Maxiforce Diesel Overhaul kits, Inframe kits, Basic Kits & parts from RPM

Maxiforce Diesel Engine Kits & Parts

John Deere®, Perkins®, Caterpillar®, Yanmar®, Cummins®, Kubota®, Mitsubishi®, Shibaura®, International Harvester®/Navistar® & Others

Over 30 years of supplying quality diesel parts

Replacement parts for the following engines:

John Deere®, Perkins®, Caterpillar®, Yanmar®, Cummins®,
Kubota®, Mitsubishi®, Shibaura®
and International Harvester®/Navistar®.

Brand and Engine Kit key:
John Deere - Prefix T, TOK = Out of Frame Engine Kit, TIK= In Frame Engine Kit
Cummins - Prefix C, COK = Out of Frame Engine Kit, CIK= In Frame Engine Kit
Caterpillar - Prefix B, BOK = Out of Frame kit w/valve train kit, BBK = Out of Frame Engine Kit
Perkins - Prefix P, POK = Out of Frame kit w/valve train kit, PBK = Out of Frame Engine Kit
Mitsubishi - Prefix M, MOK = Out of Frame kit w/valve train kit, MBK = Out of Frame Engine Kit
Yanmar - Prefix Y, YOK = Out of Frame Engine Kit
Kubota - Prefix K, K(Engine model)xx - Out of Frame Engine Kit
Navistar - No Prefix - NOK = Out of Frame Engine Kit, NIK= In Frame Engine Kit

OK = Out of frame kits include:
Description:
Connecting rod bushings
Balance shaft bushing
Camshaft bushing
Connect rod cap screws
Rear oil seal
Crankshaft front seal
Piston-Liner kit
Valve stem seals
Overhaul gasket set
Main bearing set
Thrust washers
Connecting rod bearing set

IF = Inframe Kits Include:
Connecting rod cap screws
Oil pan gasket set
Piston-Liner kit
Valve stem seals
Head gasket set
Main bearing set
Thrust washers
Rod bearing set

Some engines have thrust washers and some don't. Some oil pan gaskets are 1 piece or multiple and sometimes is just a tube of RTV depending on manufacturer.

Cummins® B & C Series • ISB • QSB • QSC • 3.3 Liters • 3.9 Liters • 4.5 Liters • 5.9 Liters • 6.7 Liters • 8.3 Liters

John Deere® 3.152 • 3.164 • 3.179 • 4.202 • 4.219 • 4.239 • 4.270 • 4.276 • 6.101 • 6.303 • 6.329 • 6.359 • 6.404 • 6.414 • 6.466
6.531 • 6.619 • 3016 • 3029 • 4020 • 4024 • 4033 • 4039 • 4045 • 5030 • 6076 •6068 • 6081 • 6090 • 6125•6135

Perkins® 3.152 • 4.108 • 4.203 • 4.212 • 4.236 • 4.248 • 4.318 • 6.354 • 104-22 • 403C-15 • 403D-15 • 404C-22 • 404D-22
404F-22 • 704-30 • 804C-33 • 804D-33 • 1004.40 • 1004.42 • 1006.60 • 1103 • 1104 • 1106C • 1106D • 1204E • 1206E
• 1206F

Yanmar® 3TNE84 • 3TNE84T • 3TNE88 • 3TNV70 • 3TNV76 • 3TNV84 • 3TNV88 • 4TNE106D • 4TNE106T • 4TNE84
4TNE86 • 4TNE88 • 4TNE92 • 4TNE94 • 4TNE98 • 4TNV106 • 4TNV106T • 4TNV84 • 4TNV84T • 4TNV86 • 4TNV88 • 4TNV94L • 4TNV98 • 4TNV98C • 4TNV98CT • 4TNV98T • TK486 • TK486V

Mitsubishi® S4K • S4S • S4S DT • S6K • S6S • S6S D • S6S DT

Shbaura N4LDI • N843 • N843L • N844 • N844L • N844L-D • N844L-F • N844LT • N844LT-D • N844LT-F • N844LTA-D • N844T

Komatsu® 3D70E • 3D76E • 3D84E • 3D88E • 4D84E • 4D88E • 4D94E • 4D94LE • 4D95LE • 4D98E • 4D102 • 4D106
4D107 • 6D102 • 6D107 • 6D114 • S3D84E • S4D95LE
• S4D106

