont.)
Ref # Qty VALVE SEAT (cont.) Years Part No. Size Desc.
25   8 Int. 94-93 FP1805250 $11.27 . 1.9425" OD, 1.6875" ID, .2480" Depth
Ref # Qty VALVE GUIDE Years Part No. Size Desc.
26  16 Guide 94-93 FP1805407 $5.12 . Int. & Exh.; .3750" ID, 2.6000" O.A.L.
Ref # Qty VALVE SPRING Years Part No. Size Desc.
27  16 Spring 94-93 FP317365 . Int. & Exh.; Incl. damper; 2.0500" Free Height
Ref # Qty PUSH RODS Years Part No. Size Desc.
.  16 Push Rod 94-93 FP1804338 $4.28 . Install w/copper colored ball toward rocker arm; 9.9890" O.A.L.
Ref # Qty VALVE SEAL Years Part No. Size Desc.
41  16 Valve Stem Seal 94-93 MV1796C $1.51 . Umbrella type; Fits Std. to .015" O/S valve stem; Rubber
41  16 Valve Stem Seal 94-93 FP1804420 $6.15 . Umbrella type; Fits Std. to .015" O/S valve stem; Rubber.
INT & EXH MANIFOLDS
. Qty Int. & Exh. Manifolds Years Part No. Size Desc.
.   1 Valley Pan Gasket Set 94-93 FP1813067 $106.34 . .
FUEL SYSTEM & PARTS
. Qty FUEL FILTERS & PUMP Years Part No. Size Desc.
.   1 Mechanical Fuel Pump 94-93 FP1804495 $120.65 . .
COOLING SYSTEM
Ref # Qty WATER PUMP Years Part No. Size     Desc.
12   1 Water Pump Gasket 94-93 FP1804136 $19.00 .
Ref # Qty Thermostat Years Part No. Size     Desc.
20   1 Thermostat 94-93 FP1807945 $28.45 192 Deg.
21   1 Thermostat Kit 94-93 FP1807974 $29.99 192 Deg.; Incl. gskt.
22   1 Thermostat Gasket 94-93 FP1804032 $5.04 .
(continued on next page)

Page 94
International/Navistar Truck
34
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L 444 OHV Turbo-Diesel V8 (IDI), 4.11" Bore 1993-94
ENGINE BLOCK & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
3   1 Front Crankcase Cover Gasket 94-93 FP1804480 $37.92 . .
6.   1 Oil Pan Gasket Set 94-93 260-6054 . .
.   1 Chemicals 94-93 FP446839 $12.37 . Front Cover; RTV Sealant
Ref # Qty GASKET SETS Years Part No. Size Desc.
.   1 Lower Gasket Set 94-93 FP1802213 $92.05 . .
.   1 Complete Overhaul Gasket Set 94-93 FPPGN73C $385.43 . .
.   1 Kit Gasket Set 94-93 260-1673 $189.04 . Turbo mtg. gskts. not incl.; Int. manifold gskt. not incl.; Premium valve stem seals incl.
Ref # Qty Cam Bearings Years Part No. Size Desc.
19   1 Cam Set 94-93 FP1804475 $60.32 STD .
Ref # Qty FREEZE PLUGS Years Part No. Size Desc.
.   1 Stainless Block Plug Kit 94-93 381-8056 $34.34 . Incl. 7. centerless ground OD, stainless steel block plugs
(continued on next page)

Page 95
International/Navistar Truck
34
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (IDI), 4.11" Bore 1993-94
Crankshaft/OIL PUMP
Ref # Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
47   1 Oil Seal 94-93 FP1804009 $36.35 . Viton®
Ref # Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
7.   1 Oil Seal 94-93 FP1816559 $39.69 . .
8   1 Oil Seal Kit 94-93 FP1819733 $63.38 . .
9   1 Wear Sleeve 94-93 FP1816569 $36.35 . .
Ref # Qty Main bearings Years Part No. Size Desc.
38   4 Plain Main Brg. 94-93 FP1802216 $25.28 STD Position 1-2-4-5
38   4 Plain Main Brg. 94-93 FP1802217 $25.28 10 Position 1-2-4-5
38   4 Plain Main Brg. 94-93 FP1802218 $25.28 20 Position 1-2-4-5
38   4 Plain Main Brg. 94-93 FP1802219 $25.28 30 Position 1-2-4-5
39   1 Flanged Main Brg. 94-93 FP1802220 $60.29 STD Position 3
39   1 Flanged Main Brg. 94-93 FP1802221 $60.29 10 Position 3
39   1 Flanged Main Brg. 94-93 FP1802222 $60.29 20 Position 3
39   1 Flanged Main Brg. 94-93 FP1802223 $60.29 30 Position 3
Ref # Qty OIL PUMP Years Part No. Size Desc.
11   1 Oil Pump 94-93 FP1805398 $279.68 . .
(continued on next page)

Page 96
International/Navistar Truck
34 (cont.) M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (IDI), 4.11" Bore 1993-94
CYLINDER COMPONENTS
Ref # Qty Pistons Years Part No. Size Desc.
29   8 Pin Bushing 94-93 FP1804000 $14.15 . .
Ref # Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
23  16 Con. Rod Bolt 94-93 FP1804003 $4.28 . .
24  16 Con. Rod Nut 94-93 FP1805866 $1.29 . .
27   8 Rod Pair 94-93 FP1802200 $22.13 STD .
27   8 Rod Pair 94-93 FP1802201 $22.13 10 .
27   8 Rod Pair 94-93 FP1802202 $20.61 20 .
27   8 Rod Pair 94-93 FP1802203 $22.13 30 .