Kubota® D902 • D905 • D1105 • D1703 • D1803 • V1505 • V1702 • V2003 • V2203 • V2403 • V2607 • V3300 • V3307
V3307-CR • V3800 • V3800-CR

IH/Navistar® DT360 • DT414 • DT436 • DT437 • DT466

Isuzu® 3CA1 • 3CB1 • 3CD1 • 3CE1 • 4GC1T

CATALOG INDEX:
Click on link to go to table for kits & parts

John Deere Page John Deere Page

John Deere 3.152 O'rings on liner 2 John Deere 3.152 O'rings on Block 3

John Deere 3.164 Small Pin, O'rings on Liner 4 John Deere 3.164 Small Pin, O'rings on Block 5

John Deere 3.164 Large Pin, O'rings on Block 6 John Deere 3.179D 7

John Deere 3029D Liter Designated 8 John Deere 3.179T 9

John Deere 3029T Liter Designated 10 John Deere 4.202 O'rings on liner 11

John Deere 4.202 O'rings on block 12 John Deere 4.219 Small Pin, O'rings on Liner 13

John Deere 4.219 Small Pin, O'rings on Block 14 John Deere 4.219 Large Pin, O'rings on Block 15

John Deere 4.239D 16 John Deere 4039D Liter Designated 17

John Deere 4.239T 18 John Deere 4039T Liter Designated 19

John Deere 4.276D Small Pin 20 John Deere 4.276D Large Pin 21

John Deere 4045D Liter Designated 22 John Deere 4.276T 23

John Deere 4045T Liter Designated 24 John Deere 6.303 O'rings on Liner 25

John Deere 6.303 O'rings on Block 26 John Deere 6.329 Small Pin, O'rings on Liner 27

John Deere 6.329 Small Pin, O'rings on Block 28 John Deere 6.329 Large Pin, O'rings on Block 29

John Deere 6.359D 30 John Deere 6059D Liter Designated 31

John Deere 6.359T 32 John Deere 6059T Liter Designated 33

John Deere 6.414D Large Pin 34 John Deere 6068D Liter Designated, Large Pin 35

John Deere 6.414T 36 John Deere 6068T Liter Designated 37

John Deere 4.270 To ESN 280,000 See Block 38 John Deere 4.270 To ESN 280,000 39

John Deere 4.270 To ESN 280,000 Early Power Booster 40 John Deere 4.270 From ESN 280,001 41

John Deere 6.404D To ESN 214,999 See Block 42 John Deere 6.404D To ESN 214,999 43

John Deere 6.404D To ESN 214,999 Early Power Boost 44 John Deere 6.404D ESN 215,000 – 335,845 45

John Deere 6.404D From ESN 335,846 46 John Deere 6.404T/A To ESN 335,845 47

John Deere 6.404T/A From ESN 335,846 48 John Deere 6.466D 49

John Deere 6.466A/T Con Rod (m): R57303, R67320 50 John Deere 6.466A/T Con Rod (m) R71074 51

John Deere 6.466A ESN 233,593-317,858 52 John Deere 6076 T/A/H Low Ring Piston 53

John Deere 6076 T/A/H High Ring Piston 54 John Deere 6.531D See Con. Rod (m) 55

John Deere 6.531T See Con. Rod (m) 56 John Deere 6.531A See Con. Rod (m) 57

John Deere 6.619A/T Early 58 John Deere 6.619A/T Mid 59

John Deere 6.619A/T Late 60 John Deere 6.101A/T TO ESN 499,999 61

John Deere 3TNE84 84mm Bore Non Turbo 62 John Deere 4TNE84 84mm Bore Non Turbo 63

John Deere 4TNE84T 84mm Bore Turbo 64 John Deere 3TNE88 88mm Bore Non Turbo 65

John Deere 4TNE88 88mm Bore Non Turbo 66 John Deere 3TNV84 84mm Bore Non Turbo & Turbo 67

John Deere 4TNV84 84mm Bore Non Turbo 68 John Deere 4TNV84T 84mm Bore Turbo 69

John Deere 3TNV88 88mm Bore Non Turbo 70 John Deere 4TNV88 88mm Bore Non Turbo 71

John Deere 4TNV98 98mm Bore Non Turbo Direct Injection 72 John Deere 4TNV98T 98mm Bore Turbo Direct Injection 73