Page 97
International/Navistar Truck
35 M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (DI), 4.11" Bore 1994-2003
CYL. HEAD & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
5   2 Head Gasket 03-94 FP1826672 $101.60 . .
.   1 Head gasket set 03-94 FP1830826 $316.35 . Contains head Gaskets & valve stem seals only
69   1 Breather Seal Ring 03-94 FP1824452 $1.07 . Inner crankcase vent
69   1 Breather Seal Ring 03-94 FP1820784 $0.35 . Outer crankcase vent
Ref # Qty HEAD BOLTS Years Part No. Size Desc.
11  36 Head Bolt 03-94 FP1818092 $8.08 . .
Ref # Qty VALVE Years Part No. Size Desc.
19   8 Intake 03-94 FP1823453 $34.79 . .
20   8 Exhaust 03-94 FP1823452 $39.51 . .
24  32 Keeper 03-94 FP1810944 $1.22 . 5/16" valve stem
Ref # Qty VALVE GUIDE Years Part No. Size Desc.
26  16 Guide 03-94 FP1822862 $23.75 . .3146" ID, 2.4450" O.A.L.
Ref # Qty VALVE SEAL Years Part No. Size Desc.
41  16 Valve Stem Seal 03-94 FP1816179 $10.97 . Exh. & Int.
IGNITION
. Qty IGNITION Years Part No. Size Desc.
.   8 Glow Plug 03-94 FP1820697 $33.18 . .
(continued on next page)

Page 98
International/Navistar Truck
35
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (DI), 4.11" Bore 1994-2003
INT & EXH MANIFOLDS
Ref # Qty Int. & Exh. Manifolds Years Part No. Size Desc.
3   2 Exhaust Manifold Gasket 03-94 FP1814219 $18.89 . .
FUEL SYSTEM & PARTS
. Qty FUEL Injection Years Part No. Size Desc.
.   8 Fuel Injector Seal 03-94 FP1814695 $1.62 . Lower
. Qty FUEL FILTERS & PUMP Years Part No. Size Desc.
.   1 Mechanical Fuel Pump 03-94 FP1824415 $298.82 . .
.   1 O-Ring 03-94 FP1822708 $1.70 . Fuel pump seal
. Qty Turbo- Charger Years Part No. Size Desc.
.   2 Turbo Ring 03-94 FP702299 . Turbo sealing ring
.   1 Turbo- Charger Mounting Gasket 03-94 FP1822120 $10.34 . .
.   1 Rect. or Square Seal 03-94 FP1818372 $8.86 . Compressor outlet
.   2 O-Ring 03-94 FP1815561 $1.81 . Oil drain
.   2 O-Ring 03-94 FP1815560 $1.35 . Oil supply
.   1 Turbo Oil Injection Pump Gskt 03-94 FP1825163 $17.25 . From Ser. No. 213855 through Ser. No. 214133 and from Ser. No. 216544
(continued on next page)

Page 99
International/Navistar Truck
35
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (DI), 4.11" Bore 1994-2003
COOLING SYSTEM
Ref # Qty WATER PUMP Years Part No. Size Desc.
13   1 Rect. or Square Seal 03-94 FP1818397 $1.70 . Water pump inlet
.   1 Water Pump Seal Ring 03-94 FP1831713 $8.30 . .
Ref # Qty Thermostat Years Part No. Size Desc.
.   1 Water Outlet Gasket 03-94 FP1821880 $3.05 . .
continued on next page)

Page 100
International/Navistar Truck
35
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (DI), 4.11" Bore 1994-2003
ENGINE BLOCK & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
.   1 Chemicals 03-94 FP1816593 $34.85 . Oil pan; RTV Sealant
10   1 O-Ring 03-94 FP875519 $0.86 . Dipstick
11   1 Drain Plug Gasket 03-94 FP1822712 $5.87 . .
Ref # Qty GASKET SETS Years Part No. Size Desc.
.   1 In-Frame Gasket Set 03-94 FPPGT444S $408.35 . Valve cover gskts. not incl.; Head bolts not incl.; Premium valve stem seals incl.
Ref # Qty Cam Bearings Years Part No. Size Desc.
19   1 Cam Set 03-94 FP1812317 $52.28 STD .
Ref # Qty FREEZE PLUGS Years Part No. Size Desc.
.   1 Stainless Block Plug Kit 03-94 381-8088 $26.64 . Incl. 7. centerless ground OD, stainless steel block plugs
(continued on next page)

Page 101
International/Navistar Truck
35
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (DI), 4.11" Bore 1994-2003

Crankshaft/OIL PUMP

Ref # Qty SEALS -
Front Crankshaft
Years Part No. Size Desc.
47 1 Oil seal kit 94-03 FP1812376 $34.88 . .
. 1 Wear sleeve 94-03 FP1814607 $14.25 . .
Ref # Qty SEALS -
Rear Crankshaft
Years Part No. Size Desc.
8 1 Oil seal kit 94-03 FP1812329 $79.29 . .
Ref # Qty Main bearings Years Part No. Size Desc.
38 4 Plain main bearing 94-03 FP1812321 $25.36 STD Position 1-2-3-4
38 4 Plain main bearing 94-03 FP1812322 $25.36 10 Position 1-2-3-4
38 4 Plain main bearing 94-03 FP1812323 $25.36 20 Position 1-2-3-4
38 4 Plain main bearing 94-03 FP1812324 $25.36 30 Position 1-2-3-4
39 1 Flanged main bearing 94-03 FP1812325 $45.95 STD Position 5
39 1 Flanged main bearing 94-03 FP1812326 $63.49 10 Position 5
39 1 Flanged main bearing 94-03 FP1812327 $61.87 20 Position 5
39 1 Flanged main bearing 94-03 FP1812328 $58.64 30 Position 5
Ref # Qty OIL PUMP Years Part No. Size Desc.
11 1 Oil pump 94-03 FP1830813 $171.64 . .
22 1 Oil pump inlet tube gasket 94-03 FP1823671 $5.33 . Oil suction tube to oil pump; From Ser. No. 375550
22 1 Oil pump inlet tube gasket 94-03 FP1815899 $6.42 . Oil suction tube to oil pump; To Ser. No. 375549
. 1 Lo filter adapter gasket 94-03 FP1831665 $14.20 . .
26 1 Oil pump gasket 94-03 FP1815898 $20.46 . High pressure pump flange gasket
26 1 Oil pump gasket 94-03 FP1831516 $3.31 . Pump mounting

(continued on next page)

Page 102
International/Navistar Truck
35
(cont.)
M/D Truck 7.3L Turbo-Diesel Eng.
7.3L
444 OHV Turbo-Diesel V8 (DI), 4.11" Bore 1994-2003
CYLINDER COMPONENTS
Ref # Qty Pistons Years Part No. Size Desc.
13   8 Piston Body w/o Pin 03-94 FP1824284 $170.02 STD .
13   8 Piston Body w/o Pin 03-94 FP1830898 $196.39 10 .
13   8 Piston Body w/o Pin 03-94 FP1830899 $171.66 20 .
13   8 Piston Body w/o Pin 03-94 FP1830900 $197.00 30 .
14   8 Piston Kit w/Pin & Retainers 03-94 FP1830898WP $201.90 10 .
14   8 Piston Kit w/Pin & Retainers 03-94 FP1824284WP $177.95 STD Also available as Sealed Power No. 2767PN $171.43
14   8 Piston Kit w/Pin & Retainers 03-94 FP1830899WP $195.44 20 Also available as Sealed Power No. 2767PN $171.43 20
14   8 Piston Kit w/Pin & Retainers 03-94 FP1830900WP $220.95 30 Also available as Sealed Power No. 2767PN $171.43 30
15   8 Piston w/Pin, Retainer, Rings 03-94 FP1830953 $204.92 STD .
15   8 Piston w/Pin, Retainer, Rings 03-94 FP1830954 $213.14 10 .
15   8 Piston w/Pin, Retainer, Rings 03-94 FP1830955 $206.67 20 .
15   8 Piston w/Pin, Retainer, Rings 03-94 FP1830956 $215.20 30 .
19   8 Pin 03-94 FP1809339 $23.79 . .
11  16 Piston Pin Retainer 03-94 FP1814326 $2.04 . .
29   8 Pin Bushing 03-94 FP1812457 $14.15 . .
Ref # Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
27   8 Rod Pair 03-94 FP1812301 $18.86 STD .
27   8 Rod Pair 03-94 FP1812302 $18.94 10 .
27   8 Rod Pair 03-94 FP1812303 $18.86 20 .
27   8 Rod Pair 03-94 FP1812304 $17.43 30 .
Ref # Qty PISTON RINGS Years Part No. Size Desc.
33   8 Ring Set Single Cylinder 03-94 FP1830950 $61.79 10 1-1/8, 1-5/64, 1-.136
33   8 Ring Set Single Cylinder 03-94 FP1830951 $61.79 20 1-1/8, 1-5/64, 1-.136
33   8 Ring Set Single Cylinder 03-94 FP1830952 $61.79 30 1-1/8, 1-5/64, 1-.136
33   8 Ring Set Single Cylinder 03-94 FP1830949 $72.97 STD 1-1/8, 1-5/64, 1-.136; 2nd ring gap is .060-.075" like O.E. ring
KITS
. Qty Overhaul Kit Years Part No. Size     Desc.
.   1 In-Frame Overhaul Kit 03-94 FPIFKT444E $2,480.77 .