John Deere 3029 2.9D Piston (m) RE61467 74 John Deere 3029 2.9D/T Piston (m) RE520573 75

John Deere 3029 2.9T Piston (m) RE61270 76 John Deere 3029 2.9T Piston (m) RE500211 77

John Deere 4024TL, TIER 3, PISTON (M) RE522094 78 John Deere 4024TT Early, TIER 2, PISTON (M) RE516347 79

John Deere 4024TT Late, TIER 2 & 3, PISTON (M) RE526785 80 John Deere 4024HF, TIER 3, PISTON (M) RE527622 81

John Deere 4045 4.5T/H Piston (m) RE55512/RE505102 82 John Deere 4045 4.5T/H Piston (m) RE527039 Tier 2 & Tier 3 83

John Deere 4045 4.5T/H Piston (m) RE521616 Tier 2 & Tier 3 84 John Deere 4045 4.5T/H Piston (m) RE515037 Tier 2 & Tier 3 85

John Deere 4045 4.5T/H Piston (m) RE507758 Tier 2 & Tier 3 86 John Deere 4045 4.5T/H Piston (m) RE515037 Tier 2 & Tier 3 (2) 87

John Deere 4045 4.5T/H Piston (m) RE545770 Tier 2 & Tier 3 88 John Deere 4045D 4.5D Piston (m) RE59279/RE505101 89

John Deere 4045T 4.5T Piston (m) RE59277/RE505100 90 John Deere 4045 4.5T/H Piston (m) RE544601 Interim Tier 4 91

John Deere 4045 4.5T/H Piston (m) RE544607 Interim Tier 4 92 John Deere 4045 4.5T/H Piston (m) RE551101 Tier 4 Final 93

John Deere 4045 4.5T/H Piston (m) RE570485 Tier 4 Final 94 John Deere 5030TT Late, TIER 2 & 3, PISTON (M) RE526785 95

John Deere 5030TT Early, TIER 2, PISTON (M) RE516347 96 John Deere 5030TL, TIER 3, PISTON (M) RE522094 97

John Deere 5030HF, TIER 3, PISTON (M) RE527622 98 John Deere 6068 6.8T/H Piston (m) RE55512 / RE505102 99

John Deere 6068 6.8T/H Piston (m) RE521616 Tier 2 & Tier 3 100 John Deere 6068 6.8T/H Piston (m) RE515037 Tier 2 & Tier 3 101

John Deere 6068 6.8T/H Piston (m) RE507758 Tier 2 & Tier 3 102 John Deere 6068 6.8T/H Piston (m) RE527039 Tier 2 & Tier 3 (2) 103

John Deere 6068 6.8T/H Piston (m) RE545770 Tier 2 & Tier 3 1 04 John Deere 6068 6.8L Piston (m) RE544601 Interim Tier 4 105

John Deere 6068 6.8L Piston (m) RE553821 Tier 4 Final 106 John Deere 6068 6.8L Piston (m) RE544607 Interim Tier 4 107

John Deere 6068D 6.8D Piston (m) RE59279/RE505101 108 John Deere 6068T 6.8T Piston (m) RE59277 / RE505100 109

John Deere 6081 High Compression Piston, to ESN 199,999 110 John Deere 6081 Low Compression Piston, to ESN 199,999 1 11

John Deere 6081 Forged Steel Piston, from ESN 200,000 and up 112 John Deere PowerTech 6090 9.0L Tier 2 & 3, Piston # RE529264 113

John Deere PowerTech 6090 9.0L Tier 4, Piston # RE555132 114 John Deere PowerTech 6090 9.0L Tier 4, Piston # DZ102298 115

A complete list of equipment models.
Pages 429 to

Page 2
JOHN DEERE 3.152 O’RINGS ON LINER

Engine Desc: To ESN 154,765

Engine Data: O'rings on Liner Engine Info: }3 Cyl

Engine Dimensions: Bore: 3.86 in / 98 mm Pin Ø: 1.1878 in / (+/- .0001)= 30mm Block (M): T24963, T26935

Con Rod (M): T20007, R81410 Piston (M): T23481

Farm Tractors 820 1020 1030 Backhoe Loaders 300 300A

Crawler Dozers 350A 350B
Forklifts 380

Engine Series: 300

1) Engine O/H Kit TOK3481 $723.88
2) Engine I/F Kit TIK3481 $648.93 SPEC SHEET - 3.152 JOHN DEERE || Piston-Liner Kit TPLK481 $155.34 Consists of:
a) TT23481 $62.93
b) TAR70633 $22.53
c) TT23482 $11.17
d) TAR51902 $59.32
e) TR51112 $1.06 Main Bearing TRE27352 $12.77 Std. TRE27353 $12.77 0.010 TRE27360 $12.77 0.020 TRE27368 $12.77 0.030 Use 3 Thrust Bearing TAT21139 $31.78 Std. TAT21132 $31.78 0.010 TAT21134 $31.78 0.020 TAT21136 $31.78 0.030 Use 1 Con Rod Bearing TRE27348 $9.06 Std. TRE27349 $9.06 0.010 TRE27358 $9.06 0.020 TRE27364 $9.06 0.030
Use 3

1) Front Seal TAR67942 $8.22
2) Rear Seal TRE44574 $27.17 1
3) Crankshaft TAT18031 $1,268.75
4) Crankshaft, Gear TT20094 $67.03
5) Ring Gear TR114282 $34.92 (142T) 1) O/H Gasket Set TRE38570 $107.94
2) Head Gasket Set TRE38848 $67.11
3) Head Gasket TR98460 $32.84
4) Oil Pan Gasket TR97341 $10.88
5) Rocker Cover Gsk TR75729 $16.07
6) Timing Cover Gasket TT20273 $2.33
7) Gasket Thermostat Housing TT20219 $0.68 1) Bush, Con Rod TT23471 $8.54 x3
2) Bolt, Con Rod TR74194 $2.78 x6 4
3) Camshaft Kit TRE55900 $418.14 5
4) Con Rod TAT18005 $87.01 1) Pump, Oil TRE55343 $175.48
2) Oil Cooler TRE31929 $203.71 3
3) Rocker Arm TRE31973 $30.36
4) Rocker Shaft TR54985
5) Pump, Oil Tube TR113752 $10.66
6) Oil Pump O'Ring TR61871 $1.39 1) Lower Gear TAT24252 $104.82
2) Lower Bushing TT26321 $7.66
3) Upper Gear TAT18009 $131.91
4) Upper Bushing TT20034 $5.89
5) Cam. Follower TT20073 $10.31 x6
6) Cam. Gear TT20070 $102.27
7) Camshaft Kit TRE55900 $418.14 5

Valve, Intake ; Std. TR79628 $8.76 0.003 TR79629 $8.76 0.015 Valve, Exhaust TR79624 $10.82 Std. TR79625 $10.24 0.003 TR79626 $11.61 0.015 1) Insert, Valve In TR73064 $10.74 Std.
2) Insert, Valve Ex TR51734 $11.59 Std. 1) Cap, Valve TT20129 $2.48
2) Lock, Valve TT20077 $0.86 1) Spring, Valve TR26125 $2.60
2) Rotator, Valve TRE11410 $11.43
3) O'ring, Valve TR87627 $0.44

1) Thermostat TRE33705 $9.51
180° F
2) Thermostat Cover TT23620 $13.50
3) Thermostat Cover Gsk TT20215 $0.68 2 1) Fuel Transfer Pump TRE42211 $50.45
2) Fuel Pump Gasket TR27285 $1.16 Water Pump Repair Kit Without Impeller TRE19507 $54.23 6 With Impeller TRE62658 $67.56 6
2)
Water Pump Gasket TT20242 $3.83 TT20268 $4.39 1) Injector, Pencil TAR89564 $52.85
2) Kit, Grommet TMX504 $10.37
3) Cap TAT27622 $5.51 TAR85618 $8.44
4) Washer TT29539 $0.41
5) Tube Nut TR51937 $3.42 Seal, Injector TR60746 $0.33 TR48000 $0.94

(1): Do not use with Flywheel Housing (m) T20300, T22991.
(2): Do not use with Housing (m) R54096, R70741, R74549.
(3): Conversion Kit TMX386: Available Consists of: TT31306, X1 Nipple
TR99802, X2 Hose.
(4): Use TR74194, with C.Rod (m) T20007; use TR80033, with C.Rod (m) R81410.
(5): Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked
T20015, T20016, R79643, R106957, and RE522311.
(6): See the Water Pump Identification Chart to make sure these part numbers are correct. You will need the water pump casting number and will need to know if you have a stamped steel pulley or a cast iron pulley.