Page 103
International/Navistar Truck
36 H/D Truck MV446 Eng.
7.3L
446 OHV V8 (16 Valve), 4.125" Bore 1975-81
CYL. HEAD & PARTS
Qty VALVE Years Part No. Size Desc.
  8 Intake 81-75 V2523 $29.64   Std Only Chrome plated stem; 2.0540" Head Dia., .3725" Stem Dia., 5.4670" O.A.L.
  8 Exhaust 81-75 V2090X $36.38   Std Only Chrome plated stem; 1.5350" Head Dia., .3720" Stem Dia., 5.4820" O.A.L.
 32 Keeper 81-75 FP41339 $1.16 . 1 groove; Square cut key groove
 32 Keeper 81-75 VK138 $1.02 . 1 groove; Square cut key groove; Carton pack 32
 32 Keeper 81-75 VK138R $0.48 . 1 groove; Square cut key groove; Hardened
Qty VALVE SEAT Years Part No. Size Desc.
  8 Int. 81-75 245-2125-1 $7.88   Std Only 2.1305" OD, 1.8125" ID, .2480" Depth
Qty VALVE GUIDE Years Part No. Size Desc.
 16 Guide 81-75 VG660 $4.76 . .3745" ID, 2.6000" O.A.L.
Qty VALVE SPRING Years Part No. Size Desc.
 16 Spring 81-75 FP317365 . Incl. damper; 2.0500" Free Height
Qty PUSH RODS Years Part No. Size Desc.
 16 Push Rod 81-75 RP3201 $5.14 . 10.3460" O.A.L.
Qty VALVE MISC. Years Part No. Size Desc.
  8 Rotocap Assy. 81-75 FPRC126SA . Exh.; Incl. Rotocap & Valve Spring
  8 Rotocap 81-75 FP443128 $15.82 . Exh.
Qty VALVE SEAL Years Part No. Size Desc.
 16 Valve Stem Seal 81-75 FP156541 $2.69 . Installation requires valve guide machining; Polyacrylate
Camshaft GROUP
Qty TIMING Years Part No. Size Desc.
  1 Gear Set 81-75 221-3335S $133.73 . Incl. 1 221-3329A, 1 221-3334.
Qty Camshaft / Lifter Years Part No. Size Desc.
 16 Lifter 81-75 FP446571 $7.58 . Hyd.; w/2 grooves
  1 Prelube 81-75 55-400 $7.22 . 4 oz. bottle; 1.5 oz. packet No. 55-403 $2.30 also avail.
ENGINE BLOCK & PARTS
Qty Gaskets Years Part No. Size Desc.
  1 Oil Pan Gasket Set 81-75 260-6054 . .
Qty GASKET SETS Years Part No. Size Desc.
  1 Kit Gasket Set 81-75 260-1117 $165.65 . Int. manifold gskt. not incl.; Premium valve stem seals incl.
Qty Cam Bearings Years Part No. Size Desc.
  1 Cam Set 81-75 FP1804475 $60.32 STD .
Crankshaft/OIL PUMP
Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
  1 Oil Seal 81-75 FP1804009 $36.35 . Viton®
  1 Oil Seal Kit 81-75 FP1808751 $38.02 . .
  1 Oil Seal Kit 81-75 5064 34.81 . (Seal & Sleeve)
Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
  1 Oil Seal 81-75 2218 54.71 . .
  1 Wear Sleeve 81-75 FP1816569 $36.35 . .
Qty Main bearings Years Part No. Size Desc.
  1 Main Set 81-75 5082M $148.36   Std-10- 20 .
Qty OIL PUMP Years Part No. Size Desc.
  1 Oil Pump 81-75 224-41189 $167.67 . Repl. O.E. No. 446455C91
CYLINDER COMPONENTS
Qty Liners Years Part No. Size Desc.
  8 Repair Sleeve 81-75 SL23Y $105.01   Std Only 1/8" wall, must be cut to correct length
  8 Repair Sleeve 81-75 SL23M $102.42   Std Only 3/32" wall, must be cut to correct length
(continued on next page)

Page 104
International/Navistar Truck
36
(cont.)
H/D Truck MV446 Eng.
7.3L
446 OHV V8 (16 Valve), 4.125" Bore 1975-81
CYLINDER COMPONENTS (cont.)
Qty Pistons Years Part No.                 Size Desc.
  8 Cast Piston - Individual 81-75 WH999P  Std-20- 30
40-60
MV446 Engs.; Hypereutectic; 2-3/32", 1-3/16" Ring Groove, 1.900" CD, 1.0200" Pin Dia., Recessed Head .327" deep x 3.320" dia.
Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
  8 Rod Pair 81-75 FP3730CP $22.10 . .
  8 Rod Pair 81-75 FP3730CP10 $22.07 . .
  8 Rod Pair 81-75 FP3730CP20 $18.70 . .
  8 Rod Pair 81-75 FP3730CP30 $22.05 . .
  8 Rod Pair 81-75 FP3730CP40 . .
Qty PISTON RINGS Years Part No. Size Desc.
  1 Premium Set 81-75 E404K $374.42   Std-60 H/D use; Highway use; 2-3/32, 1-3/16
  1 Premium Set 81-75 E273K $201.34   Std-20 30
40-60
L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
  1 Standard Set 81-75 E422X30  30 L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
  8 Premium Single Cylinder Set 81-75 WE404K  Std-30 H/D use; Highway use; 2-3/32, 1-3/16
  8 Premium Single Cylinder Set 81-75 WE273K $27.52   Std-20- 30
40-60
L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16

KITS
RERING KIT Qty Premium Kit No. Qty Economy Kit No.
Years Desc.
81-75 L/D or pick-up & delivery use; Int. manifold gskt. not incl. Re-ring  1 FP2056043 $497.45 . -----
81-75 H/D or Highway use; Int. manifold gskt. not incl. Re-ring 1 FP205705 $415.21 . -----
81-75 Nat. Gas or LPG; Int. manifold gskt. not incl. Re-ring . ----- 1 FP205205 $465.09


37 H/D Truck MV446 Eng. (LPG or Natural Gas)
7.3L
446 OHV NG V8 (16 Valve), 4.125" Bore 1975-81
CYL. HEAD & PARTS
Qty VALVE Years Part No. Size Desc.
  8 Intake . V2523 $29.64   Std Only Chrome plated stem; 2.0540" Head Dia., .3725" Stem Dia., 5.4670" O.A.L.
  8 Exhaust . V2090X $36.38   Std Only Chrome plated stem; 1.5350" Head Dia., .3720" Stem Dia., 5.4820" O.A.L.
 32 Keeper . FP41339 $1.16 . 1 groove; Square cut key groove
 32 Keeper . VK138 $1.02 . 1 groove; Square cut key groove; Carton pack 32
 32 Keeper . VK138R $0.48 . 1 groove; Square cut key groove; Hardened
Qty VALVE SEAT Years Part No. Size Desc.
  8 Int. . 245-2125-1 $7.88   Std Only 2.1305" OD, 1.8125" ID, .2480" Depth
Qty VALVE GUIDE Years Part No. Size Desc.
 16 Guide . VG660 $4.76 . .3745" ID, 2.6000" O.A.L.
Qty VALVE SPRING Years Part No. Size Desc.
 16 Spring . FP317365 . Incl. damper; 2.0500" Free Height
Qty PUSH RODS Years Part No. Size Desc.
 16 Push Rod . RP3201 $5.14 . 10.3460" O.A.L.
Qty VALVE SEAL Years Part No. Size Desc.
 16 Valve Stem Seal . ST2002 $3.36 . Installation requires valve guide machining; Polyacrylate
 16 Valve Stem Seal . FP156541 $2.69 . Installation requires valve guide machining; Polyacrylate
 16 Valve Stem Seal Bulk . ST2002BC $2.76 . Positive type; Installation requires valve guide machining; Carton of 100; Polyacrylate
Camshaft GROUP
Qty TIMING Years Part No. Size Desc.
  1 Gear Set . 221-3335S $133.73 . Incl. 1 221-3329A, 1 221-3334.
Qty Camshaft / Lifter Years Part No. Size Desc.
 16 Lifter . FP446571 $7.58 . Hyd.; w/2 grooves
  1 Prelube . 55-400 $7.22 . 4 oz. bottle; 1.5 oz. packet No. 55-403 $2.30 also avail.
ENGINE BLOCK & PARTS
Qty Gaskets Years Part No. Size Desc.
  1 Oil Pan Gasket Set 81-75 260-6054 . .
(continued on next page)

Page 105
International/Navistar Truck
37
(cont.)
H/D Truck MV446 Eng. (LPG or Natural Gas)
7.3L
446 OHV NG V8 (16 Valve), 4.125" Bore 1975-81
ENGINE BLOCK & PARTS (cont.)
Qty GASKET SETS Years Part No. Size Desc.
  1 Kit Gasket Set . 260-1117 $165.65 . Premium valve stem seals incl.
Qty Cam Bearings Years Part No. Size Desc.
  1 Cam Set . FP1804475 $60.32 STD .
Crankshaft/OIL PUMP
Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
  1 Oil Seal 81-75 FP1804009 $36.35 . Viton®
  1 Oil Seal Kit 81-75 FP1808751 $38.02 . .
Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
  1 Oil Seal 81-75 2218 54.71 . .
  1 Wear Sleeve 81-75 FP1816569 $36.35 . .
Qty Main bearings Years Part No. Size Desc.
  1 Main Set . 5082M $148.36   Std-10- 20 .
Qty OIL PUMP Years Part No. Size Desc.
  1 Oil Pump . 224-41189 $167.67 . Repl. O.E. No. 446455C91
CYLINDER COMPONENTS
Qty Liners Years Part No. Size Desc.
  8 Repair Sleeve . SL23Y $105.01   Std Only 1/8" wall, must be cut to correct length
  8 Repair Sleeve . SL23M $102.42   Std Only 3/32" wall, must be cut to correct length
Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
  8 Rod Pair 81-75 FP3730CP40 . .
  8 Rod Pair . FP3730CP $22.10 . .
  8 Rod Pair . FP3730CP10 $22.07 . .
  8 Rod Pair . FP3730CP20 $18.70 . .
  8 Rod Pair . FP3730CP30 $22.05 . .
Qty PISTON RINGS Years Part No. Size Desc.
  1 Standard Set . E422X3030 . 2-3/32, 1-3/16
.
38 M/D Truck RD450, RED450, RED450A Engs.
7.4L
450 OHV L6 (12 Valve), 4.375" Bore 1961-73
CYL. HEAD & PARTS
Qty VALVE SEAT Years Part No. Size Desc.
  6. Exh. 73-61 245-1875-1N $22.08   Std Only . Premium Material; 1.8810" OD, 1.6100" ID, .2485" Depth
  6. Exh. 73-61 245-1875-1 $7.22   Std Only 1.8810" OD, 1.6100" ID, .2485" Depth
Qty VALVE SPRING Years Part No. Size Desc.
 12 Spring 73-61 VS336 $4.95 . Inner; 2.3430" Free Height
 12 Spring 73-61 VS337 $13.34 . Outer; 2.5620" Free Height
 12 Spring Insert 73-61 259-303C $0.40 . .015"; ID .703"; Carton of 100
 12 Spring Insert 73-61 259-303B $0.33 . .030"; ID .703"; Carton of 100
 12 Spring Insert 73-61 259-303A $0.35 . .060"; ID .703"; Carton of 100
 12 Spring Insert 73-61 259-303ARS $0.38 . .060"; ID .703"; Carton of 500
Qty VALVE SEAL Years Part No. Size Desc.
 12 Valve Stem Seal 73-61 ST2007 $4.60 . Positive type; Rubber
  6. O-Ring 73-61 FP111024 $1.35 . Int.; Rubber
Crankshaft/OIL PUMP
Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
  1 Wear Sleeve 73-61 FP1816569 $36.35 . .
  1 Oil Seal 73-61 417316 23.99 . .
CYLINDER COMPONENTS
Qty PISTON RINGS Years Part No. Size Desc.
  1 Premium Set 69-61 5642KX $275.27   Std Only Eng. Ser. Nos. 118530 to 118542, 118562 to 119569, 119634 to 119666 & From 119670; 2-3/32, 1-3/16
  6. Premium Single Cylinder Set    69-61 W-5642KX  Std Only Eng. Ser. Nos. 118530 to 118542, 118562 to 119569, 119634 to 119666 & From 119670; 2-3/32, 1-3/16


Page 106
International/Navistar Truck
39 H/D Truck RD450, RED450, RED450A Engs.
7.4L
450 OHV L6 (12 Valve), 4.375" Bore 1960-74
CYL. HEAD & PARTS
Qty VALVE SEAT Years Part No.                 Size Desc.
  6. Exh. 73-60 245-1875-1N $22.08   Std Only Premium Material; 1.8810" OD, 1.6100" ID, .2485" Depth
  6. Exh. 73-60 245-1875-1 $7.22   Std Only 1.8810" OD, 1.6100" ID, .2485" Depth
Qty VALVE SPRING Years Part No. Size Desc.
 12 Spring 73-60 VS336 $4.95 . Inner; 2.3430" Free Height
 12 Spring 73-60 VS337 $13.34 . Outer; 2.5620" Free Height
 12 Spring Insert 73-60 259-303C $0.40 . .015"; ID .703"; Carton of 100
 12 Spring Insert 73-60 259-303B $0.33 . .030"; ID .703"; Carton of 100
 12 Spring Insert 73-60 259-303A $0.35 . .060"; ID .703"; Carton of 100
 12 Spring Insert 73-60 259-303ARS $0.38 . .060"; ID .703"; Carton of 500
Qty VALVE SEAL Years Part No. Size Desc.
 12 Valve Stem Seal 73-60 ST2007 $4.60 . Positive type; Rubber
  6. O-Ring 73-60 FP111024 $1.35 . Int.; Rubber
Crankshaft/OIL PUMP
Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
  1 Wear Sleeve 74-60 FP1816569 $36.35 . .
  1 Oil Seal 74-60 417316 23.99 . .
CYLINDER COMPONENTS
Qty PISTON RINGS Years Part No. Size Desc.
  1 Premium Set 73-60 5642KX $275.27   Std Only Eng. Ser. Nos. 118530 to 118542, 118562 to 119569, 119634 to 119666 & From 119670; 2-3/32, 1-3/16
  6. Premium Single Cylinder Set 73-60 W-5642KX  Std Only Eng. Ser. Nos. 118530 to 118542, 118562 to 119569, 119634 to 119666 & From 119670; 2-3/32, 1-3/16
.
40 M/D Truck V461 Eng.
7.6L
461. OHV V8 (16 Valve),  4.125" B ore 1961-64
CYL. HEAD & PARTS
Qty VALVE Years Part No. Size Desc.
 32 Keeper 64-61 VK140 $1.32 . .
Qty VALVE SPRING Years Part No. Size Desc.
 16 Spring 64-61 FP317365 . Late Engs.; Incl. damper; 2.0500" Free Height
Qty VALVE MISC. Years Part No. Size Desc.
  8 Rotocap Assy. 64-61 FPRC126SA . Exh.; Late Engs.; Incl. Rotocap & Valve Spring
  8 Rotocap 64-61 FP443128 $15.82 . Exh.; Late Engs.
Qty VALVE SEAL Years Part No. Size Desc.
 16 Valve Stem Seal 64-61 ST2007 $4.60 . Positive type; Rubber
 16 O-Ring 64-61 FP111024 $1.35 . From Ser. No. 139494; Rubber
 16 Valve Stem Seal 64-61 MV1551 $0.67 . Late Engs.; O-Ring; Carton of 50; Rubber
Camshaft GROUP
Qty Camshaft / Lifter Years Part No. Size Desc.
  1 Camshaft 64-61 CS218 $200.41 . Use iron oil pump drive gear.
  1 Prelube 64-61 55-400 $7.22 . 4 oz. bottle; 1.5 oz. packet No. 55-403 $2.30 also avail.
ENGINE BLOCK & PARTS
Qty Gaskets Years Part No. Size Desc.
  1 Oil Pan Gasket 64-61 FP448428 $6.26 . .
Qty Cam Bearings Years Part No. Size Desc.
  1 Cam Set 64-61 FP448139 $98.42 STD .
Crankshaft/OIL PUMP
Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
  1 Redi-Sleeve 64-61 99248 55.60 . .
  1 Oil Seal 64-61 7581H 38.44 . .
Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
  1 Oil Seal 64-61 5112S 0.00 . .
CYLINDER COMPONENTS
Qty Pistons Years Part No. Size Desc.
  8 Pin Bushing 64-61 2199Y20 $10.77 . .
Qty PISTON RINGS Years Part No. Size Desc.
  1 Premium Set 64-61 E404K $374.42   Std-60 H/D use; Highway use; 2-3/32, 1-3/16

(continued on next page)

Page 107
International/Navistar Truck
40
(cont.)
M/D Truck V461 Eng.
7.6L
461. OHV V8 (16 Valve), 4.125" Bore 1961-64
CYLINDER COMPONENTS (cont.)
Qty PISTON RINGS (cont.) Years Part No. Size Desc.
  1 Premium Set 64-61 E273K $201.34   Std-20-30
40-60
L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
  1 Standard Set 64-61 E422X30 30 L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
  8 Premium Single Cylinder Set 64-61 WE404K  Std-30 H/D use; Highway use; 2-3/32, 1-3/16
  8 Premium Single Cylinder Set 64-61 WE273K $27.52   Std-20-30
40-60
L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
.
41 H/D Truck V461 Eng.
7.6L
461. OHV V8 (16 Valve), 4.125" Bore 1960-64
CYL. HEAD & PARTS
Qty VALVE Years Part No. Desc.
 32 Keeper 64-60 VK140 $1.32 .
Qty VALVE SPRING Years Part No. Desc.
 16 Spring 64-60 FP317365 Late Engs.; Incl. damper; 2.0500" Free Height
 16 Spring 64-60 VS693 $3.68 Late Engs.; Incl. damper; 2.0500" Free Height
Qty VALVE MISC. Years Part No. Desc.
  8 Rotocap Assy. 64-60 FPRC126SA Exh.; Late Engs.; Incl. Rotocap & Valve Spring
  8 Rotocap 64-60 FP443128 $15.82 Exh.; Late Engs.
Qty VALVE SEAL Years Part No. Desc.
 16 Valve Stem Seal 64-60 ST2007 $4.60 Positive type; Rubber
 16 O-Ring 64-60 FP111024 $1.35 From Ser. No. 139494; Rubber
 16 Valve Stem Seal 64-60 MV1551 $0.67 Late Engs.; O-Ring; Carton of 50; Rubber
Camshaft GROUP
Qty Camshaft / Lifter Years Part No. Desc.
  1 Camshaft 64-60 CS218 $200.41 Use iron oil pump drive gear.
  1 Prelube 64-60 55-400 $7.22 4 oz. bottle; 1.5 oz. packet No. 55-403 $2.30 also avail.
ENGINE BLOCK & PARTS
Qty Gaskets Years Part No. Desc.
  1 Oil Pan Gasket 64-60 FP448428 $6.26 .
Qty Cam Bearings Years Part No. Desc.
  1 Cam Set 64-60 FP448139 $98.42 .
Crankshaft/OIL PUMP
Qty SEALS -
FRONT CRANK
Years Part No. Desc.
  1 Redi-Sleeve 64-60 99248 55.60 .
  1 Oil Seal 64-60 7581H 38.44 .
Qty SEALS -
REAR CRANK
Years Part No. Desc.
  1 Oil Seal 64-60 5112S 0.00 .
CYLINDER COMPONENTS
Qty Pistons Years Part No. Size Desc.
  8 Pin Bushing 64-60 2199Y20 $10.77 . .
Qty PISTON RINGS Years Part No. Size Desc.
  1 Premium Set 64-60 E404K $374.42   Std-60 H/D use; Highway use; 2-3/32, 1-3/16
  1 Premium Set 64-60 E273K $201.34   Std-20-30
40-60
L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
  1 Standard Set 64-60 E422X30  30 L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
  8 Premium Single Cylinder Set 64-60 WE404K  Std-30 H/D use; Highway use; 2-3/32, 1-3/16
  8 Premium Single Cylinder Set 64-60 WE273K $27.52   Std-20-30
40-60
L/D, Pick-up & Delivery Service; 2-3/32, 1-3/16
.
42 M/D Truck DV462, DV462B Eng
7.6L
461. OH s. H/D Truck DV462, DV462B Engs.
V Diesel V8 (16 Valve), 4.125" Bore 1966-73
CYL. HEAD & PARTS
Qty VALVE Years Part No. Size Desc.
 32 Keeper 73-66 FP41339 $1.16 . 1 groove; Square cut key groove
 32 Keeper 73-66 VK138 $1.02 . 1 groove; Square cut key groove; Carton pack 32
 32 Keeper 73-66 VK138R $0.48 . 1 groove; Square cut key groove; Hardened
Qty VALVE SPRING Years Part No. Size Desc.
 16 Spring 73-66 FP317365 . Incl. damper; 2.0500" Free Height
(continued on next page)

Page 108
International/Navistar Truck
42 (cont.) M/D Truck DV462, DV462B Engs. H/D Truck DV462, DV462B Engs.
7.6L
461. OHV Diesel V8 (16 Valve), 4.125" Bore 1966-73
CYL. HEAD & PARTS (cont.)
. Qty VALVE MISC. Years Part No. Size Desc.
.   8 Rotocap Assy. 73-66 FPRC126SA . Exh.; Incl. Rotocap & Valve Spring
.   8 Rotocap 73-66 FP443128 $15.82 . Exh.
. Qty VALVE SEAL Years Part No. Size Desc.
.  16 O-Ring 73-66 FP111024 $1.35 . Rubber
ENGINE BLOCK & PARTS
. Qty Cam Bearings Years Part No. Size Desc.
.   1 Cam Set 73-66 FP448139 $98.42 STD .
Crankshaft/OIL PUMP
. Qty SEALS -
FRONT CRANK
Years Part No. Size Desc.
.   1 Redi-Sleeve 73-66 99248 55.60 . .
.   1 Oil Seal 73-66 7581H 38.44 . .
. Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
.   1 Oil Seal Kit 73-66 5065 74.32 . .
. Qty Main bearings Years Part No. Size Desc.
.   1 Main Set 73-66 FP5032M $200.17 STD .
.   1 Main Set 73-66 FP5032M10 $200.17 10 .
.   1 Main Set 73-66 FP5032M20 $182.77 20 .
.   1 Main Set 73-66 FP5032M30 $200.17 30 .
.
43 H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
CYL. HEAD & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
1   1 Breather Housing Gasket 83-75 FP673973 $4.87 . .
(continued on next page)

Page 109
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
CYL. HEAD & PARTS (cont.)
Ref # Qty Gaskets (cont.) Years Part No. Size Desc.
2   6. Grommet 83-75 FP677692 $2.00 . Valve Cover Bolt
3   1 Valve Cover Gasket 83-75 FP675109 $15.73 . .
5   1 Head Gasket 83-75 FP1819547 $68.15 . .
.   1 Head gasket set 83-75 FP1808973 $179.59 . .
Ref # Qty VALVE Years Part No. Size Desc.
19   6. Intake 83-75 FP675046 $20.59 . .
20   6. Exhaust 83-75 FP676865 $25.30 . .
24  24 Keeper 83-75 FP41339 $1.16 . 1 groove; Square cut key groove
24  24 Keeper 83-75 VK138 $1.02 . 1 groove; Square cut key groove; Carton pack 32
24  24 Keeper 83-75 VK138R $0.48 . 1 groove; Square cut key groove; Hardened
Ref # Qty VALVE SEAT Years Part No. Size Desc.
25   6. Exh. 83-75 FP671563 $17.27 2 .
25   6. Exh. 83-75 FP671565 $14.15 15 .
25   6. Int. 83-75 FP671559 $14.25 2 .
25   6. Int. 83-75 FP671561 $8.03 15 .
Ref # Qty VALVE GUIDE Years Part No. Size Desc.
26  12 Guide 83-75 FP675439 $7.47 . 2.750" O.A.L.; .3745" ID, 2.7500" O.A.L.
Ref # Qty VALVE SPRING Years Part No. Size Desc.
27  12 Spring 83-75 FP682064 $7.38 . To Ser. No. 74999; 2.3400" Free Height
Ref # Qty PUSH RODS Years Part No. Size Desc.
.  12 Push Rod 83-75 FP675621 $18.91 . To Ser. No. 532980; 11.4000" O.A.L.
Ref # Qty VALVE MISC. Years Part No. Size Desc.
32   6. Rotocap Assy. 83-75 FP1811581 $15.82 . Exh.
Ref # Qty VALVE SEAL Years Part No. Size Desc.
41  12 Valve Stem Seal 83-75 FP1815374 $4.29 . From Ser. No. 594840
41  12 Valve Stem Seal 83-75 FP681234 $1.02 . To Ser. No. 594839; Umbrella type
(continued on next page)

Page 110.
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
INT & EXH MANIFOLDS


Ref # Qty Int. & Exh. Manifolds Years Part No. Size Desc.
4 1 Intake Manifold Gasket 83-75 FP682199 $15.68 . .
(continued on next page)

Page 111
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
Camshaft GROUP
Ref # Qty TIMING Years Part No. Size Desc.
24   1 Cam Gear 83-75 FP675600 $158.41 . 66 Teeth
Ref # Qty Camshaft TIMING Years Part No. Size Desc.
42   1 Woodruff Key 83-75 FP218211 $2.70 . Cam gear; 1/4" x 3/4"
Ref # Qty Camshaft / Lifter Years Part No. Size Desc.
54  12 Lifter 83-75 FP911776 $14.09 . Mech.; .997" dia. body
FUEL SYSTEM & PARTS
. Qty FUEL Injection Years Part No. Size Desc.
.   6. Fuel Injector Sleeve 83-75 FP675442 $11.91 . .
(continued on next page)

Page 112
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
COOLING SYSTEM


Ref # Qty Thermostat Years Part No. Size Desc.
22 1 Thermostat Gasket 75-83 FP675384 $1.86 . .

(continued on next page)

Page 113.
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
ENGINE BLOCK & PARTS
Ref # Qty Gaskets Years Part No. Size Desc.
5   1 Oil Pan Gasket 83-75 FP671825 $34.76 . .
Ref # Qty GASKET SETS Years Part No. Size Desc.
.   1 Lower Gasket Set 83-75 FP674399 $165.30 . Crankshaft seals not incl.
Ref # Qty Cam Bearings Years Part No. Size Desc.
19   1 Cam Set 83-75 FP680117 $38.02 STD .
(continued on next page)

Page 114.
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
Crankshaft/OIL PUMP
Ref # Qty Crankshaft Years Part No. Size Desc.
1   1 Crankshaft 83-75 FP675669 $2,752.23 . .
Ref # Qty SEALS -
REAR CRANK
Years Part No. Size Desc.
8   1 Oil Seal Kit 83-75 FP1809964 $39.56 . Incl. seal & wear sleeve
Ref # Qty Main bearings Years Part No. Size Desc.
37   1 Main Set 83-75 FP1823847 $278.09 STD Narrow
37   1 Main Set 83-75 FP1823848 $317.90 10 Narrow
37   1 Main Set 83-75 FP1823849 $325.74 20 Narrow
37   1 Main Set 83-75 FP1823850 $327.35 30 Narrow
Ref # Qty OIL PUMP Years Part No. Size Desc.
31   1 Oil Inlet Elbow Gasket 83-75 FP671821 $2.91 . Oil inlet elbow
(continued on next page)

Page 115
International/Navistar Truck
43
(cont.)
H/D Truck D466 Eng.
7.6L
466 OHV Diesel L6 (12 Valve), 4.3005" Bore 1975-83
CYLINDER COMPONENTS
Ref # Qty Liners Years Part No. Size Desc.
1   6. Piston & Liner Kit w/o Rings 83-75 FP1802580 $308.35 . To Ser. No. 74999; 15.2:1 C.R.
3   6. Cylinder Kit Complete 83-75 FP687432 $309.97 STD To Ser. No. 74999; For Engs. equipped w/side mounted breather; 15.2:1 C.R.
Ref # Qty Pistons Years Part No. Size Desc.
13   6. Piston Body w/o Pin 83-75 FP684255 $163.60 . To. Ser. No. 74999; 15.2:1 C.R.
Ref # Qty Connecting RODS &
BRGS.
Years Part No. Size Desc.
27   6. Rod Pair 83-75 FP681314 $17.43 STD Narrow
27   6. Rod Pair 83-75 FP681315 $18.84 10 Narrow
27   6. Rod Pair 83-75 FP687382 $18.84 20 Narrow
27   6. Rod Pair 83-75 FP681316 $18.84 30 Narrow
27   6. Rod Pair 83-75 FP68131440 $22.41 40 Narrow
Ref # Qty PISTON RINGS Years Part No. Size Desc.
33   6. Ring Set Single Cylinder 83-75 FP684256 $65.06 STD Engs. w/side mounted breather; 2-1/8, 1-1/4; Incl. narrow gap intermediate rings
.   1 Premium Set 83-75 FP684256S $387.72 STD Engs. w/side mounted breather; 2-1/8, 1-1/4; Incl. narrow gap intermediate rings

Top of Page

HOME
